DS3800DMPK1E1D

/ 4.9
1001 reviews | Need a Specific Revision?
The GE DS3800DMPK1E1D general-purpose voltage regulator board is manufactured using the traditional Mark IV series.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for DS3800DMPK1E1D
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for DS3800DMPK1E1D

  • Manufacturer:
    General Electric
  • Part Number:
    DS3800DMPK1E1D
  • Product Family:
    GE Mark V/VI Driver Board
  • Product Type:
    General Regulator Board
  • Stock:
    1
  • EPROM Modules:
    14 modules (user-removable, socket-mounted)
  • Jumpers:
    17 configurable jumpers
  • Ribbon Cables:
    Two 34-pin ribbon cables
  • One-Pin Connections:
    Two one-pin connections
  • Module Socket Type:
    Built-in connectors with removable sockets
  • EPROM Handling:
    Static-sensitive; requires static-protective bags
  • Module Removal Tool:
    Flat-blade screwdriver
  • Jumper Pin Configurations:
    Pins 1-2 or Pins 2-3
  • Installation Requirement:
    Static-protective surface during assembly
  • Weight:
    0.22 kg
  • Estimated shipping dimensions:
    17.8x15.2x1cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Use Cases Environmental Ratings Certifications & Standards

Features:

  • Interface Between the Industrial Control System and Regulated Power Distribution Network
  • Combines Capability of Voltage Regulation with Configurable Memory and Jumper Settings
  • Operates in Conjunction with the Mark IV Series Control Systems and Associated Industrial Monitors
Seamless module replacement is standard with the DS3800DMPK1E1D, however using proper static protection procedures will allow safe removal and reinstallation of EPROM modules without data corruption during maintenance. The DS3800DMPK1E1D has made improvements in several areas over previous regulator board designs in addition to incorporating built-in connector sockets for flexible module configuration within the Mark IV control system.

The DS3800DMPK1E1D provides essential regulation functions common to the entire control rack, and is a critical component of the power management path, directly affecting the proper, normal operation of the overall monitor system. One DS3800DMPK1E1D regulator board is required per rack depending on the desired configuration level. The DS3800DMPK1E1D occupies a dedicated position in the rack and is always installed with proper attention to jumper alignment and EPROM module seating.

For Dual Redundant Power applications, the Mark IV system may require additional power supply modules installed in redundant slots. In addition to standard single board operation, the redundant configuration also performs automatic switchover. The Mark IV dual power configuration executes failover using the internal circuitry specified in the system options.

The DS3800DMPK1E1D General Electric General Regulator Board may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
General Electric DS3800DMPK1E1D General Regulator Board Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
General Electric DS3800DMPK1E1D General Regulator Board Specs

General

  • Manufacturer General Electric
  • Model DS3800DMPK1E1D
  • Condition New Original ready stock
  • Product Family DS3800HIOA1C1E,DS3800HIOD1H1G
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Turbine Speed Regulation: Monitors and adjusts real-time turbine velocities.
  • System Load Management: Stabilizes heavy generator power outputs continuously.
  • Fuel Flow Control: Regulates liquid or gas fuel injection loops.
  • Static Voltage Regulation: Prevents power surges inside machine control networks.
  • Automated Logic Execution: Runs embedded firmware code via 14 onboard EPROMs.
  • Diagnostic Data Transmission: Sends critical telemetry through dual 34-pin ribbon connectors.
  • Operating Temperature: Performs safely from 0°C up to 60°C.
  • Storage Temperature: Withstands warehouse climates from -40°C to 85°C.
  • Relative Humidity: Endures up to 95% non-condensing moisture conditions.
  • Cooling Requirement: Depends on forced cabinet airflow for heat dissipation.
  • ESD Vulnerability: Requires full static-shielded packaging during all handling procedures.
  • UL Recognized: Certified under United States industrial control safety regulations.
  • CE Marking: Matches European health and electrical safety directives.
  • ANSI/ISA Compliant: Built to withstand heavy industrial vibration and electrical noise.
Description
The DS3800DMPK1E1D is a General Regulator board under the Mark IV series, specifically engineered to regulate and stabilize voltage and current outputs within industrial control systems. This DS3800DMPK1E1D board is designed to address the critical challenge of maintaining consistent power regulation in complex automation environments, ensuring that connected systems receive stable and reliable electrical supply without fluctuations that could disrupt operations. The DS3800DMPK1E1D is widely applied in power generation facilities, manufacturing plants, and process control industries where precise voltage regulation is essential for protecting sensitive equipment and maintaining operational continuity.

The DS3800DMPK1E1D features 14 EPROM modules mounted on the board, which store essential configuration data and operational parameters required for the regulator's functionality. Additionally, the DS3800DMPK1E1D incorporates 17 jumpers for configuration settings, two 34-pin ribbon cables for data and signal transmission, and two one-pin connections for specific interfacing requirements. When replacing the DS3800DMPK1E1D, it is important to note that the replacement unit does not come with EPROM modules pre-installed in the module sockets. The connectors are built directly into the board, allowing the modules to be fitted and withdrawn as needed during maintenance or upgrade procedures.

When handling the EPROM modules from the original DS3800DMPK1E1D, use a flat-blade screwdriver to carefully pry between the module and the socket at either end, gently rocking the blade to loosen the module before repeating the process on the opposite end. Immediately place the removed module into a static-protective bag, as static electricity can readily corrupt the data stored on the module. To install the module onto the replacement DS3800DMPK1E1D, locate the corresponding socket, align the module properly, and gently press it into place using your fingertips. Inspect the connection to ensure there is no gap between the socket and the module, pressing firmly if necessary to establish a complete and secure connection.
Revisions

Revision Part #

Also known as

DS3800DMPK1C1B
DS3800DMPK1-C1B, Series C1B Rev C1B
DS3800DMPK1C
DS3800DMPK1-C, Series C, Rev C
DS3800DMPK1E
DS3800DMPK1-E, Series E, Rev E
DS3800DMPK1D
DS3800DMPK1-D, Series D, Rev D
Alternative Names
DS38OODMPK1E1D DS3800DMPKIE1D DS3800DMPK1EOD DS3800HCMC1A1B DS3800HIOA1C1E DS3800HIOD1H1G
Technical notes
The DS3800DMPK1E1D features 14 EPROM module slots, 17 configurable jumpers, two 34-pin flat cable connectors, and two independent single-pin connections, enabling robust industrial communication and processing capabilities.
