        IC693MDL753

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        The GE Fanuc IC693MDL753 is a Series 90-30 32-point 12/24 V DC positive-logic output module arranged in four isolated groups of eight outputs with dual 24-pin connectors.
        In Stock
        Ships by Thursday, October 29
        Fast Shipping Available
        Get a quick price for IC693MDL753
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for IC693MDL753

        • Manufacturer:
          General Electric
        • Part Number:
          IC693MDL753
        • Product Family:
          GE 90-30 Series PLC
        • Product Type:
          32-Point 12/24 V DC Positive Logic Output Module
        • Stock:
          1
        • Nominal Output Voltage:
          12/24 V DC positive logic
        • Operating Voltage Range:
          10.2–28.8 V DC
        • Output Points:
          32
        • Output Grouping:
          Four groups of eight
        • Isolation, Field to Logic:
          1500 V
        • Isolation, Group to Group:
          250 V
        • Maximum Current per Point:
          0.5 A
        • Maximum Current per Group:
          4 A
        • Maximum Current per Group Common Pin:
          3 A
        • Inrush Current:
          5.4 A for 10 ms
        • Maximum On-State Voltage Drop:
          0.3 V
        • Maximum Off-State Leakage:
          0.1 mA
        • On Response Time:
          0.5 ms maximum
        • Off Response Time:
          0.5 ms maximum
        • Backplane Current:
          260 mA maximum from 5 V bus
        • Field-Supply Current at 24 V:
          16.5 mA per group with all outputs on
        • Field-Supply Current at 12 V:
          9.6 mA per group with all outputs on
        • Field Connectors:
          Two 24-pin Fujitsu connectors
        • Dimensions:
          3.6 × 13.0 × 13.5 cm
        • Weight:
          0.28 kg
        • Tariff Code:
          8538900000
        • Country of origin:
          USA
        • Place of shipment:
          Xiamen, Fujian, China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Output Architecture Field Connection Load Planning Application
        • Thirty-two 12/24 V DC positive-logic output points
        • Four electrically isolated groups of eight shared-common outputs
        • Two 24-pin Fujitsu connectors for field wiring

        IC693MDL753 is a GE Fanuc Series 90-30 discrete output module designed for positive-logic DC field-load control.

        The module switches 32 outputs through four isolated groups and uses dual field connectors for compatible terminal blocks or prewired cable assemblies.

        Before installation or replacement, verify slot assignment, sourcing polarity, group commons, external load power and fusing, connector pinout, cable compatibility and total point and group loading.

        Availability, condition, price, and shipping time for IC693MDL753 are confirmed during quotation.
