- Identify the fixed 10 m oil-proof open-ended cable before ordering
- Terminate the four conductors exactly as documented for the LVDT coils and shield
- Protect the permanent cable route because it is part of the sensor assembly
Emerson PR9350-02-S2 is a special contact LVDT for ±25 mm linear displacement measurement in installations requiring an oil-proof fixed lead.
The official PR9350/02-S2 version has a permanently attached 10 m cable with open ends instead of the standard detachable three-pole connector arrangement.
Before installation or replacement, verify the open-end wire identification, shield treatment, compatible carrier interface, oil exposure, cable route, mechanical linkage, travel and channel calibration.
Availability, condition, price, and shipping time for PR9350-02-S2 are confirmed during quotation.
Emerson PR9350-02-S2 Manuals, Datasheets, Links
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
- The S2 version uses a fixed 10 m cable
- Brown, white and green are the coil connections
- The black conductor is the cable shield and is not bonded to the sensor housing
- Use a compatible 5 Vrms carrier interface
- Verify polarity, zero and span after field termination
- Do not treat a standard PR9350/02 connector assembly as mechanically identical
- Inspect the cable along the full route for abrasion and oil-related damage
- Measure both coil halves when troubleshooting continuity
- Validate motion in both directions before restoring protection
- Linear stroke measurement in oil-exposed machinery areas
- Contact displacement feedback with a long fixed field cable
- Actuator, valve or mechanism position monitoring requiring open-end termination
