  • Lifecycle status

    Active / Available from OEM
    Apter Power supports sourcing and configuration review for this exact DeltaV M-series assembly.

CE4032S1T2B8

/ 4.9
1001 reviews | Need a Specific Revision?
Emerson CE4032S1T2B8 is a DeltaV M-series Series 2 Plus redundant 32-channel 24 V DC high-side discrete output assembly with a redundant 40-pin mass termination block.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for CE4032S1T2B8
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for CE4032S1T2B8

  • Manufacturer:
    Emerson
  • Part Number:
    CE4032S1T2B8
  • Product Family:
    DeltaV
  • Product Type:
    DeltaV M-Series Series 2 Plus Redundant 32-Channel 24 V DC High-Side Discrete Output Assembly with 4
  • Stock:
    1
  • Series:
    DeltaV M-series
  • Card Generation:
    Series 2 Plus
  • Channel Count:
    32
  • Output Type:
    24 V DC high-side discrete output
  • Redundancy:
    Redundant
  • Termination:
    40-pin mass I/O termination block
  • Assembly Scope:
    I/O card group and termination hardware
  • Ordering Code:
    CE4032S1T2B8
  • Tariff Code:
    Please confirm the destination before shipping
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Applications Redundancy Compatibility Commissioning

Features:

  • Full CE4032S1T2B8 ordering identity marks the archived M-series configuration.
  • Series 2 Plus redundant output architecture distinguishes it from simplex assemblies.
  • The redundant 40-pin mass-termination scope keeps card and terminal hardware selection aligned.
The complete CE4032S1T2B8 code is the receiving anchor; a shortened family description cannot establish the ordered configuration.

Its redundant Series 2 Plus architecture is the main changeout boundary, so the installed carrier and both hardware paths must agree before work begins.

The 40-pin mass-termination arrangement links the assembly to the cabinet wiring plan; a simplex block is not an automatic substitute.

Apter Power can support sourcing and configuration review for the active Emerson CE4032S1T2B8 DeltaV M-Series redundant output assembly with 40-pin termination.
Emerson CE4032S1T2B8 DeltaV M-Series Series 2 Plus Redundant 32-Channel 24 V DC High-Side Discrete Output Assembly with 4 Manuals,Datasheets,Link

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Use CE4032S1T2B8 in the documented DeltaV M-series redundant Series 2 Plus output architecture.
  • Apply it where a redundant 40-pin mass-termination arrangement is already defined by the cabinet design.
  • Control maintenance spares by the complete order code so card and terminal hardware remain one configuration.
  • Plan changeouts around the existing M-series carrier and approved 24 V DC high-side output wiring.
  • Treat CE4032S1T2B8 as a redundant assembly; do not reduce the order to a single card description.
  • Reconcile both installed paths and carrier positions with the approved site drawing before removal.
  • Keep the redundant 40-pin mass-termination hardware paired with the intended Series 2 Plus architecture.
  • Stop the changeout if the cabinet presents a simplex termination block or a different carrier arrangement.
  • The documented platform boundary for CE4032S1T2B8 is DeltaV M-series Traditional I/O.
  • A similar 32-channel description does not prove compatibility with S-series or later VE-prefixed orders.
  • Match the complete code, redundant configuration and termination arrangement before accepting a substitute.
  • Escalate any carrier, connector or field-wiring difference for an approved engineering review.
  • Confirm 24 V DC field supply polarity and each high-side output assignment before energizing loads.
  • Compare the 40-pin mass-termination channel map with the site drawing and cabinet labels.
  • Run the site-approved redundancy test across both paths after hardware and wiring checks pass.
  • Record channel behavior and diagnostics before returning the controlled process to normal service.
Description
CE4032S1T2B8 is the DeltaV M-series Series 2 Plus redundant 32-channel 24 V DC high-side discrete output assembly supplied with a redundant 40-pin mass termination block.

In a maintenance or expansion project, CE4032S1T2B8 keeps the I/O card and redundant mass-termination hardware aligned as one ordering configuration. This reduces ambiguity at receiving and changeout, but the installed M-series carrier, 24 V DC field supply, load type and terminal wiring must still be verified before installation.

Use CE4032S1T2B8 for the documented M-series redundant Series 2 Plus architecture only. A simplex termination block or an S-series/VE-prefixed assembly is not automatically equivalent; stop the substitution until the complete ordering code, carrier position and site drawing agree.
Alternative Names
Emerson CE4032S1T2B8 DeltaV CE4032S1T2B8
Technical notes
CE4032S1T2B8 is the archived M-series Series 2 Plus order for redundant 32-channel, 24 V DC high-side output service with a redundant 40-pin mass termination block. A simplex block or an SE/VE-prefixed assembly is not automatically equivalent; stop the changeout until the installed carrier, terminal arrangement and complete code agree.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How should a receiving inspector identify CE4032S1T2B8?
Match the complete ordering code and verify the package identifies an M-series Series 2 Plus redundant 32-channel 24 V DC high-side output assembly with redundant 40-pin mass termination hardware.
Can a maintenance team replace a simplex output assembly with CE4032S1T2B8?
No. Confirm the installed carrier and redundant architecture first. A simplex termination block is a different configuration and should not be accepted without an approved system-engineering review.
What field wiring must an installer verify for CE4032S1T2B8?
Reconcile the site drawing with the redundant 40-pin mass termination arrangement, 24 V DC field supply, high-side output polarity and each channel assignment before connecting loads.
What should commissioning confirm after installing CE4032S1T2B8?
Verify both redundant paths according to the site test procedure, confirm channel mapping and output behavior, record any diagnostics, and return the process to service only after the approved functional test passes.
Which output loads are appropriate for CE4032S1T2B8?
Use it only for compatible 24 V DC high-side discrete output loads. Compare load current, inrush, suppression, field supply and cabinet wiring with the approved project design before energizing.
Can an SE- or VE-prefixed assembly be ordered as CE4032S1T2B8?
Not automatically. The prefix identifies a different documented series or ordering generation. Accept a substitute only when Emerson documentation and the installed hardware configuration prove the complete assembly is equivalent.
