DS3800HIOD1H1G

/ 4.9
1001 reviews | Need a Specific Revision?
The GE DS3800HIOD1H1G digital I/O board is widely used in industrial gas turbine control systems. As a crucial communication interface, it processes digital input and output signals, ensuring real-time monitoring of heavy-duty gas turbine operations.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for DS3800HIOD1H1G
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for DS3800HIOD1H1G

  • Manufacturer:
    General Electric
  • Part Number:
    DS3800HIOD1H1G
  • Product Family:
    GE Mark V/VI Driver Board
  • Product Type:
    Digital I/O Board
  • Stock:
    1
  • Connector Type (One End):
    Modular Connector
  • Mounting Feature (Opposite End):
    Retention Levers
  • 10-Pin Connectors:
    2
  • 40-Pin Connector:
    1
  • Connector Accessibility:
    Front-Facing (between retention levers)
  • Configurable Jumpers:
    6
  • Static Sensitivity:
    Sensitive to Electrostatic Discharge (ESD)
  • Weight:
    0.24 kg
  • Estimated shipping dimensions:
    19.2x23.3x2cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Use Cases Firmware & Updates Performance & Efficiency

Features:

  • Interface Between the Drive Control System and Field Digital I/O Devices
  • Integrates Digital Signal Processing with Secure Retention Mounting
  • Functions in Conjunction with the Speedtronic Mark IV Control Architecture
Seamless signal integration is standard with the DS3800HIOD1H1G, however using appropriate static protection precautions will prevent electrostatic discharge damage during handling and installation. The DS3800HIOD1H1G has been designed with accessibility improvements in several areas over previous board designs in addition to incorporating six configurable jumpers for flexible application parameters.

The DS3800HIOD1H1G provides essential digital I/O functions common to the entire turbine control rack, and is a critical component of the control signal path, directly affecting the proper, normal operation of the overall gas turbine management system. One DS3800HIOD1H1G board is required per designated I/O slot depending on the specific control configuration.

For proper installation applications, the Speedtronic Mark IV system requires the DS3800HIOD1H1G Digital I/O Board to be installed with strict adherence to electrostatic discharge protocols. In addition to standard signal processing operation, the DS3800HIOD1H1G configuration also requires proper jumper settings. The DS3800HIOD1H1G installation procedure executes secure mounting using the retention levers specified in the board design.

The DS3800HIOD1H1G General Electric Digital I/O Board may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
General Electric DS3800HIOD1H1G Digital I/O Board Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
General Electric DS3800HIOD1H1G Digital I/O Board Specs

General

  • Manufacturer General Electric
  • Model DS3800HIOD1H1G
  • Condition New Original ready stock
  • Product Family DS3800HIOA1C1E,DS3800HMPJ1A1D
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Turbine Control Systems: Primary deployments occur within GE Speedtronic Mark IV architectures to safely manage fuel valves, trip systems, and startup sequencing.
  • Sensor and Actuator Interfacing: Acts as a bridge to aggregate telemetry from physical field devices (such as pressure switches or limit sensors) and route instructions back to binary actuators.
  • Industrial Automation & DCS: Deployed within broader Distributed Control System (DCS) frameworks for plant-wide real-time monitoring and automated assembly orchestration.
  • Drive System Integration: Facilitates communication between control system racks and external variable speed motor drives.
  • Onboard Configuration Jumpers: Functional updates or behavioral changes are manually achieved using six onboard jumpers that modify how signals are handled right at the hardware layer.
  • EPROM Modules: Firmware modifications on Mark IV series boards typically require replacing or reflashing physical EPROM/EEPROM chips socketed directly onto the circuit board rather than downloading digital files over a network.
  • Streamlined Single-Slot Architecture: Features a compact physical design that inserts into standard chassis racks without specialized tools, minimizing panel footprint.
  • Front-Facing Connectivity: Built with one 40-pin connector and two 10-pin connectors positioned between mechanical retention levers. This configuration optimizes maintenance efficiency by making wiring readily accessible from the front.
  • Environmental Tolerance: Functions effectively in temperature ranges from 0°C to 60°C and withstands relative humidity levels from 5% to 95% non-condensing, maintaining operational stability through fluctuating industrial microclimates.
  • Static Sensitivity: Achieving peak lifecycle efficiency requires careful handling; the unit is highly sensitive to electrostatic discharge (ESD) and requires grounding wrist straps during installation to avoid component failure.
Description
The DS3800HIOD1H1G Digital I/O Board is designed for straightforward installation within the drive enclosure, featuring a modular connector at one end and retention levers at the opposite end to ensure secure mounting and reliable connectivity. Positioned between the retention levers on the DS3800HIOD1H1G board are two 10-pin connectors and one 40-pin connector, all arranged for convenient front-facing access during installation and maintenance procedures. Additionally, the DS3800HIOD1H1G incorporates six jumpers that enable flexible configuration options to accommodate various operational requirements within the turbine control architecture.

The DS3800HIOD1H1G Digital I/O Board is sensitive to static electricity buildup, and appropriate handling precautions are essential to prevent electrostatic discharge damage. The DS3800HIOD1H1G is packaged in a sealed static protection container for shipping to ensure it arrives in optimal condition. When handling the DS3800HIOD1H1G board, operators should utilize a static protective wrist strap, securing one end around the wrist or arm while fastening the clip at the opposite end of the cord to a grounded metal surface such as a metal chair, post, or other suitable metal item to maintain proper grounding throughout the installation process.

The DS3800HIOD1H1G Digital I/O Board is specifically designed to handle the complex input and output signal processing demands of gas turbine control environments, providing reliable digital signal interfacing between the control system and field devices. This DS3800HIOD1H1G board addresses the critical challenge of maintaining precise digital communication pathways in industrial power generation settings where signal integrity directly impacts turbine performance and operational safety. The DS3800HIOD1H1G enables accurate monitoring and control of digital signals, ensuring responsive turbine management under varying load conditions and operational scenarios.
Revisions

Revision Part #

Also known as

DS3800HIOD1H1G
DS3800HIOD1-H1G, Series H1G, Rev H1G
DS3800HIOD1G1G
DS3800HIOD1-G1G, Series G1G, Rev G1G
DS3800HIOD1H1H
DS3800HIOD1-H1H, Series H1H, Rev H1H
DS3800HIOD1H
DS3800HIOD1-H, Series H, Rev H
Alternative Names
DS38OOHIOD1H1G DS3800HI0D1H1G DS3800HIODIH1G DS3800HIOD1HIG DS3800HIOA1C1E DS3800HMPJ1A1D
Technical notes
The DS3800HIOD1H1G is specifically designed to address the complex signal delays and electrical noise interference issues in high-stress industrial environments. By providing a reliable transmission path for discrete signals, it solves key problems such as unexpected system downtime and control errors, thereby optimizing the overall operational safety and efficiency of the gas turbine system.
