Emerson PR6423/00R-010 is a reverse-mount PR 6423 8 mm eddy-current sensor with a 5 m cable, fitted adapter plug and LEMO end for non-contact shaft measurement.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for PR6423/00R-010
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for PR6423/00R-010

  • Manufacturer:
    Emerson
  • Part Number:
    PR6423/00R-010
  • Product Family:
    Epro
  • Product Type:
    PR 6423 8 mm Eddy-Current Sensor
  • Stock:
    1
  • Probe Family:
    PR 6423
  • Sensor Head Diameter:
    8 mm
  • Mounting:
    Reverse mount
  • Armored Cable:
    Without
  • Adapter Plug:
    With
  • Total Cable Length:
    5 m
  • Cable End:
    LEMO
  • Linear Measuring Range:
    2 mm
  • Nominal Sensitivity:
    8 V/mm
  • Maximum Fixing Torque:
    15 Nm
  • Minimum Target Area:
    3 mm
  • Minimum Shaft Diameter:
    28 mm
  • Maximum Axial Tilt:
    Less than 2°
  • Tariff Code:
    9031809090
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Applications Compatibility Environment Protection

Features:

  • Uses the 8 mm PR 6423 probe family with a 5 m cable, fitted adapter plug and LEMO end.
  • Provides a 2 mm linear measuring range through a 5 m chain with an adapter plug.
  • Selects reverse mounting with 5 m total cable and LEMO termination.
The current ordering configuration is PR6423/00R-010, the PR 6423 8 mm Eddy-Current Sensor documented for AMS 6500 Machinery Health.

In the intended system role, the probe forms a calibrated eddy-current chain with an approved converter for non-contact measurement of shaft displacement, vibration or speed.

For selection and commissioning, match the converter, target material, total cable, termination and reverse-mount geometry before installation. Set the initial gap only after the full measuring chain is assembled.

Availability is subject to Apter Power inventory and sourcing confirmation.
Verified resources for Emerson PR6423/00R-010:Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Measures radial shaft vibration in a chain configured with a 5 m cable, fitted adapter plug and LEMO end, for its documented operating duty.
  • Tracks axial position changes through the 5 m probe-to-converter path with an adapter plug, through the intended receiving-system interface.
  • Provides dynamic gap information through the 5 m lead and LEMO termination to the monitoring electronics, in the configured and commissioned installation.
  • The measuring chain must use a converter calibrated for the PR 6423 sensor family, for the documented host or measurement platform.
  • Target material influences scale and must match the converter calibration, before an existing connection or channel is reused.
  • The LEMO interface and adapter arrangement must match the extension connection, so the configured interface remains compatible in service.
  • Probe and first-cable temperature limits follow the official 8 mm sensor data, under the specified installation conditions.
  • The connection joint must remain sealed and mechanically protected, as part of the installed environmental design.
  • Dry, clean handling prevents contamination of the precision connector contacts, during the final site-suitability review.
  • Static gap voltage provides a practical check of probe installation and target clearance, within the documented protection design.
  • Signal instability can indicate loose mounting, cable damage or an incorrect target, supporting fault isolation before corrective work begins.
  • Protection trips must stay inhibited until the complete measuring chain has passed a loop test, until the complete circuit passes its functional test.
Description
PR6423/00R-010 is the reverse-mount version of the PR 6423 8 mm sensor family. Its suffix selects a 5 m cable, fitted adapter plug and LEMO end.

The probe forms a calibrated eddy-current chain with an approved converter for non-contact measurement of shaft displacement, vibration or speed.

Match the converter, target material, total cable, termination and reverse-mount geometry before installation. Set the initial gap only after the full measuring chain is assembled.
Alternative Names
PR6423/00R-010 Emerson PR6423/00R-010 PR6423 00R 010 PR6423-00R-010 PR642300R010 Emerson PR 6423 8 mm Eddy-Current Sensor Emerson AMS 6500 Machinery Health PR6423/00R-010 PR6423/00R-010 PR 6423 8 mm Eddy-Current Sensor
Technical notes
Insulate and seal the adapter joint after connection; moisture or a mismatched extension can corrupt the gap signal.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What detachable connection hardware is supplied with PR6423/00R-010?
It uses a fitted adapter plug and LEMO cable end on the documented 5 m reverse-mount sensor lead.
How should the adapter joint on PR6423/00R-010 be protected after mating?
Keep the joint clean, dry, electrically insulated, sealed against moisture and relieved from cable strain.
Why does PR6423/00R-010 suit installations requiring probe-side disconnection?
Its adapter-plug arrangement permits a separable connection while the approved converter-side wiring remains installed.
Which photographs distinguish PR6423/00R-010 during an availability check?
Provide the probe label, adapter plug, LEMO end, converter label, cable condition, required quantity and destination.
Which connection details determine whether PR6423/00R-010 is compatible with an installed measuring chain?
The fitted adapter plug, LEMO end, total calibrated cable length, approved converter input and target material must all match the existing chain.
What commercial details should an inquiry for PR6423/00R-010 include?
State the complete suffix, required condition, whether the adapter assembly must be included, quantity, destination and requested delivery date.
