    Apter Power can review module identity, I/O assembly details, and sourcing options for this Series C requirement.

CC-PAIN01 51410069-176

/ 4.9
1001 reviews | Need a Specific Revision?
Honeywell CC-PAIN01 51410069-176 is a high-level G3 analog input module rated 150 mA at 24 VDC for a compatible Series C installation.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for CC-PAIN01 51410069-176
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for CC-PAIN01 51410069-176

  • Manufacturer:
    Honeywell
  • Part Number:
    CC-PAIN01 51410069-176
  • Product Family:
    Honeywell Experion PKS ( C200, C300 )
  • Product Type:
    Analog Input Module
  • Stock:
    1
  • Input Channels:
    16 Channels (Single-Ended)
  • Input Range / Type:
    4-20 mA current (through internal 200 Ω resistor)
  • A/D Converter Resolution:
    16 bits Input Scan Rate50 ms
  • Hardware Accuracy:
    ±0.075% of full-scale (23.5°C ± 2°C); ±0.15% (0°C to 60°C)
  • Common Mode Rejection Ratio (CMRR):
    70 dB (dc to 60 Hz, 500 Ω source imbalance)
  • Normal Mode Rejection Ratio (NMRR):
    20 dB (at 60 Hz)
  • Maximum Normal Mode Input:
    ±30 Volts
  • Crosstalk (Channel-to-Channel):
    -60 dB (dc to 60 Hz)
  • Operating Temperature:
    0°C to 60°C
  • Storage Temperature:
    -40°C to +85+85°C (Standard Series-C environmental profile)
  • Weight:
    0.3 kg
  • Estimated shipping dimensions:
    5.5x16x14.5cm
  • Tariff Code:
    8537101190
  • Country of origin:
    China
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Signal Paths Accuracy Limits IOTA Matching Product Applications

Features:

  • Sixteen analog inputs: Accepts 16 single-ended 4–20 mA process signals.
  • High-level conversion: Uses internal 200 Ω resistors, 16-bit conversion, and a 50 ms scan.
  • Series C identity: The photographed 51410069-176 unit is a G3 high-level CC-PAIN01 module.
CC-PAIN01 51410069-176 is a non-HART Series C analog input module for current-loop measurements.

Published rejection, accuracy, crosstalk, and temperature limits define the measurement boundary for the complete installed channel.

The module should be matched with its compatible IOTA, revisions, terminal map, ranges, grounding, cabinet power, and Experion configuration.

Apter Power supports CC-PAIN01 51410069-176 enquiries with sourcing, documentation, IOTA review, and Series C configuration guidance.
Honeywell CC-PAIN01 51410069-176 Analog Input Module Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Channel capacity: The module acquires 16 single-ended current inputs.
  • Input range: Each channel accepts 4–20 mA through an internal 200 Ω path.
  • Conversion: The analog-to-digital converter provides 16-bit resolution.
  • Scan period: The published input scan rate is 50 ms.
  • Accuracy: ±0.075% full scale near 23.5°C and ±0.15% full scale across 0°C to 60°C.
  • Mode rejection: 70 dB common-mode rejection and 20 dB normal-mode rejection under published conditions.
  • Crosstalk: Channel-to-channel crosstalk is specified at −60 dB from DC to 60 Hz.
  • Normal-mode filter: The single-pole RC response is specified at −3 dB near 6.0 Hz.
  • Nonredundant base: CC-TAIN01 is the documented 6-inch IOTA for CC-PAIN01.
  • Redundant base: CC-TAIN11 is the documented 12-inch redundant IOTA.
  • Revision control: Retain 51410069-176 with the photographed firmware and hardware revisions.
  • Signal boundary: CC-PAIN01 is a non-HART current-input module; do not infer HART support from another analog IOM.
  • Process transmitters: Acquires 4–20 mA pressure, flow, level, temperature, and analytical measurements.
  • Series C control: Converts field current signals for the configured Experion strategy.
  • Redundant architecture: Supports a redundant IOTA arrangement when the complete cabinet design is configured for it.
  • Maintenance replacement: Retains channel ranges, IOTA selection, revisions, field power, and terminal records during exact-model service.
Description
Within an Experion Series C control installation, CC-PAIN01 51410069-176 functions as a Honeywell high-level G3 analog input module. The installed nameplate identifies the exact part number, a 150 mA load at 24 VDC, and an operating ambient range from 0°C to 60°C.

Through the matching IOTA, CC-PAIN01 51410069-176 receives high-level field signals and transfers converted channel data to the controller. The IOTA identity, field wiring, loop-power arrangement, signal type, scaling, and channel allocation must remain consistent with the saved control configuration.

For revision control, CC-PAIN01 51410069-176 should be matched by the complete model, part suffix, firmware and hardware markings, and installed Series C assembly. Similar CC-PAIN01 suffixes must not be treated as direct substitutes until revision compatibility, IOTA pairing, and configuration requirements have been verified.
Alternative Names
CC-PAIN01 51410069-176 CC-PA1N01 51410069-176 CC-PAINO1 51410069-176 CC-PAIN0I 5I4I0069-176 CC-PAIM01 51405045-175 CC-PAON01 51410070-175 CC-PAOX01 51405039-275
Technical notes
CC-PAIN01 51410069-176 is identified as a high-level G3 analog input module rated 150 mA at 24 VDC and 0°C to 60°C. Commissioning should retain the IOTA identity, channel allocation, loop-power arrangement, signal scaling, alarm limits, firmware and hardware revisions, and the complete 51410069-176 part number.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Why can a loop read incorrectly after installing CC-PAIN01 51410069-176?
Check the 4–20 mA range, 200 Ω input path, terminal polarity, field power, channel scaling, grounding, and control-database assignment.
How is the IOTA selected for CC-PAIN01 51410069-176?
Use CC-TAIN01 for the documented nonredundant arrangement or CC-TAIN11 where the cabinet is engineered for redundancy.
What should be recorded before replacing CC-PAIN01 51410069-176?
Capture the full part number, firmware and hardware revisions, IOTA, channel ranges, field tags, wiring, and cabinet slot.
How should noisy channels on CC-PAIN01 51410069-176 be investigated?
Compare affected channels, shields, commons, field power, grounding, source impedance, and configuration before replacing the module.
How is the non-HART boundary confirmed for CC-PAIN01 51410069-176?
The official module function is high-level 4–20 mA input without HART; HART requirements need a documented HART-capable IOM.
What should accompany a sourcing request for CC-PAIN01 51410069-176?
Provide the complete model and part number, photographed revisions, IOTA identity, redundancy requirement, and installed channel configuration.
