        Delixi CDC6-150 220V
        Delixi CDC6-150 220V
        Delixi CDC6-150 220V
        Delixi CDC6-150 220V
        Delixi CDC6-150 220V
        Delixi CDC6-150 220V
        Ask our team:
        • Phone: +86 181 0690 9650
        • E-Mail info@apterpower.com

        CDC6-150 220V

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        DELIXI Electric CDC6-150 220V is a CDC6 AC contactor with a 150 A AC-3 rating and a 220 V AC control coil selection.
        In Stock
        Ships by Wednesday, September 30
        Fast Shipping Available
        Get a quick price for CDC6-150 220V
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for CDC6-150 220V

        • Manufacturer:
          DELIXI
        • Part Number:
          CDC6-150 220V
        • Product Family:
          DELIXI
        • Product Type:
          AC Contactor
        • Stock:
          1
        • Control coil selection:
          220 V AC; 50 Hz, or 50/60 Hz for documented 115–225 AF versions
        • Rated operational current, AC-3:
          150 A
        • Rated operational current, AC-1:
          200 A
        • Rated insulation voltage:
          1000 V
        • AC-3 motor power at 220/240 V:
          40 kW
        • AC-3 motor power at 380/400 V:
          75 kW
        • AC-3 motor power at 415/440 V:
          80 kW
        • AC-3 motor power at 660/690 V:
          100 kW
        • Allowable pickup range:
          85–110% of rated control voltage Us
        • Dropout range:
          20–75% of rated control voltage Us
        • Maximum operating rate:
          600 operations per hour
        • Main conductor capacity:
          One 120 mm² copper conductor
        • Copper-bar capacity:
          Two 25 × 3 mm bars
        • Tariff Code:
          8536490090
        • Country of origin:
          China
        • Place of shipment:
          Xiamen,Fujian,China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Main Circuit Motor Ratings Coil and Wiring Application
        • The CDC6-150 contactor is rated 150 A for AC-3 duty and 200 A for AC-1 duty
        • The requested coil selection uses 220 V AC control power
        • The documented rated insulation voltage is 1000 V

        CDC6-150 220V is a DELIXI Electric CDC6 AC contactor configured around a 150 A frame and a 220 V AC control coil.

        The official CDC6 data identifies 150 A AC-3 duty, 200 A AC-1 duty, a 1000 V insulation rating, and motor ratings from 40 kW at 220/240 V to 100 kW at 660/690 V.

        Before installation or replacement, verify the complete nameplate order code, auxiliary-contact arrangement, coil frequency, main-circuit voltage, utilization category, conductor capacity, protection, and mechanical interlock requirements.

        Availability, condition, price, and shipping time for CDC6-150 220V are confirmed during quotation.

        DELIXI Electric CDC6-150 220V AC Contactor Manuals, Datasheets, Links

        Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

        • CDC6-150 is rated 150 amperes for AC-3 operational current
        • CDC6-150 is rated 200 amperes for AC-1 operational current
        • The CDC6 platform has a documented rated insulation voltage of 1000 volts
        • The AC-3 motor rating is 40 kilowatts at 220/240 volts
        • The AC-3 motor rating is 75 kilowatts at 380/400 volts
        • The AC-3 motor rating is 80 kilowatts at 415/440 volts and 100 kilowatts at 660/690 volts
        • The 220-volt control-coil option is documented for 50 hertz and for 50/60 hertz on 115–225 AF contactors
        • The operating range is 85 to 110 percent of rated control voltage and dropout is 20 to 75 percent
        • CDC6-150 accepts one 120-square-millimetre main conductor or two 25-by-3-millimetre copper bars
        • Switching three-phase motors up to the documented AC-3 rating
        • Contactor duty in industrial motor-control panels using a 220 V AC control circuit
        • High-current load switching where the application is engineered for CDC6-150 AC-1 or AC-3 duty
        Description
        CDC6-150 220V is a DELIXI Electric CDC6 AC contactor with a 150 A AC-3 rating and a 220 V AC control-coil selection.

        The contactor is documented for 200 A AC-1 duty, 1000 V rated insulation, and AC-3 motor ratings of 40 kW at 220/240 V, 75 kW at 380/400 V, 80 kW at 415/440 V, and 100 kW at 660/690 V.

        Before installation or replacement, confirm the full nameplate order code, auxiliary contacts, coil frequency, main voltage, load category, protection, conductor size, interlock accessories, and panel clearances.
        Alternative Names
        CDC6-150 220V CDC6 150 220V CDC6-150-220V DELIXI CDC6-150 220V DELIXI Electric CDC6-150 220V
        Technical notes
        CDC6-150 220V describes the 150 A contactor and 220 V coil selection, but DELIXI ordering syntax also encodes auxiliary contacts, coil type, frequency, and special options; confirm the complete nameplate code before ordering.
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        What does the DELIXI Electric CDC6-150 220V designation identify?
        It identifies a CDC6-series AC contactor with a 150 A AC-3 rating and a 220 V AC control-coil selection.
        How do the AC-3 and AC-1 ratings differ for DELIXI Electric CDC6-150 220V?
        DELIXI Electric CDC6-150 220V is rated at 150 A for AC-3 motor-switching duty and 200 A for AC-1 resistive or slightly inductive-load duty.
        Which motor capacity can DELIXI Electric CDC6-150 220V control at 380/400 V?
        The documented AC-3 motor rating for DELIXI Electric CDC6-150 220V is 75 kW at 380/400 V.
        Within what control-voltage range will DELIXI Electric CDC6-150 220V operate?
        The coil operates at 85% to 110% of its rated control voltage and releases when the voltage falls within the documented 20% to 75% dropout range.
        Why should the nameplate be checked before ordering DELIXI Electric CDC6-150 220V?
        The stated model identifies the 150 A contactor and 220 V coil selection, but the complete DELIXI order code can also specify auxiliary contacts, coil type, frequency, and special options.
        What should be confirmed before installing DELIXI Electric CDC6-150 220V?
        Confirm the complete order code, coil frequency, auxiliary contacts, main-circuit voltage, utilization category, motor load, protective devices, conductor capacity, interlocks, and installation clearances.
        What should be checked before installing DELIXI Electric CDC6-150 220V?
        Confirm the full order code, coil frequency, auxiliary contacts, main voltage, utilization category, motor load, protection, conductors, interlock, and clearances.
