    Empower your facility's distributed control architecture with genuine Honeywell 8C-TAIM01 replacement components from Apter Power.

8C-TAIM01 51306999-175

/ 4.9
1001 reviews | Need a Specific Revision?
The HONEYWELL 8C-TAIM01 51306999-175 delivers ruggedized, conformal-coated multi-channel low-level analog input terminations to guarantee flawless signal integrity in harsh processing plants.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for 8C-TAIM01 51306999-175
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 8C-TAIM01 51306999-175

  • Manufacturer:
    Honeywell
  • Part Number:
    8C-TAIM01 51306999-175
  • Product Family:
    Honeywell Experion PKS ( C200, C300 )
  • Product Type:
    Low-Level Analog Input Termination Assembly
  • Stock:
    1
  • Architecture Topology:
    Non-Redundant (NR) Base Assembly
  • Channel Capacity:
    16 Fully Isolated Channels (Channel-to-Channel / IOL / Power)
  • Supported Inputs:
    Thermocouples (Types J, K, E, T, B, S, R, N), RTDs (Pt100, Pt1000, Ni120, Cu10, Cu50), mV signals (-20 to +100 mV)
  • Operating Voltage:
    24 VDC Nominal (Supplied via Series 8 Power System / Header Board)
  • Current Draw:
    Approximately 120 mA max (Under full module load)
  • Internal Cabinet Operating Temp:
    0°C to +60°C (32°F to 140°F) Storage & T
  • Relative Humidity Range:
    5% to 95% RH (Non-condensing, de-rated above 40°C)
  • Environmental Protection:
    Conformal Coated (ISA S71.04 G3 Corrosive Standard Compliant)
  • Estimated shipping dimensions:
    14.5x12x5cm
  • Tariff Code:
    8538900000
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Applications Applications Performance & Efficiency Safety & Compliance

Features:

  • ISA G3-Rated Conformal Coating for Ultimate Resilience
  • Space-Optimized Vertical Footprint with Detachable Terminals
  • Isolated Low-Level Signal Integrity with Live Module Swapping
The HONEYWELL 8C-TAIM01 51306999-175 features a ruggedized, factory-applied conformal coating engineered to safeguard internal electronic circuitry against high humidity, particulate contaminants, and aggressive corrosive gases. This premium protection matrix drastically mitigates component failure rates in demanding offshore or chemical environments, ensuring reliable multi-year operations.

Engineered with a streamlined 9-inch vertical form factor and two-tier detachable terminal blocks, the HONEYWELL 8C-TAIM01 51306999-175 simplifies dense marshalling cabinet routing and eliminates complex wire stresses. This high-density architecture accelerates physical installation times, maximizes enclosure space, and optimizes natural convection cooling loops.

Providing an ultra-secure interface for up to 16 fully isolated channels, the HONEYWELL 8C-TAIM01 51306999-175 prevents ground loop corruption on sensitive thermocouple inputs while supporting full removal and insertion under power. This allows technicians to hot-swap active processing modules instantly without disrupting permanent field terminal wires.

The 8C-TAIM01 51306999-175 HONEYWELL Low-Level Analog Input Termination Assembly may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
HONEYWELL 8C-TAIM01 51306999-175 Low-Level Analog Input Termination Assembly Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
HONEYWELL 8C-TAIM01 51306999-175 Low-Level Analog Input Termination Assembly

General

  • Manufacturer HONEYWELL
  • Model 8C-TAIM01 51306999-175
  • Condition New Original ready stock
  • Product Family 8C-TAIMA1 51307171-175,8C-TAID61 51307069-175,8C-TAIDB1 51307133-175
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Upstream & Downstream Temperature Tracking: High-accuracy thermal profiling via direct RTD and TC connection in oil/gas extraction.
  • Corrosive Chemical Processing Enclosures: G3-coated protection for petrochemical reactors and harsh chemical manufacturing facilities.
  • Boiler & Turbine Thermal Monitoring: Reliable handling of millivolt inputs in power plants with robust line isolation.
  • Large-Scale Water Treatment Telemetry: Trusted for connecting field instruments to centralized C300 controllers in municipal systems.
  • Elite Conversion Precision: Minimizes drift with a factory-calibrated sensor gain error of only 0.050% full scale.
  • 16-Channel Galvanic Isolation: Dedicated channel-to-channel isolation prevents field ground loop interference.
  • Footprint Optimization & Lower TCO: 9-inch vertical orientation eliminates the need for extra external marshalling or fusing panels.
  • Zero Process Disturbance: Supports RIUP (Hot-Swapping) for replacing processing blocks without interrupting field wires.
  • Stringent G3 Shielding: Compliant with ISA Standard S71.04 G3 for resistance against corrosion.
  • Hazardous Environment Approval: Certified for ATEX Zone 2 and Class I, Div 2, ensuring spark-free operation.
  • Industrial Surge & Noise Mitigation: Meets EN 61000-4-5 standards for 1kV/2kV surge protection.
  • European Regulatory CE Alignment: Complies with LVD (2014/35/EU) and EMC (2014/30/EU) directives.
Description
The HONEYWELL 8C-TAIM01 51306999-175 is an industrial-grade Input Output Termination Assembly (IOTA) purpose-built for the elite Honeywell Experion PKS and PlantCruise Series 8 hardware platform. Acting as the vital physical gateway between field instrumentation and the C300 controller, this component provides a dedicated, direct termination landscape for up to 16 channels of highly sensitive temperature and millivolt sensors. By establishing a rock-solid electrical bridge, it ensures that low-level field signals are routed into the processing module with zero degradation.

Featuring factory-applied G3-level conformal coating as indicated by its exclusive "8C" architecture prefix, the HONEYWELL 8C-TAIM01 51306999-175 offers uncompromised environmental defense against humidity, dust, and aggressive chemical vapours. This robust protective layer shields the circuitry from airborne particulate corrosion, making it the industry’s top choice for high-stakes deployment in oil refineries, petrochemical complexes, offshore platforms, and power generation facilities. Procurement managers choose this coated assembly to drastically eliminate unplanned system interruptions caused by atmospheric degradation.

Designed with a space-saving vertical form factor, the HONEYWELL 8C-TAIM01 51306999-175 optimizes marshalling cabinet density while promoting exceptional unassisted thermal dissipation. The unique "tilted" chassis layout eliminates harsh 90-degree cable kinks, allowing heavy 12 AWG field wiring to glide smoothly into two-tier detachable blocks. This intuitive mechanical arrangement cuts cabinet layout costs, slashes initial system installation times, and simplifies routine lifecycle testing or module swapping.

When paired with its companion electronic processing module, the HONEYWELL 8C-TAIM01 51306999-175 ecosystem supports live module removal and insertion under power (RIUP). This advanced capability empowers maintenance technicians to hot-swap active components without touching field terminations, completely protecting the process loop from downtime. It stands as an indispensable asset for high-integrity distributed control system (DCS) architectures where process continuity and safety compliance are mandatory.
Alternative Names
8C-TAIM01 51306999-175 8C-TAIMO1 513O6999-175 BC-TAIM01 51306999-175 8C-TAIM0I 5I306999-I75 8CTAIM0151306999175 8C-TAIMA1 51307171-175 8C-TAID61 51307069-175 8C-TAIDB1 51307133-175
Technical notes
The HONEYWELL 8C-TAIM01 51306999-175 functions as a specialized non-redundant field termination assembly and must be populated with an active 8C-PAIMA1 Low-Level AI Module to execute signal processing. To secure full measurement accuracy and suppress electromagnetic interference in heavy motor environments, engineers must utilize shielded twisted-pair cabling grounded exclusively at a single local ground point.
