    Apter Power supplies 3500/22M-01-01-01 as a current standard TDI and copper-Ethernet I/O configuration. Confirm rack and M-series monitor compatibility.

3500/22M-01-01-01

/ 4.9
1001 reviews | Need a Specific Revision?
3500/22M-01-01-01 is a standard copper-Ethernet TDI with CSA/NRTL/C Division 2 approval.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for 3500/22M-01-01-01
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 3500/22M-01-01-01

  • Manufacturer:
    Bently Nevada
  • Part Number:
    3500/22M-01-01-01
  • Product Family:
    3500 System
  • Product Type:
    3500/22M Transient Data Interface
  • Stock:
    1
  • Current order template:
    3500/22-AA-BB-CC
  • Interface type:
    01, standard TDI
  • I/O module:
    01, 10Base-T/100Base-TX Ethernet
  • Agency approval:
    01, CSA/NRTL/C Class I Division 2
  • Rack position:
    Slot 1 next to the power supplies
  • Host protocols:
    BN Host and BN TDI over Ethernet TCP/IP
  • Primary role:
    Rack interface and dynamic-data collection
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Ordering Code System Matching Installation

Product overview:

  • Rack interface plus steady-state and transient data collection
  • Autosensing 10Base-T/100Base-TX copper Ethernet
  • Standard TDI with CSA/NRTL/C Division 2 approval

3500/22M-01-01-01 links the rack to host software and collects waveform data from compatible M-series monitors.

Plan the rack upgrade sequence, network settings and dynamic-data channel license before installation.

Verified resources for Bently Nevada 3500/22M-01-01-01:

Additional technical data:

  • Typical power consumption: 10.5 watts
  • Front configuration connection: isolated USB-B
  • Maximum copper Ethernet segment: 100 m
  • Main module dimensions: 241.3 x 24.4 x 241.8 mm
  • Main module weight: 0.91 kg

Ordering structure:

  • AA 01 selects the standard Transient Data Interface
  • BB 01 selects 10Base-T/100Base-TX Ethernet I/O
  • CC 01 selects CSA/NRTL/C Class I Division 2
  • Dynamic-data channel capacity is enabled separately with a 3500/09 disk

Compatibility checklist:

  • Install the matching rear copper Ethernet I/O module
  • Verify compatibility with every M-series monitor in the rack
  • Use supported System 1 and 3500 software revisions
  • Confirm dynamic-data point licensing when continuous waveform capture is needed

Installation checks:

  • Remove any existing RIM front module and rear I/O before fitting the TDI pair
  • Insert the TDI in Slot 1
  • Apply the approved network-hardening configuration
  • Verify OK, TX/RX and configuration status indications
Description

3500/22M-01-01-01 is the standard Transient Data Interface for a Bently Nevada 3500 rack. It combines rack-interface functions with steady-state and transient dynamic-data collection and uses a 10Base-T/100Base-TX copper Ethernet I/O module.

The TDI occupies Slot 1 next to the power supplies and communicates with compatible 3500 M-series monitors, System 1 software and 3500 configuration tools. Confirm rack firmware, M-series compatibility, network security and dynamic-channel licensing before commissioning.

Alternative Names
3500/22M-01-01-01 3500 22M 01 01 01 3500-22M-01-01-01 Bently Nevada 3500/22M-01-01-01 Bentley Nevada 3500/22M-01-01-01 Bently Nevada 3500 22M 01 01 01 3500 System 3500/22M-01-01-01 3500/22M-01-01-01 Transient Data Interface
Technical notes
3500/22M-01-01-01 is not part of the critical machinery-protection path, but every rack requires one compatible TDI or RIM. Remove the old RIM I/O before installing a TDI I/O module.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is the role of 3500/22M-01-01-01?
It provides rack-interface communications and collects steady-state and transient waveform data from compatible 3500 monitors.
Which Ethernet interface is selected?
Option 01 specifies a 10Base-T/100Base-TX copper Ethernet I/O module with an RJ-45 connection.
Where is the TDI installed?
It always occupies Slot 1 immediately next to the rack power-supply positions.
Does the TDI perform the protection trip function?
No. It is outside the critical monitoring path and does not replace the independent alarm functions of the monitor modules.
Can a 3500/20 RIM be replaced directly?
Check M-series compatibility and remove both the RIM and its rear I/O before installing the TDI pair.
What software communicates with the module?
It supports 3500 configuration and data-acquisition tools and compatible System 1 condition-monitoring software.
Where is network and ordering information provided?
The Manuals tab links to an Apter-hosted 3500/22M technical document.
What details are needed for a quote?
Provide rack revision, monitor population, rear I/O requirement, approvals, channel-enabling needs and destination.
