TACH100-01 174652-01

/ 4.9
1001 reviews | Need a Specific Revision?
The Bently Nevada TACH100-01 174652-01 Standalone Digital Tachometer provides precise and reliable speed measurements for standalone or integrated monitoring applications.
Get a quick price for TACH100-01 174652-01
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for TACH100-01 174652-01

  • Manufacturer:
    Bently Nevada
  • Part Number:
    TACH100-01 174652-01
  • Product Family:
    3500 System
  • Inputs Signal:
    From any Bently Nevada Proximitor Sensor
  • Threshold:
    Automatic adjustment
  • Threshold:
    Automatic adjustment
  • Hysteresis:
    0.2 Vdc to 2.5Vdc, field adjustable
  • Events Per Turn:
    1 to 99, field-adjustable
  • Electrical Supply:
    110-230 Vac, 50-60 Hz. 1.5 Amp, SB fuse. 1.01 Watts nominal power consumption with 88888 displayed
  • Outputs Display Type:
    6-digit LED, 7 segments per digit. Digit height is 13.2 mm (0.52 in)
  • Measurement Range:
    1 to 999,999 rpm
  • Measurement Resolution:
    1 rpm
  • Measurement Accuracy:
    Accurate to within 0.015% of input speed displayed in RPM
  • Display Hysteresis:
    Input signal must change by 0.003% minimum to display a new output value
  • Proximitor Power:
    -24 Vdc at 20 mA maximum
  • Altitude:
    2000 m
  • Operating Temperature:
    0°C to +60°C (+32°F to +140°F)
  • Storage Temperature:
    -40°C to +85°C (-40°F to +185°F)
  • Relative Humidity:
    95% max, noncondensing
  • Weight:
    0.48 kg
  • Estimated shipping dimensions:
    14x16x7.5cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.
Description
The TACH100-01 174652-01 digital tachometer is designed for flexible industrial use, serving either as a stand-alone speed indicator or as a remote display for permanently installed monitoring systems. It is ideal for scenarios where the monitoring system is located remotely, such as in a control room, or where no permanent monitoring system is installed at the machine.

Equipped with its own power supply, the TACH100-01 174652-01 can provide -24 Vdc to a Proximitor sensor and also accept signals from externally powered Keyphasor Proximity Probes. Signals can be connected in parallel with an existing monitor rack or directly to the probe, offering versatile installation options.

The tachometer features a 6-digit LED display, capable of showing speeds from 1 to 999,999 rpm with a resolution of 1 rpm and accuracy within 0.015% of input speed. Thresholds adjust automatically, and hysteresis can be tuned from 0.2 to 2.5 Vdc, allowing precise customization of the measurement output.

Constructed to operate in harsh industrial environments, it supports temperatures from 0°C to 60°C, storage from -40°C to 85°C, relative humidity up to 95% non-condensing, and altitudes up to 2000 m. With its compact design, reliable Proximitor power, and flexible connectivity, the TACH100-01 174652-01 is an essential tool for both field and remote speed measurement applications.
Alternative Names
TACHI00-0I 174652-0I TACH1OO-O1 174652-O1 TACH100-01 17465Z-01 TACH10001 17465201 TACH100-01 174652-01
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is the TACH100-01 174652-01 measurement range?
The tachometer measures 1 to 999,999 rpm.
What is the TACH100-01 174652-01 measurement resolution?
The resolution is 1 rpm, providing precise speed readings.
How fast can you ship the TACH100-01 174652-01?
Most product are available for immediate shipment within 2-3 business days.
What is the TACH100-01 174652-01 electrical supply requirement?
110–230 Vac, 50–60 Hz, 1.5 Amp SB fuse, with 1.01 Watts nominal power when displaying “88888”.
