    Apter Power guarantees premium quality Bently Nevada 330130-080-03-CN proximity hardware, offering a highly reliable source for critical machinery protection replacement parts.

330130-080-03-CN

/ 4.9
1001 reviews | Need a Specific Revision?
The 3300 XL Standard Extension Cable (330130-080-03-CN) is designed to extend the connection of 3300 XL proximity transducer system.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for 330130-080-03-CN
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330130-080-03-CN

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330130-080-03-CN
  • Stock:
    1
  • Cable Length:
    8.0 meters (26.2 feet)
  • Connector Protector and Cable:
    Armored cable with connector protector
  • Agency Approval:
    CSA, ATEX, IECEx Approvals
  • Ambient Temperature:
    +18°C to +27°C (+64°F to +80°F).
  • Maximum Altitude:
    Up to 2000 meters.
  • Power Supply:
    -24 Vdc.
  • Load:
    10 kΩ.
  • Weight:
    0.82 kg
  • Estimated shipping dimensions:
    30x30x3cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Monitoring & Control Environmental Ratings

Features:

  • Integrated Stainless Steel Armor Conduit (03 Option)
  • Patented ClickLoc Gold-Plated Fluid-Resistant Connectors
  • Calibrated 200 mV/mil Electrical Performance Interchangeability
The Bently Nevada 330130-080-03-CN features premium stainless steel interlocking armor that provides elite crush-resistance and structural shielding. This robust barrier protects the inner premium coaxial cable from intense physical degradation, shearing stress, and abrasion inside conduits, ensuring long-term structural survivability across extreme industrial oil/gas plants.

Equipped with specialized gold-plated brass connections, the Bently Nevada 330130-080-03-CN ensures minimal insertion loss and eliminates oxide-driven signal drifting. The toolless ClickLoc mechanism provides an audible locking click, while the integrated elastomeric protector sleeves block hazardous hydrocarbons, steam, and abrasive dust from corrupting the signal interface.

The internal core of the Bently Nevada 330130-080-03-CN is manufactured to strict electrical length and impedance tolerances. This allows it to match perfectly within any standard 9-meter XL loop, maintaining an uncompromised linear scale factor without any external calibration, reducing field commissioning time from hours to mere minutes.

The 6SE7028-0ES87-2DA1 Siemens SIMOVERT MASTERDRIVES Braking Unit may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 330130-080-03-CN 3300 XL 8mm Standard Proximity Transducer Extension Cable Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 330130-080-03-CN 3300 XL 8mm Standard Proximity Transducer Extension Cable

General

  • Manufacturer Bently Nevada
  • Model 330130-080-03-CN
  • Condition New Original ready stock
  • Product Family 330130-080-00-05,330130-080-01-05,330130-040-00-00
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • High-Speed Steam and Gas Turbines: The Bently Nevada 330130-080-03-CN is critical for connecting bearing-housed displacement probes on large power generation turbines, tracking sub-micron oil-film journal variations to avoid catastrophic rotor-to-stator contact.
  • Critical Petrochemical Centrifugal Compressors: Operating reliably inside hazardous API 617-compliant hydrocarbon compressors, this armored cable transmits uninterrupted shaft vibration data under constant chemical exposure and extreme structural shaking.
  • Large-Scale Boiler Feed Water Pumps: Utilized extensively in power plant utility blocks, the Bently Nevada 330130-080-03-CN withstands ambient high-temperature steam leaks while delivering vital axial thrust position readings to prevent internal pump destruction.
  • Heavy Industrial Induced Draft (ID) Fans: Ideal for harsh steel or cement mills, the armored outer layer of the Bently Nevada 330130-080-03-CN resists flying abrasive dust particles and heavy ash falling into open cooling towers or exhaust ducts.
  • Continuous Radial Vibration Tracking: When integrated into a standard loop, the Bently Nevada 330130-080-03-CN flawlessly conveys high-frequency dynamic orbital movements, enabling the 3500/42M module to run real-time FFT spectrum diagnostics and detect shaft unbalance or misalignment.
  • Precision Rotor Axial Position Monitoring: The highly linear voltage response provided via the Bently Nevada 330130-080-03-CN tracks slow-moving thrust changes, ensuring the machine protection system safely executes automatic emergency trips if thrust bearing degradation occurs.
  • Eccentricity and Phase Angle Detection: By linking a Keyphasor probe across long distances, the Bently Nevada 330130-080-03-CN assists in tracking the precise timing of peak vibrations, giving maintenance managers accurate data for complex balancing procedures.
  • Dynamic Machinery Condition Trending: The unwavering stability of the Bently Nevada 330130-080-03-CN prevents false alarms in your plant's Distributed Control System (DCS), allowing reliable long-term health trending through standard Modbus or Profitnet communications.
  • Elite Temperature Endurance: With an operational threshold spanning from -51°C up to +177°C, the Bently Nevada 330130-080-03-CN can be safely routed through extreme arctic outdoor setups as well as intense furnace-adjacent machinery decks.
  • Corrosive Hydrocarbon and Oil Resistance: The advanced outer materials and armored jacket protect the internal conductor cores from chemical breaking, allowing the Bently Nevada 330130-080-03-CN to sit submerged in lubrication oils or splash-heavy environments without loss of insulation.
  • Intrinsically Safe Intended Use: Tailored via its "CN" option, the Bently Nevada 330130-080-03-CN satisfies rigorous NEPSI requirements for Zone 0, Zone 1, and Zone 2 installations when connected via an approved galvanic isolation barrier or Proximitor housing.
  • Total Condensing Moisture Protection: When utilizing its built-in connector protectors, the Bently Nevada 330130-080-03-CN achieves 100% relative humidity resistance, blocking corrosive condensation inside tropical coastal refineries from degrading the core connection.
Description
The 3300 XL Standard Extension Cable (330130-080-03-CN) is designed to extend the connection of 3300 XL proximity transducer systems, ensuring reliable signal transmission between the probe and monitoring equipment.

This cable features a length of 8.0 meters (26.2 feet), suitable for installations requiring longer reach. It comes as an armored cable with a connector protector, providing enhanced mechanical protection and durability in demanding industrial environments.


As part of the iconic 3300 XL portfolio, the Bently Nevada 330130-080-03-CN completely eliminates the need for tedious matching of individual components. It supports 100% total interchangeability across probes and Proximitor sensors, and maintains full backward compatibility with legacy non-XL 3300 5mm and 8mm series, significantly optimizing your plant's spare parts inventory costs.


The 3300 XL Standard Extension Cable (330130-080-03-CN) carries CSA, ATEX, and IECEx approvals, making it compliant for use in hazardous and regulated locations.
Alternative Names
330130 080 03 CN 330130-080-03-00 330130-080-03-05 330130-085-03-CN 330130-080-00-05 330130-080-01-05 330130-040-00-00
Technical notes
The Bently Nevada 330130-080-03-CN must maintain a tight loop configuration with a combined total system length of 9.0 meters (when paired with a 1.0m probe) to guarantee the exact 7.87 V/mm (200 mV/mil) linear scale factor. It is critical to ensure that the gold-plated ClickLoc connectors of the Bently Nevada 330130-080-03-CN are clean, dry, and audibly "clicked" during field installation to avoid impedance mismatches or intermittent diagnostic faults.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How does the electrical length of the Bently Nevada 330130-080-03-CN affect the overall proximity loop calibration and scale factor?
The Bently Nevada 330130-080-03-CN has a strict physical length of 8.0 meters, which must be combined specifically with a 1.0-meter unextended probe to form a calibrated 9.0-meter system. The internal capacitance (69.9 pF/m) and impedance are tightly controlled; if you modify or cut the Bently Nevada 330130-080-03-CN, the electrical balance will collapse, causing a severe shift in the 7.87 V/mm (200 mV/mil) Scale Factor and inducing false vibration errors in your 3500/42M monitor.
Can the Bently Nevada 330130-080-03-CN be integrated directly with legacy, non-XL 3300 Proximitor Sensors without software reconfiguration?
Yes, the Bently Nevada 330130-080-03-CN is fully backward compatible with standard non-XL 3300 5mm and 8mm transducer components. However, engineers must ensure the Proximitor sensor configuration matches a 9-meter total system length; no software or firmware updates are required on the receiving I/O modules, as the hardware seamlessly provides analog voltage outputs directly proportional to the physical gap.
How does the armor of the Bently Nevada 330130-080-03-CN impact isolation from high-frequency electromagnetic noise and grounding loops?
The stainless steel armor of the Bently Nevada 330130-080-03-CN acts as a powerful physical shield but is electrically isolated from the internal coaxial shield. To prevent destructive grounding loops, the coaxial shield must remain isolated from the machine ground; the armor of the Bently Nevada 330130-080-03-CN should be grounded through the terminal housing box, while the internal signal line relies on the Proximitor Sensor’s clean, floating instrumentation ground.
What are the installation bending limits and environmental restrictions when routing the Bently Nevada 330130-080-03-CN through narrow conduits?
Due to the interlocking stainless steel armor option (03), the Bently Nevada 330130-080-03-CN has a strict minimum bending radius of 25.4 mm (1.0 inch). Exceeding this bend radius will kink the armor, permanently crushing the inner Teflon insulation and altering system capacitance. Furthermore, while the Bently Nevada 330130-080-03-CN withstands extreme temperatures up to +177℃, it cannot be continuously submerged in pressurized liquid without specialized conduit housing.
