330130-070-01-00

/ 4.9
1001 reviews | Need a Specific Revision?
Bently Nevada 330130-070-01-00 is a 7.0 m armored FEP extension cable without agency approvals for completing a calibrated 3300 XL 8 mm proximity transducer system.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for 330130-070-01-00
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330130-070-01-00

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330130-070-01-00
  • Product Family:
    3300 XL Extension Cable
  • Product Type:
    3300 XL standard armored extension cable
  • Stock:
    1
  • Cable family:
    3300 XL standard extension cable
  • Length:
    7.0 m (22.9 ft)
  • Connector and cable option:
    Armored cable
  • Approval option:
    Not required
  • Armor and insulation:
    FEP
  • Characteristic impedance:
    75 Ω
  • Capacitance:
    69.9 pF/m typical
  • Cable outside diameter:
    3.7 mm maximum
  • Armor outside diameter:
    7.67 mm maximum
  • Ferrule diameter:
    10.2 mm maximum
  • Minimum bend radius:
    25.4 mm
  • Tensile strength:
    330 N maximum
  • Operating/storage temperature:
    -52°C to +177°C
  • Weight:
    1.59 lbs (0.721 kg)
  • Tariff Code:
    8544429090
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Cable Position Armor Routing Limits Electrical Length

Features:

  • 7.0 m calibrated electrical length
  • Armored FEP triaxial construction
  • No agency approval option
Bently Nevada 330130-070-01-00 carries the probe signal to the matching Proximitor sensor as part of a calibrated 3300 XL path.

The armored FEP structure of 330130-070-01-00 protects the triaxial cable while retaining the connector and ferrule geometry required at the enclosure.

Selection and routing of 330130-070-01-00 must preserve total system length, bend radius, connector cleanliness, and the no-approval suffix.

The Bently Nevada 330130-070-01-00 3300 XL standard armored extension cable may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 330130-070-01-00 3300 XL standard armored extension cable Manuals,Datasheets,LinkImportant Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Probe-to-Proximitor Cable Position

  • Probe side: One connector joins the extension cable to the selected proximity probe.
  • Sensor side: The opposite connector terminates at the matching Proximitor sensor.
  • Calibrated chain: Probe length and extension-cable length together define the electrical system length.
  • Replacement check: A cable with the same physical reach but different suffixes can change construction or approvals.

FEP Cable and Armor Transition

  • Insulation: FEP forms the standard-temperature electrical insulation.
  • Armor: The external armor protects the cable from mechanical damage.
  • Ferrule: The armor ferrule provides the transition into the connector region.
  • Clearance: Connector and 10.2 mm ferrule dimensions must fit the selected enclosure entry.

Routing and Mechanical Limits

  • Bend radius: The installed route must maintain at least a 25.4 mm bend radius.
  • Pulling load: Tensile force is limited to 330 N maximum.
  • Transition support: The armor end must not carry concentrated bending or pulling load.
  • Temperature: The cable is specified from -52°C to +177°C.

Length Code and Calibration

  • Length option: The 070 code identifies a 7.0 m extension cable.
  • Length sum: The connected probe length must be added to the 7.0 m cable length.
  • Tolerance: Manufactured cable length uses a +20%/-0% tolerance.
  • Approval code: The final 00 means no listed agency approval option is included.
Description
Bently Nevada 330130-070-01-00 is a standard 3300 XL extension cable that carries the probe signal to the matching Proximitor sensor. Its 7.0 m electrical length must be combined with the selected probe length to equal the Proximitor sensor system length.

Armored FEP construction protects the triaxial path of 330130-070-01-00 while maintaining the connector geometry used by the 3300 XL system. The armor ends before the cable length so the connector and ferrule can be routed into the sensor enclosure without exceeding their clearance dimensions.

The approval option of 330130-070-01-00 is 00, so no agency approval is included in this cable configuration. Proper operation still depends on clean connectors, the specified bend radius, and a matched probe-cable-Proximitor length rather than cable length alone.
Alternative Names
3301300700100 330130 070 01 00 330130-070 01-00 Bently Nevada 330130-070-01-00 330130-070-01-00 XL Extension Cable 33O13O-O7O-O1-OO 330I30-070-0I-00 330130 070-01 00
Technical notes
Within a matched 3300 XL chain, Bently Nevada 330130-070-01-00 supplies a 7.0 m armored FEP path with no agency approval option.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What must be added to the 7.0 m length of 330130-070-01-00?
Add the connected probe length to 330130-070-01-00; their sum must equal the total length encoded by the selected Proximitor sensor.
Why is 330130-070-01-00 not the same as 330130-070-03-00?
The 01 suffix makes 330130-070-01-00 an armored cable without a connector protector, whereas option 03 adds the protector to the armored cable.
Can 330130-070-01-00 be bent tightly to fit a small junction box?
No. Routing 330130-070-01-00 below its 25.4 mm minimum bend radius can damage the triaxial cable and alter the measurement path.
What does the final 00 mean for 330130-070-01-00?
The final 00 means 330130-070-01-00 is ordered without the listed CSA, ATEX, and IECEx approval option; it is not a cable-length code.
Which physical checks come first when 330130-070-01-00 signal continuity is lost?
Inspect both 330130-070-01-00 coaxial connector interfaces, armor transition, bend points, and total system-length match before replacing calibrated components.
