IC693MDL655

/ 4.9
1001 reviews | Need a Specific Revision?
General Electric IC693MDL655 is a Series 90-30 24 VDC positive/negative logic input module with 32 input points for high-density discrete signal acquisition.
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for IC693MDL655
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for IC693MDL655

  • Manufacturer:
    General Electric
  • Part Number:
    IC693MDL655
  • Product Family:
    GE 90-30 Series PLC
  • Product Type:
    Input Module
  • Rated Voltage:
    24 volts DC, Positive or Negative Logic
  • Input Voltage Range:
    0 to 30 volts DC
  • Inputs per Module:
    32 (four groups of eight inputs each)
  • Input Current:
    7.0 mA (typical ON current @ 24 VDC)
  • On-state Voltage:
    11.5 to 30 volts DC
  • Off-state Voltage:
    0 to 5 volts DC
  • On-state Current:
    3.2 mA (minimum)
  • Off-state Current:
    1.1 mA (maximum)
  • On response Time:
    2 ms maximum
  • Off response Time:
    2 ms maximum
  • Weight:
    0.62 lbs (0.28 kg)
  • Estimated shipping dimensions:
    3.5x13x13.7cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Diagnostics Installation

Features:

  • Provides 32 discrete input points.
  • Supports 24 VDC positive or negative logic.
  • Arranges the inputs as four groups of eight.
The current ordering configuration is IC693MDL655, the Series 90-30 32-circuit fast input module for 24 VDC field signals.

It acquires high-density discrete states through four separately commoned input groups in a supported backplane and controller configuration.

Before installation, verify field polarity, connector and terminal hardware, common wiring, I/O addressing, and host-system compatibility.

Availability is subject to Apter Power inventory and sourcing confirmation.
Verified resources for General Electric IC693MDL655: Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
