          Quotation assistance for F7133 and access to official HIMA documentation are available from Apter Power for installed HIQuad power-distribution assemblies.

        F7133

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        HIMA F7133 is a four-channel power distribution module with individual fuse indication, common fuse-status monitoring, and L- distribution.
        In Stock
        Ships by Thursday, October 29
        Fast Shipping Available
        Get a quick price for F7133
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for F7133

        • Manufacturer:
          HIMA
        • Part Number:
          F7133
        • Product Family:
          HIMA HIQuad® X
        • Product Type:
          Four-Channel Power Distribution Module
        • Stock:
          1
        • Channels:
          4 fused outputs
        • Nominal Supply:
          24 VDC
        • Current Consumption:
          60 mA
        • Fuse Rating:
          4 A slow-blow per channel
        • Status Indication:
          One LED per fuse
        • Alarm Contact:
          Collective relay
        • Relay Contact:
          Up to 30 V / 4 A
        • Module Width:
          4 TE
        • Tariff Code:
          8538900000
        • Country of origin:
          Germany
        • Place of shipment:
          Xiamen,Fujian,China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Power Distribution Fuse Monitoring Wiring Applications

        Features:

        • Four separately fused 24 VDC branches
        • Individual fuse LEDs
        • Collective fuse-status relay
        F7133 organizes protected auxiliary power into four independently serviceable branches.

        A local LED identifies the affected fuse, while the collective relay gives the cabinet a remote indication that the monitored set is no longer healthy.

        Branch current, conductor size, fuse selectivity, relay-contact loading, and isolation practice are established from the downstream circuit design.

        Apter Power supports quotation requests and official HIMA documentation access for the HIMA F7133 Four-Channel Power Distribution Module.
        HIMA F7133 Four-Channel Power Distribution Module Manuals, Datasheets, Links Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

        Four fused 24 VDC distribution channels

        • Branch count: F7133 divides the incoming rack supply into four separately protected output channels.
        • Fuse type: Each branch uses a 5 x 20 mm, 4 A time-lag G-fuse cartridge specified for the module.
        • Negative distribution: The assembly includes L- distribution so the protected circuits can share the documented return arrangement.
        • Load allocation: Connected devices are grouped so the expected current of one branch remains below its fuse and conductor limits.
        • Selectivity: Branching the supply helps isolate a downstream fault without unnecessarily removing every auxiliary cabinet load.

        Indication and alarm of fuse condition

        • Channel indication: Individual status indicators identify which protected branch requires inspection.
        • Collective alarm: A common monitoring contact lets the cabinet control design report loss of fuse health remotely.
        • Delayed element: The time-lag characteristic tolerates permitted short inrush conditions while continuing to protect sustained overloads.
        • Fault tracing: Technicians can compare the local indication, collective signal, and branch load before replacing a cartridge.
        • Safety limitation: Fuse monitoring reports power-distribution health but does not itself prove that the connected final element can operate.

        Connecting the power-distribution module

        • Supply input: The documented 24 VDC feed is applied through the rack-side connection assigned to F7133.
        • Protected outputs: Four front-side branches route the fused positive supply to the selected field or interface loads.
        • Return path: L- terminals preserve the negative distribution scheme used by the associated HIQuad cabinet.
        • Conductor sizing: Wire cross-section, terminal rating, branch current, and upstream protection are coordinated before energization.
        • Safe service: External isolation and verification of a de-energized state are required before fuse or terminal work.

        Cabinet circuits supplied through F7133

        • Safety modules: Protected branches can feed approved HIQuad modules that require separately fused 24 VDC distribution.
        • Field interfaces: Interface assemblies and signal-conditioning circuits use the module where a monitored cabinet supply branch is specified.
        • Alarm circuits: Annunciators and auxiliary alarm devices can be grouped on a branch sized for their steady and inrush current.
        • Final-element auxiliaries: Valve, relay, or contactor interface circuits can receive protected power when their load remains within the documented branch design.
        Description
        Within HIMA HIQuad and HIQuad X installations, F7133 is a four-channel power distribution module that routes 24 VDC through individually fused output branches.

        A collective relay contact allows F7133 to report when the monitored fuse condition is no longer healthy. Front connections carry the protected outputs and common L- distribution, while rear contacts receive rack power.

        Combining branch protection, front indication, and status supervision in one narrow module lets F7133 isolate a failed circuit without disturbing the remaining outputs. Fuse rating, downstream load, conductor size, external isolation, and relay-contact loading remain part of the circuit design.
        Alternative Names
        HIMA F7133 HIQuad F7133 HIQuad X F7133 F 7133 F-7133 HIMA F 7133 F7I33 F7l33
        Technical notes
        F7133 distributes 24 VDC through four fused branches, provides per-channel LED indication, and reports collective fuse status by relay.
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        How are the four outputs protected on F7133?
        F7133 uses one 4 A slow-blow miniature fuse for each of its four 24 VDC distribution channels.
        How is a blown fuse identified on F7133?
        Each channel on F7133 has a front LED, and the collective relay contact reports whether all monitored fuses remain healthy.
        What should be connected to the alarm contact of F7133?
        Use the documented collective relay contact of F7133 for panel indication or a monitoring input, staying within its stated voltage and current rating.
        How should downstream loads be divided on F7133?
        Group loads so each F7133 branch remains within the fuse, conductor, connector, and supply limits and one fault does not remove unrelated equipment.
        What must be isolated before servicing F7133?
        De-energize the relevant 24 VDC feed and confirm safe isolation before replacing a fuse or disturbing wiring on F7133.
        Which rack checks apply to F7133?
        Verify the documented rear-terminal feed, module position, L- distribution, total supply capacity, and relay wiring before fitting F7133.
        Which safety-cabinet circuits benefit from F7133 power distribution?
        F7133 is used for protected 24 VDC branch distribution in HIQuad and HIQuad X safety cabinets, including shutdown, fire-and-gas, and burner-control systems.
