PR9376-010-011

/ 4.9
1001 reviews | Need a Specific Revision?
Emerson PR9376-010-011 is a non-contact Hall effect speed and key sensor with protective hose, 124 mm sensor length, 5 m cable and open cable end.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for PR9376-010-011
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for PR9376-010-011

  • Manufacturer:
    Emerson
  • Part Number:
    PR9376-010-011
  • Product Family:
    Epro
  • Product Type:
    Hall Effect Speed and Key Sensor
  • Stock:
    1
  • Protective hose:
    Yes
  • Total sensor length:
    124 mm
  • Total cable length:
    5 m
  • Trigger frequency range:
    Up to 12 kHz
  • Output:
    One AC period per revolution or tooth
  • Rise and fall time:
    1 µs
  • Air gap:
    1 mm for module 1; 1.5 mm for module 2 or larger
  • Supply:
    10 to 30 VDC
  • Current draw:
    25 mA at 24 VDC, unloaded
  • Permissible load:
    400 Ω
  • Target material:
    Soft magnetic iron or steel
  • Operating temperature:
    -25 to +100°C
  • Protection class:
    IP67
  • Sensor body envelope:
    117.5 mm overall by 14 mm body diameter for /010 orientation-mark version
  • Tariff Code:
    9031809090
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Target Setup Electrical Match Pulse Quality Application
  • Align the orientation mark with the passing target geometry
  • Set air gap with runout and thermal movement included
  • Match the powered pulse output to the receiving speed or key input

Emerson PR9376-010-011 is a non-contact Hall effect sensor for speed or key-phase measurement on critical rotating machinery.

The official PR9376/010-011 order code specifies the 124 mm orientation-mark sensor with protective hose, no intermediate plug, 5 m total cable and open cable end.

Before installation or replacement, verify target material and tooth geometry, sensor orientation mark, air gap, supply and load, cable termination, machine speed and receiving-input compatibility.

Availability, condition, price, and shipping time for PR9376-010-011 are confirmed during quotation.

Emerson PR9376-010-011 Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Use soft-magnetic iron or steel target material
  • Keep tooth geometry within the published trigger limits
  • Provide mechanical clearance for runout and growth
  • Supply the sensor from 10 to 30 VDC
  • Keep the receiving load within the documented limit
  • Terminate the 5 m open cable and shield to the approved channel drawing
  • Check one clean pulse per intended tooth or revolution
  • Use the orientation mark to obtain the correct switching geometry
  • Investigate missed or double pulses before enabling overspeed or phase logic
  • Turbine, compressor, pump or fan shaft-speed measurement
  • Key-phase or once-per-revolution reference generation
  • Gear-tooth pulse sensing for condition monitoring and machinery protection
Description
Emerson PR9376-010-011 is a non-contact Hall effect sensor for speed or key-phase measurement on critical rotating machinery.

The official PR9376/010-011 order code specifies the 124 mm orientation-mark sensor with protective hose, no intermediate plug, 5 m total cable and open cable end.

Before installation or replacement, verify target material and tooth geometry, sensor orientation mark, air gap, supply and load, cable termination, machine speed and receiving-input compatibility.
Alternative Names
PR9376-010-011 PR9376/010-011 PR 9376-010-011 PR 9376/010-011 Emerson PR9376-010-011 Emerson PR9376/010-011 Emerson Epro PR9376-010-011 Emerson Epro PR9376/010-011 Epro PR9376-010-011 Epro PR9376/010-011
Technical notes
PR9376-010-011 requires a soft-magnetic iron or steel target and correct orientation-mark alignment. Verify air gap, supply polarity, load and open-end wiring before applying speed or key-phase logic.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Can Emerson PR9376-010-011 replace an eddy current proximity probe?
No direct replacement should be assumed. It is a Hall effect pulse sensor for speed or key measurement and requires a compatible magnetic target, DC supply and pulse input.
What must be confirmed about the trigger target for Emerson PR9376-010-011?
Use soft-magnetic iron or steel with suitable tooth width, spacing and edge geometry; confirm the target can be sensed throughout runout and machine movement.
Why does the orientation mark matter on Emerson PR9376-010-011?
The internal Hall elements must be aligned to the passing tooth direction. Incorrect rotational orientation can weaken or distort the pulse.
How should the air gap be chosen for Emerson PR9376-010-011?
Set it from the documented tooth module and allow for runout, thermal growth and bracket movement so the target never strikes the sensor or leaves the reliable switching zone.
Can the 5 m open-ended cable of Emerson PR9376-010-011 be connected to any speed input?
Only when the input accepts the sensor's powered pulse output and the supply, load, common, shield and switching thresholds match the receiving equipment.
What should be checked when Emerson PR9376-010-011 produces no pulses?
Check supply voltage and polarity, target material, air gap, orientation mark, open-end wire termination, load, cable continuity and whether the shaft actually crosses the target threshold.
How should Emerson PR9376-010-011 be tested after replacement?
Turn the machine slowly to confirm one clean transition per intended tooth, verify speed and phase direction, then compare the pulse train at operating speed while monitoring missed or double triggers.
