8C-TAIX61 51306977-175

/ 4.9
1001 reviews | Need a Specific Revision?
Honeywell 8C-TAIX61 51306977-175 is the coated redundant Series C analog input IOTA for sixteen 4–20 mA channels. It provides field termination for redundant analog input electronics.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for 8C-TAIX61 51306977-175
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 8C-TAIX61 51306977-175

  • Manufacturer:
    Honeywell
  • Part Number:
    8C-TAIX61 51306977-175
  • Product Family:
    Honeywell Experion PKS ( C200, C300 )
  • Product Type:
    Analog Input I/O Termination Assembly
  • Stock:
    1
  • Channel Capacity:
    16 Channels (Single-Ended)
  • Operating Voltage:
    24 VDC Nominal Loop/System Power
  • Current Consumption:
    120 mA Maximum Module Current
  • A/D Conversion Resolution:
    16-Bit Analog-to-Digital Processing
  • Measurement Accuracy:
    ±0.05% to ±0.075% of Full Scale (Reference Conditions)
  • Input Loop Resistance:
    200 Ohms Nominal
  • Operating Temperature:
    0°C to +60°C (32°F to 140°F)
  • Storage Temperature:
    -40°C to +85°C (-40°F to 185°F)
  • Relative Humidity:
    10% to 90% Non-Condensing
  • Weight:
    0.8378 lbs (0.38 kg)
  • Estimated shipping dimensions:
    29.5x12x7cm
  • Tariff Code:
    8538900000
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Compatibility Diagnostics

Features:

  • High-Precision 16-Bit Signal Processing
  • Conformal Coating and Noise Rejection
  • Series 8 RIUP and Modular Maintenance
The HONEYWELL 8C-TAIX61 51306977-175 leverages an advanced 16-bit analog-to-digital conversion interface to resolve minute process variations with extreme fidelity, helping to secure flawless loop management. It ensures that critical feedback metrics remain accurate under strict operational tolerances, preventing regulatory drift in delicate processing loops.

Featuring a ruggedized factory conformal layer, the HONEYWELL 8C-TAIX61 51306977-175 provides robust protection against corrosive ISA Class G3 environments. It offers substantial galvanic isolation and powerful normal-mode noise rejection, shielding sensitive network components from severe plant floor voltage spikes and hazardous ground loops.

The HONEYWELL 8C-TAIX61 51306977-175 structure interfaces cleanly with Honeywell's dynamic Removal and Insertion Under Power (RIUP) system for plug-in hardware. Field wiring stays securely landed on the terminal screws while matching I/O electronic modules can be quickly updated or hot-swapped without generating process outages.

The 8C-TAIX61 51306977-175 HONEYWELL Analog Input I/O Termination Assembly may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Verified resources for Honeywell 8C-TAIX61 51306977-175: Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
HONEYWELL 8C-TAIX61 51306977-175 Analog Input I/O Termination Assembly

General

  • Manufacturer HONEYWELL
  • Model 8C-TAIX61 51306977-175
  • Condition New Original ready stock
  • Product Family 8C-TAIX51 51306979-175,8C-TAIXA1 51307127-175,8C-TAIXB1 51307129-175
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Organizes sixteen two-wire transmitter channels in a redundant Series C analog-input arrangement.
  • Supports continuous process measurement where paired input electronics are required by the control design.
  • Fits Experion cabinets that preserve the approved redundant IOM and IOTA architecture.
  • Both connector paths must match the intended redundant Series C analog-input electronics.
  • A non-redundant base is not interchangeable because its topology, keying, and cabinet arrangement differ.
  • Field terminals, loop-power assignments, and channel numbering must follow the installed drawing.
  • Field-short protection forms part of the documented input design.
  • Troubleshooting should compare both redundant paths, loop current, polarity, and channel status.
  • A discrepancy between paired inputs requires inspection of transmitters, wiring, connectors, and electronics.
Description
The HONEYWELL 8C-TAIX61 51306977-175 serves as a vital electrical bridge within the Honeywell Series 8 controller network, connecting physical field transmitters directly to the central processing modules. This 16-channel single-ended interface provides secure termination for analog loop variables, handling parameters such as flow rates, pressure levels, and temperatures without data degradation. Its optimized physical form factor permits dense chassis arrangements, saving critical footprint space inside active control cabinets.

Engineered with a high-grade factory-applied conformal coating, the HONEYWELL 8C-TAIX61 51306977-175 provides unmatched resilience in corrosive environments prone to airborne contaminants and moisture. It mitigates electromagnetic interference (EMI) and signal noise typical of heavy machine operations, stabilizing vulnerable 4–20 mA or 0–24 V loops. This ensures steady, jitter-free analog measurements that maintain tight regulatory loop execution across complex industrial layouts.

By fitting directly into the modular Series 8 chassis architecture, the HONEYWELL 8C-TAIX61 51306977-175 maximizes plant uptime and accelerates mean-time-to-repair (MTTR) protocols. While the permanent field wiring remains untouched on this termination block, its plug-in electronic I/O modules support live hot-swapping procedures. This layout allows plant technicians to replace active internal components on-the-fly without forcing process reboots or stopping field loop power.
Alternative Names
8C-TAIX61 51306977-175 BC-TAIX61 51306977-175 8C-TA1X61 51306977-175 8C-TAIX6I 51306977-175 8C-TAIX51 51306979-175 8C-TAIXA1 51307127-175 8C-TAIXB1 51307129-175
Technical notes
Redundant wiring for 8C-TAIX61 51306977-175 must follow the paired Series C input arrangement; a non-redundant IOTA should not be substituted from appearance alone.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What redundancy role belongs to Honeywell 8C-TAIX61 51306977-175?
It is the redundant Series C analog-input IOTA, providing connections for a paired input-module arrangement.
How many field loops are organized by Honeywell 8C-TAIX61 51306977-175?
The Series C guide documents 16 two-wire analog input channels for this IOTA configuration.
Which transmitter installation suits Honeywell 8C-TAIX61 51306977-175?
Use it for approved two-wire process transmitters connected through the redundant Series C input architecture.
What protection boundary applies to Honeywell 8C-TAIX61 51306977-175?
The design includes field-short protection, but wiring and external energy must still remain within the documented limits.
Can Honeywell 8C-TAIX61 51306977-175 replace a non-redundant TAIX51 base?
Not as a visual swap; the paired electronics, redundancy topology, connectors, keying, and cabinet layout must all match.
What evidence should accompany Honeywell 8C-TAIX61 51306977-175 procurement?
Include the exact code, installed IOM pair, cabinet position, wiring photographs, quantity, destination, and requested date.
