    Apter Power supplies 3500/15-05-05-01 as a current dual universal AC configuration documented in the 3500/15 ordering table. Verify compatible rear Power Input Modules.

3500/15-05-05-01

/ 4.9
1001 reviews | Need a Specific Revision?
3500/15-05-05-01 specifies dual universal AC supplies with CSA/NRTL/C Division 2 approval.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for 3500/15-05-05-01
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 3500/15-05-05-01

  • Manufacturer:
    Bently Nevada
  • Part Number:
    3500/15-05-05-01
  • Product Family:
    3500 System
  • Product Type:
    3500/15 Dual Universal AC Power Supply
  • Stock:
    1
  • Current order template:
    3500/15-AA-BB-CC
  • Top-slot supply:
    05, universal AC voltage
  • Bottom-slot supply:
    05, universal AC voltage
  • Input range:
    85 to 264 Vac rms in non-hazardous areas
  • Redundancy arrangement:
    Lower primary and upper backup
  • Agency approval:
    01, CSA/NRTL/C Class I Division 2
  • Rack location:
    Two designated left-side half-height slots
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Ordering Code System Matching Installation

Product overview:

  • Two universal AC power supplies for a redundant 3500 rack
  • Each half-height supply can power the complete rack
  • CSA/NRTL/C Class I Division 2 approval option

3500/15-05-05-01 converts site AC input into the regulated voltages used by installed 3500 modules.

Use compatible rear universal AC PIMs and, where practical, separate primary and backup input sources.

Verified resources for Bently Nevada 3500/15-05-05-01:

Additional technical data:

  • Input frequency: 47 to 63 Hz
  • Maximum full-rack AC current draw: 2.8 A rms
  • Supply module dimensions: 120.7 x 50.8 x 251.5 mm
  • Supply module weight: 1.39 kg
  • Operating environment: -30 to +65 deg C and 95 percent non-condensing humidity

Ordering structure:

  • AA 05 selects a universal AC supply in the top slot
  • BB 05 selects a universal AC supply in the bottom slot
  • CC 01 selects CSA/NRTL/C Class I Division 2
  • The PIMs remain separate rear modules and must match the front supplies

Compatibility checklist:

  • Pair each supply with a universal AC PIM
  • Do not connect universal AC supplies to legacy AC PIMs
  • Confirm the rack backplane and supply revision
  • Use independent sources when redundant power diversity is required

Installation checks:

  • De-energize and verify the rear input wiring before service
  • Confirm the lower primary and upper backup positions
  • Check each green Supply OK indication after power-up
  • Document source voltage, fuse and PIM assignments
Description

3500/15-05-05-01 is a dual universal AC power-supply configuration for the Bently Nevada 3500 rack. Options 05 and 05 install universal AC supplies in both the top and bottom power positions, while option 01 specifies CSA/NRTL/C Class I, Division 2 approval.

Either supply can power a full rack. In a redundant arrangement the lower unit operates as primary and the upper unit as backup, allowing one supply to be removed or inserted without interrupting rack operation when the remaining supply is healthy.

Alternative Names
3500/15-05-05-01 3500 15 05 05 01 3500-15-05-05-01 Bently Nevada 3500/15-05-05-01 Bentley Nevada 3500/15-05-05-01 Bently Nevada 3500 15 05 05 01 3500 System 3500/15-05-05-01 3500/15-05-05-01 Power Supply
Technical notes
3500/15-05-05-01 requires compatible universal AC Power Input Modules; universal AC units are not interchangeable with legacy AC PIMs. Verify both rear PIMs and input sources.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What does 3500/15-05-05-01 include?
The code selects a universal AC supply in both the top and bottom rack power positions with approval option 01.
Which supply is primary in a dual arrangement?
The lower power supply acts as primary and the upper supply acts as backup.
Can each supply power the complete rack?
Yes. Either correctly installed supply is rated to power a full 3500 rack.
Which rear modules must be used?
Match each front universal AC supply with the compatible universal AC Power Input Module located directly behind it.
Are universal AC and legacy AC modules interchangeable?
No. The current universal AC supply and PIM are not compatible with legacy high- or low-voltage AC units.
What happens when one supply is removed?
Rack operation continues without interruption when the other installed supply remains healthy and correctly powered.
Where can input and mounting data be reviewed?
Use the Apter-hosted 3500/15 datasheet in the Manuals tab.
What should be provided for quotation?
Provide rack revision, both PIM numbers, AC source, redundancy requirement, approval destination and quantity.
