Bently Nevada 22810-00-14-10-02 is a 7200 8 mm M10 × 1 proximity probe with a 140 mm case, stainless-steel lead armor, a 1.0 m integral lead and miniature male coaxial connector.
In Stock
Get a quick price for 22810-00-14-10-02
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 22810-00-14-10-02

  • Manufacturer:
    Bently Nevada
  • Part Number:
    22810-00-14-10-02
  • Product Family:
    7200 Proximity Transducer Systems
  • Product Type:
    8 mm Standard Mount Probe
  • Stock:
    1
  • Case thread:
    M10 × 1
  • Overall case length:
    140 mm
  • Unthreaded length:
    0 mm
  • Integral cable length:
    1.0 m
  • Lead armor:
    Stainless-steel lead armor
  • Weight:
    0.14 kg
  • Estimated shipping dimensions:
    1.8x1.5x97cm
  • Tariff Code:
    Please confirm the destination before shipping
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals 140 mm Case Cable Protection 7200 Loop Product Applications

Features:

  • Extended metric case: The 14 option gives this M10 × 1 probe a 140 mm case.
  • Protected lead: The integral 1.0 m coaxial cable has stainless-steel armor.
  • Standard 8 mm tip: The probe uses the 7200 standard-mount 8 mm design.
The long 140 mm case is a physical mounting choice, separate from the lead-length code.

Its 00 option selects no unthreaded section, and the 02 option supplies a miniature male coaxial connector.

The probe works within a 7200 transducer path completed by an extension cable and Proximitor.

Apter Power can provide technical documentation, a quotation and 7200 configuration support for the Bently Nevada 22810-00-14-10-02 8 mm Standard Mount Probe.
Bently Nevada 22810-00-14-10-02 8 mm Standard Mount Probe Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Overall case: The 14 metric option specifies 140 mm.
  • Thread form: This 22810 probe uses M10 × 1 threads.
  • Tip section: The 00 option selects 0 mm unthreaded length.
  • Sensing tip: The standard probe face is 8 mm in diameter.
  • Lead length: The 10 option supplies 1.0 m of integral cable.
  • Armor: Stainless steel covers the lead in the 22810 family.
  • Termination: The 02 option uses a miniature male coaxial connector.
  • Tip junction: Cable LoC is part of the improved 8 mm 7200 design.
  • Five-metre path: A 1.0 m lead pairs with a 4.0 m extension.
  • Proximitor choice: The 18745-03 conditions the five-metre arrangement.
  • Noncontact tip: The probe senses the distance to the shaft target.
  • Output boundary: The monitor receives the signal after Proximitor conditioning.
  • Radial shaft motion: A complete 7200 loop can monitor vibration.
  • Thrust position: The assembled system can observe axial shaft movement.
  • Shaft radial position: The full loop can indicate average position.
  • Eccentricity: The 7200 measurement system can assess rotor bow.
Description
A 140 mm overall case distinguishes 22810-00-14-10-02 from shorter metric 7200 probes. This standard 8 mm proximity probe uses an M10 × 1 threaded case and stainless-steel armor around the integral lead.

The order code specifies 0 mm unthreaded length and a 1.0 m integral cable ending in a miniature male coaxial connector. Those physical choices give 22810-00-14-10-02 a longer case without changing the one-metre lead option.

Installed as part of a 7200 probe, extension-cable and Proximitor loop, 22810-00-14-10-02 senses the target gap at its 8 mm tip. The rest of the transducer system conditions the signal for shaft-position or vibration monitoring.
Alternative Names
Bently Nevada 22810-00-14-10-02 22810 00 14 10 02 22810/00/14/10/02 2281000141002
Technical notes
The 140 mm case of 22810-00-14-10-02 is an M10 × 1 probe configuration, not the M8 × 1 configuration subject to the 7200 table’s 100 mm maximum-case footnote. Mounting depth and access must suit the actual 140 mm case. Its 1.0 m integral lead is a separate electrical-length choice and does not shorten with the case.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Is 22810-00-14-10-02 the longer M10 probe case when a 100 mm case will not reach the mounting position?
Yes. The 14 case option specifies 140 mm overall length while retaining M10 × 1 threads.
Does 22810-00-14-10-02 add an unthreaded nose ahead of its 140 mm case?
No. Its 00 unthreaded-length option is 0 mm; the longer overall case is not an extra unthreaded extension.
Is the 1 m lead on 22810-00-14-10-02 supplied with stainless-steel armor?
Yes. The 22810 family uses stainless-steel lead armor and this order code selects a 1.0 m integral lead.
Can 22810-00-14-10-02 be paired with the 18745-03 five-metre Proximitor?
Yes, in the 7200 five-metre arrangement its 1.0 m integral lead combines with a 4.0 m extension cable.
Does the 140 mm case of 22810-00-14-10-02 change the specified electrical lead length?
No. The 14 option is case length; the separate 10 option specifies the 1.0 m integral cable.
Will 22810-00-14-10-02 alone produce the system’s 200 mV/mil output?
No. That scale factor belongs to the complete calibrated 7200 probe, extension cable and Proximitor system, not the isolated probe.
