PR9268/201-000

/ 4.9
1001 reviews | Need a Specific Revision?
Emerson PR9268/201-000 is a vertical absolute-vibration transducer rated to 100°C with a 5 m armored cable and HARTING connector.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for PR9268/201-000
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for PR9268/201-000

  • Manufacturer:
    Emerson
  • Part Number:
    PR9268/201-000
  • Product Family:
    Epro
  • Product Type:
    PR 9268 Absolute Vibration Transducer
  • Stock:
    1
  • Sensor Family:
    PR 9268/20x
  • Measurement Direction:
    Vertical
  • Temperature Class:
    Up to 100°C
  • Cable Construction:
    Armored
  • Cable Length:
    5 m
  • Cable End:
    HARTING
  • Mechanical Conversion:
    Electro-dynamic
  • Linearity Error:
    Less than 2%
  • Continuous Acceleration:
    10 g peak-to-peak in measuring direction
  • Short-Time Acceleration:
    20 g peak-to-peak in measuring direction
  • Transverse Acceleration:
    2 g peak-to-peak
  • Storage:
    -40 to +100°C without packing
  • Relative Humidity:
    0 to 100%, non-condensing in housing and plug
  • Tariff Code:
    9031809090
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Applications Monitoring Performance Certifications

Features:

  • Measures absolute casing vibration in the vertical direction.
  • Uses a 5 m armored connection cable with HARTING termination.
  • Operates on an electro-dynamic seismic measurement principle.
The current ordering configuration is PR9268/201-000, the PR 9268 Absolute Vibration Transducer documented for AMS 6500 Machinery Health.

In the intended system role, a suspended moving coil generates a voltage proportional to vibration velocity above resonance. The instrument is used with a compatible machinery-monitoring or protection input.

For selection and commissioning, mount the body on a flat rigid surface in the vertical orientation and protect it from shock. Verify connector pinout, polarity, cable shielding and channel sensitivity before enabling trips.

Availability is subject to Apter Power inventory and sourcing confirmation.
Verified resources for Emerson PR9268/201-000:Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Measures vertical bearing-housing vibration on rotating machinery, for its documented operating duty.
  • Feeds velocity-proportional signals to a compatible protection channel, through the intended receiving-system interface.
  • Supports condition monitoring where absolute casing motion is required, in the configured and commissioned installation.
  • The moving-coil output represents vibration velocity above the transducer resonance, within the documented monitoring function.
  • A connected monitor converts the signal into displayed value, alarm and trip decisions, for the configured channel or system display.
  • Channel polarity determines the reported direction of casing motion, during commissioning and routine operation.
  • Linearity error of sensitivity is specified below two percent, within the documented measurement response.
  • The sensing mechanism tolerates the documented continuous and short-duration acceleration levels, across the stated usable operating window.
  • A rigid mounting surface prevents structural motion from contaminating the measurement, when the specified setup conditions are maintained.
  • Hazardous-area use depends on the exact product marking and approved associated equipment, for the exact supplied configuration.
  • Installation follows the applicable intrinsic-safety and electrical-installation standards in the guide, under the approved installation conditions.
  • Cable, connector and ambient conditions must stay within the certified entity parameters, before any certified service is claimed.
Description
PR9268/201-000 selects the vertical PR 9268/20x transducer, a 5 m armored cable and the HARTING termination. The housing measures absolute vibration by the seismic principle.

A suspended moving coil generates a voltage proportional to vibration velocity above resonance. The instrument is used with a compatible machinery-monitoring or protection input.

Mount the body on a flat rigid surface in the vertical orientation and protect it from shock. Verify connector pinout, polarity, cable shielding and channel sensitivity before enabling trips.
Alternative Names
PR9268/201-000 Emerson PR9268/201-000 PR9268 201 000 PR9268-201-000 PR9268201000 Emerson PR 9268 Absolute Vibration Transducer Emerson AMS 6500 Machinery Health PR9268/201-000 PR9268/201-000 PR 9268 Absolute Vibration Transducer
Technical notes
Do not drop the transducer or mount it on a flexible bracket; internal damage or structural resonance can produce unsafe vibration readings.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Which orientation is built into PR9268/201-000?
The /20x selection is the official vertical measurement version for service up to 100°C.
What cable assembly belongs to PR9268/201-000?
The code selects a 5 m armored cable terminated with the HARTING connector.
What kind of vibration does PR9268/201-000 measure?
It measures absolute casing vibration and produces a signal proportional to vibration velocity above resonance.
How should a sourcing inquiry identify PR9268/201-000?
Provide the exact /201-000 code, connector photo, required certification, quantity and destination.
Is a horizontal PR 9268 transducer interchangeable with PR9268/201-000?
No automatic interchange is valid because the seismic mass and mounting direction are configuration dependent.
What manual governs installation of PR9268/201-000?
Use Emerson installation guide MHM-97479 and the receiving monitor manual for pinout and channel setup.
