PR6423/000-000 CON011

/ 4.9
1001 reviews | Need a Specific Revision?
The Emerson PR6423/000-000 CON011 is a high-precision 8mm eddy current displacement sensor, specifically designed for the detection of shaft vibration, displacement and eccentricity in critical equipment.
Get a quick price for PR6423/000-000 CON011
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for PR6423/000-000 CON011

  • Manufacturer:
    Emerson
  • Part Number:
    PR6423/000-000 CON011
  • Product Family:
    Epro
  • Linear Measurement Range:
    2 mm (80 mils)
  • Initial Air Gap:
    0.5 mm (20 mils)
  • Incremental Scale Factor (ISF):
    ISO: 8 V/mm (203.2 mV/mil) ± 5% @ temperature range 0 to 45°C (+32 to +113°F)
  • Deviation from best fit straight line (DSL):
    ± 0.025 mm (± 1 mil) @ temperature range 0 to 45°C (+32 to +113°F)
  • Minimum Shaft Diameter:
    25 mm (0.79”)
  • Target Material (Ferromagnetic Steel):
    42CrMo4 (AISI/SAE 4140) Standard Other (On Request)
  • Protection Class:
    IP66, IEC 60529
  • Operating Temperature Range:
    Sensor incl. 1m Cable: -35 to +180°C (-31 to 356°F); Cable & Connector: -35 to +150°C (-31 to 302°F)
  • Material:
    Sensor Tip (PEEK Polyether Ether Ketone), Case (Stainless Steel) Cable (PTFE Polytetrafluoroethylene), Connector (Brass, nickel-plated)
  • Tip Diameter:
    8mm
  • Case Threads:
    M10x1
  • Armored Cable:
    No
  • Weight:
    0.58 kg
  • Estimated shipping dimensions:
    11.5x7.6x6.4cm
  • Tariff Code:
    8537101190
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.
Description
The Emerson PR6423/000-000 CON011 8mm eddy current displacement sensor is a high-precision sensing device for monitoring the condition of rotating machinery, specifically designed for the detection of shaft vibration, displacement and eccentricity in critical equipment. Its 8mm probe is made of high-temperature resistant PEEK material, combined with a stainless steel housing and PTFE cable structure, enabling it to maintain stable measurement performance in harsh working conditions up to 180°C.

This sensor offers a linear measurement range of 2mm, features a high-precision increment coefficient of 8V /mm, and ensures excellent linear error control of ±0.025mm. Whether in steam turbines, compressors or large motor applications, it can achieve precise and reliable data output, meeting the requirements of long-term continuous monitoring. The standard target material is 42CrMo4 steel, ensuring a stable and consistent response of the sensor in the actual installation environment.

PR6423/000-000 CON011 features an IP66 protection rating and uses M10x1 threads for easy installation, making it suitable for rapid deployment in various industrial scenarios. Its robust structure and wide-temperature working capacity make it an indispensable key component in predictive maintenance systems, providing comprehensive protection for the safe operation of equipment.
Alternative Names
PR6423/OOO-OOO CONO11 PR6423/000-000 C0N011 PR6423/000-000 CON0II PR6423/000000 CON011 PR6423/OOOOOO CONO11 PR6423/000000 C0N011 PR6423/000000 CON0II PR6423/000-000 CON011
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Does the PR6423/000-000 CON011 come with a warranty?
Yes, the PR6423/000-000 CON011 includes a free 1-year Apter Power warranty.
What is the linear measurement range of this sensor?
The linear measurement range is 2 mm (80 mils).
What is the recommended initial air gap when installing the sensor?
The recommended initial air gap is 0.5 mm (20 mils).
What is its output proportional coefficient (ISF)?
The ISF is 8 V/mm (±5%), suitable for the temperature range of 0-45°C.
