PR6423-010-000

/ 4.9
1001 reviews | Need a Specific Revision?
Emerson PR6423-010-000 is an 8 mm M10×1 armored eddy current sensor with a 25 mm sleeve and 4 m LEMO cable.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for PR6423-010-000
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for PR6423-010-000

  • Manufacturer:
    Emerson
  • Part Number:
    PR6423-010-000
  • Product Family:
    Epro
  • Product Type:
    8 mm Eddy Current Sensor
  • Stock:
    1
  • Case Thread:
    M10×1
  • Armored Cable:
    Yes
  • Sleeve Length:
    25 mm
  • Total Sensor Length:
    34 mm
  • Adapter Plug:
    With adapter plug
  • Total Cable Length:
    4.0 m
  • Cable End:
    LEMO connector
  • Linear Measuring Range:
    2 mm
  • Initial Air Gap:
    0.5 mm
  • Incremental Scale Factor:
    8 V/mm ±5% at 0...45 °C
  • Linearity:
    ±0.025 mm at 0...45 °C
  • Minimum Shaft Diameter:
    25 mm
  • Reference Target:
    42CrMo4 / AISI 4140 steel
  • Protection Class:
    IP66
  • Sensor and 1 m Cable Temperature:
    −35...180 °C continuous; up to 200 °C short-term
  • Cable and Connector Temperature:
    0...175 °C continuous; up to 200 °C short-term
  • Tariff Code:
    9026801000
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Mounting Cabling Environment Application
  • 8 mm probe geometry supports non-contact shaft displacement and vibration measurement
  • Armored cable construction protects the fixed probe lead in mechanically exposed routes
  • The ordering code defines a compact M10×1 mounting and matched converter connection

Emerson PR6423-010-000 is the commercial hyphen form of the official PR6423/010-000 ordering configuration.

Its code identifies the probe armor, sleeve, adapter, total cable length, and connector needed to reproduce the installed measuring chain.

Confirm the converter pairing, target material, shaft diameter, probe gap, mounting, armor path, temperature, and approval conditions before commissioning.

Availability, condition, price, and shipping time for PR6423-010-000 are confirmed during quotation.

Emerson PR6423-010-000 8 mm Eddy Current Sensor Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Use a stiff, vibration-free holder with a clean M10×1 mounting thread
  • After final gap adjustment, leave at least two threads free toward the sensor head
  • Tighten the PR6423 fixing nuts to no more than 15 N·m
  • Do not shorten the PR6423 sensor cable or extension cable; coil excess cable with a diameter of at least 100 mm
  • Maintain a minimum bending radius of 35 mm for the armored cable and metal protection tube
  • Cover the connected LEMO adapter plug completely with the supplied shrink sleeve and do not turn the LEMO connectors when disconnecting them
  • Temperature error is below 4% per 100 K and is documented as API 670 compliant
  • The sensor head withstands the documented 10,000 hPa pressure condition
  • At room temperature, the sensor and cable are documented as resistant to water, steam, natural gas, helium, bearing oils, and gasoline
  • Measure radial or axial shaft displacement without mechanical contact
  • Monitor position, eccentricity, vibration, or speed/key behavior with the matched converter
  • Use the armored probe where the cable route needs mechanical protection after verifying gap, mounting, and temperature
Description
PR6423-010-000 is an Emerson Epro 8 mm non-contact eddy current sensor for radial or axial shaft measurement on critical rotating machinery.

The official PR6423/010-000 configuration uses an M10×1 armored probe, 25 mm sleeve, adapter plug, 4.0 m total cable, and LEMO cable end.

Before installing or replacing PR6423-010-000, verify the mounting thread, sleeve reach, armor route, bend radius, target and gap, converter pairing, connector, temperature, and hazardous-area arrangement.
Alternative Names
PR6423-010-000 PR6423/010-000 PR6423010000 PR6423 010 000 Emerson PR6423-010-000 Emerson Epro PR6423/010-000 Epro PR6423-010-000 PR6423 Armored 8 mm Sensor
Technical notes
PR6423-010-000 must be matched to its calibrated converter; verify the M10×1 armored mounting, 25 mm sleeve, adapter plug, 4 m cable route, LEMO end, target, gap, and approvals.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What does the armored construction of Emerson PR6423-010-000 protect?
The metal armor improves mechanical protection for the probe cable. It does not eliminate the need for strain relief, minimum bend radius, connector protection, and separation from hot or moving parts.
Which mounting details must match for Emerson PR6423-010-000?
The order code specifies an M10×1 probe with a 25 mm sleeve. Confirm the tapped hole, thread engagement, sleeve reach, bracket rigidity, and target clearance.
Can Emerson PR6423-010-000 be used with any converter?
No. PR6423 sensors operate as part of an adjusted measuring chain. Match the converter type and serial number or follow Emerson's approved calibration procedure.
What target material is specified for Emerson PR6423-010-000?
The standard response is referenced to 42CrMo4 / AISI 4140 ferromagnetic steel. Other materials can change sensitivity and linearity and require verified adjustment.
How should the adapter connection of Emerson PR6423-010-000 be protected?
Keep the adapter plug clean, dry, fully seated, and free from tensile load. Protect it from vibration, contamination, and accidental disconnection.
Can Emerson PR6423-010-000 alone confirm hazardous-area approval?
No. Verify the sensor, converter, safety barrier, cable, temperature class, conformity labels, and complete loop against the applicable certificate.
What information should accompany a quote for Emerson PR6423-010-000?
Provide the complete PR6423/010-000 designation, clear label and connector photos, paired converter type and serial number, target material, required condition, and quantity.
