    Apter Power provides CC-PFB802 51454953-176 quotations, product manuals, and model matching.

CC-PFB802 51454953-176

/ 4.9
1001 reviews | Need a Specific Revision?
Honeywell CC-PFB802 51454953-176 is an Experion PKS FIM8 interface module that connects eight FOUNDATION Fieldbus H1 networks.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for CC-PFB802 51454953-176
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for CC-PFB802 51454953-176

  • Manufacturer:
    Honeywell
  • Part Number:
    CC-PFB802 51454953-176
  • Product Family:
    Honeywell Experion PKS ( C200, C300 )
  • Product Type:
    FIM8 FOUNDATION Fieldbus Interface Module
  • Stock:
    1
  • Fieldbus network capacity:
    Eight H1 networks
  • Controller platforms:
    C200, C200E, and C300
  • Control environment:
    Honeywell Control Execution Environment
  • Configuration scope:
    FIM hardware, field devices, and control modules
  • Fieldbus simulation:
    FIM8, H1 devices, and control strategies
  • Maintenance workflow:
    Like-device and unlike-device replacement with network troubleshooting
  • Tariff Code:
    85389091
  • Country of origin:
    Malaysia
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals H1 Network Controller Workflow Configuration Tasks Service Diagnostics

Features:

  • Connects eight FOUNDATION Fieldbus H1 networks through one FIM8 hardware interface.
  • Places fieldbus devices and controller control modules in the same Experion PKS configuration workflow.
  • Supports documented C200, C200E, and C300 controller fieldbus implementation tasks.
Honeywell CC-PFB802 51454953-176 provides the FIM8 hardware point between Experion PKS controllers and eight H1 fieldbus networks.

Each H1 network carries device data into the controller environment, where control modules can use those values and return configured control actions.

Hardware, devices, control strategies, simulation, and replacement tasks remain associated with the same fieldbus network definition.

The Honeywell CC-PFB802 51454953-176 FIM8 FOUNDATION Fieldbus Interface Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Honeywell CC-PFB802 51454953-176 FIM8 FOUNDATION Fieldbus Interface Module Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Eight-Segment Fieldbus Path

  • Segment organization: The FIM8 presents eight H1 network paths to the Experion PKS controller environment.
  • Device side: Fieldbus instruments are configured on the H1 networks rather than as direct controller I/O.
  • Control side: Controller control modules consume and act on values delivered through the fieldbus interface.
  • Network context: The H1 definition remains linked to its devices and control strategies during configuration.

Experion Control Association

  • Supported controllers: C200, C200E, and C300 controllers are included in the documented FIM workflow.
  • Execution environment: Fieldbus control strategies are built for the Control Execution Environment.
  • Point construction: Fieldbus points can be linked with cascaded controller-to-fieldbus points.
  • Loading sequence: Controller, FIM, device, and control-module configuration are built and loaded as related objects.

Build, Load, and Simulate

  • Hardware definition: The FIM8 hardware is configured before its H1 devices and strategies are loaded.
  • Device definition: Each fieldbus device remains attached to its assigned H1 network.
  • Strategy definition: Analog and digital control modules can use the configured fieldbus points.
  • Simulation path: The documented simulation includes FIM8, an H1 network, devices, and control modules.

Network Maintenance Decisions

  • Like replacement: A like field device can be replaced while retaining the established network definition.
  • Unlike replacement: An unlike device requires its changed device definition to be handled in the configuration.
  • Troubleshooting scope: Checks follow the FIM, H1 network, device, and controller-point path.
  • Configuration trace: Network and control definitions provide the reference for locating a fieldbus communication problem.
Description
Honeywell CC-PFB802 51454953-176 is the FIM8 FOUNDATION Fieldbus Interface Module for Experion PKS Series C control systems. It places eight H1 fieldbus networks under the controller environment so device data and control strategies can be handled through one fieldbus interface.

Across its H1 connections, Honeywell CC-PFB802 51454953-176 links field instruments with C200, C200E, or C300 control execution. Hardware definitions, fieldbus devices, and the control modules that use their signals are configured and loaded as parts of the same controller workflow.

During commissioning, Honeywell CC-PFB802 51454953-176 can be represented with its H1 network, devices, and control strategy in the documented fieldbus simulation workflow. The same configuration structure supports device replacement and troubleshooting without separating the network definition from the controller strategy.
Alternative Names
CC PFB802 51454953 176 CCPFB802 51454953176 Honeywell CC-PFB802 51454953-176 Honeywell FIM8 CC-PFB802 CC-PFB802 Fieldbus Interface Module 51454953-176 FIM8 Module CC-PF8802 51454953-176 CC-PFB8O2 51454953-I76
Technical notes
Honeywell CC-PFB802 51454953-176 identifies the FIM8 eight-segment FOUNDATION Fieldbus interface used with Experion PKS controllers.
