Features:
- FTE Bridge for Supported Chassis Series-A Hardware
- Connects the Controller Chassis to the FTE Supervisory Network
- Uses Device Index and Honeywell BOOTP Configuration
The
Honeywell TK-FTEB01 51309512-175 is a Fault Tolerant Ethernet bridge module for supported Experion Chassis Series-A control hardware. It provides the defined connection between the controller chassis and the FTE supervisory network.
Installation and replacement require confirmation of the Device Index, cable shield grounding, yellow and green FTE connections, and hardware image version. Address assignment and firmware verification must follow the Honeywell FTE Bridge procedure.
For ordering, provide TK-FTEB01 51309512-175, the hardware revision, Device Index, image version, and required quantity so Apter Power can confirm availability and compatibility.
Honeywell TK-FTEB01 51309512-175 Manuals, Datasheets, Links
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Honeywell TK-FTEB01 51309512-175 FTE Bridge Module Specs
General
- Manufacturer Honeywell
- Model TK-FTEB01 51309512-175
- Condition New Original ready stock
- Product Family Honeywell Experion PKS ( C200, C300 )
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
- Install the module in the supported Chassis Series-A frame.
- Confirm the cable shield ground jumper before connection.
- Match the yellow and green FTE cable connections to the existing installation.
- Configure the required Device Index with the module BCD switches.
- Use the Honeywell BOOTP Server for address assignment.
- Verify the hardware image version before returning the module to service.
- Record the Device Index and image version before removal.
- Confirm grounding and cable identification on the replacement module.
- Follow the Honeywell FTE Bridge implementation procedure.
