106765-20

/ 4.9
1001 reviews | Need a Specific Revision?
The 106765-20 is an interconnect cable designed for use with the Velomitor XA (eXtended Application) Sensor. This cable assembly features a minimum length of 1 meter (3.3 feet) and maximum length of 25 meters (82 feet).
Get a quick price for 106765-20
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 106765-20

  • Manufacturer:
    Bently Nevada
  • Part Number:
    106765-20
  • Product Family:
    330500 Velomitor Piezo-velocity Sensor
  • Product Type:
    Interconnect Cable for Velomitor XA Sensor
  • Compatible Sensor:
    Velomitor XA (eXtended Application) Sensor
  • Minimum Length:
    1 meter (3.3 feet)
  • Maximum Length:
    25 meters (82 feet)
  • Ordering Increment:
    3 meters
  • Connector Type:
    Weatherproof (mating with sensor)
  • Environmental Rating (with proper installation):
    IP-65, NEMA 4X (dust and moisture resistance)
  • Sensor Case Material:
    316L stainless steel
  • Key Benefit:
    Model 106765-20 eliminates the need for separate protective housings when used with the Velomitor XA sensor, reducing installation complexity and cost.
  • Weight:
    1.2 kg
  • Estimated shipping dimensions:
    32x32x5cm
  • Tariff Code:
    8544492100
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Communication Safety and Compliance

Features:

  • The 106765-20 features a weatherproof connector assembly for reliable performance in moist environments.
  • This model includes IP-65 and NEMA 4X dust and moisture resistance when properly installed.
  • The 106765-20 is specifically designed as an interconnect cable for the Velomitor XA Sensor.
The 106765-20 provides essential connectivity functions that directly affect the environmental integrity of the Velomitor XA Sensor system. When properly installed with its mating extension cable, the 106765-20 helps the sensor assembly meet IP-65 and NEMA 4X dust and moisture resistance ratings. This makes the 106765-20 suitable for use in outdoor and moist environments where standard cables would degrade, reducing installation complexity and cost.

For applications requiring reliable performance in challenging conditions, the 106765-20 is constructed with materials designed to withstand moisture, dust, and industrial contaminants. The weatherproof connector ensures a secure, moisture-resistant seal that maintains signal integrity over extended periods. The 106765-20 complements the 316L stainless steel case of the Velomitor XA Sensor, providing a complete ruggedized solution for vibration monitoring in pumps, compressors, and fans exposed to the elements.

The 106765-20 solves the critical pain point of cable degradation in moist industrial environments by providing a weatherproof, NEMA 4X-rated interconnect solution. This cable eliminates the need for separate protective housings, reducing installation complexity and overall system cost. The 106765-20 ensures reliable signal transmission for Velomitor XA sensors in applications where moisture exposure is a concern, maintaining system integrity without the added expense of external enclosures.

The 106765-20 Bently Nevada Interconnect Cable may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).

Bently Nevada 106765-20 Interconnect Cable Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 106765-20 Interconnect Cable Specs

General

  • Manufacturer GE / Bently Nevada
  • Model 106765-20
  • Condition New Original ready stock
  • Product Family 106765-05,106765-15,106765-25
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Vibration Monitoring Connections: Specifically designed for connecting the 330525 Velomitor XA piezoelectric velocity sensor to terminal housings or monitors.
  • Key Industrial Equipment: Widely used in key rotating equipment such as steam turbines in power plants, compressors in the petrochemical industry, large pumps, and motors.
  • Harsh Environments: Due to its armored protection, it is suitable for industrial sites with physical abrasion, chemical splashes, or high mechanical pressure.
  • Signal Type: Transmits low-noise analog voltage or current signals, ensuring undistorted vibration waveform data over long distances.
  • Armor Design: Externally encased in stainless steel braided layer or flexible metal tubing, providing strong tensile and compressive protection.
  • Connections and Interfaces: Typically, one end connects to a sensor (e.g., Velomitor XA), and the other end connects to a junction box or monitoring cabinet (e.g., the 3500 system).
  • API 670 Standard: Complies with American Petroleum Institute (API) specifications for mechanical protection systems, ensuring reliability in mission-critical applications.
  • Temperature Resistance: Designed for operating temperatures typically from -20°C to +85°C, capable of withstanding the heat environment near engines or turbines.
  • Chemical Resistance: Its sheath material is resistant to oil, fuel oil, and general chemical corrosion.
Description
The 106765-20 operates as an interconnect cable assembly specifically designed for the Velomitor XA (eXtended Application) Sensor, a ruggedized version of Bently Nevada's 330500 Velomitor Sensor. This cable features a weatherproof connector that, when properly mated with the sensor, enables mounting without an external housing.

The 106765-20 plays a critical role in maintaining the environmental integrity of the Velomitor XA Sensor system. When properly installed with its mating extension cable, the 106765-20 helps the sensor assembly meet IP-65 and NEMA 4X dust and moisture resistance ratings.

The 106765-20 is constructed with materials and sealing technology designed to withstand harsh industrial conditions. The weatherproof connector ensures a secure, moisture-resistant connection between the sensor and the cable assembly.

The 106765-20 solves the critical pain point of cable degradation in moist industrial environments by providing a weatherproof, NEMA 4X-rated interconnect solution. This cable eliminates the need for separate protective housings, reducing installation complexity and cost.
Alternative Names
106765-01 106765-05 106765-15 106765-25
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What environmental ratings does the 106765-20 help achieve for the Velomitor XA Sensor?
When properly installed with a mating extension cable, the 106765-20 enables the Velomitor XA Sensor assembly to meet IP-65 and NEMA 4X dust and moisture resistance ratings for use in moist environments.
What are the length options for the 106765-20 interconnect cable?
The 106765-20 is available in custom lengths from a minimum of 1 meter to a maximum of 25 meters, ordered in increments of 3 meters for installation flexibility.
How does the 106765-20 simplify installation compared to standard vibration sensors?
The weatherproof connector and cable assembly eliminate the need for a separate protective housing, allowing direct mounting while maintaining NEMA 4X rating and reducing installation complexity and cost.
What sensor is the 106765-20 designed to work with?
The 106765-20 is specifically designed as an interconnect cable for the Velomitor XA (eXtended Application) Sensor, a ruggedized version of Bently Nevada's 330500 Velomitor Sensor with a 316L stainless steel case.
