SSD-D08G-4300 51403645-400

/ 4.9
1001 reviews | Need a Specific Revision?
SSD-D08G-4300 51403645-400 is a Honeywell 8 gb industrial solid-state drive assembly used for Honeywell industrial control equipment requiring the exact SSD-D08G-4300 and 51403645-400 storage assembly.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for SSD-D08G-4300 51403645-400
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for SSD-D08G-4300 51403645-400

  • Manufacturer:
    Honeywell
  • Part Number:
    SSD-D08G-4300 51403645-400
  • Product Family:
    Honeywell Experion PKS ( C200, C300 )
  • Product Type:
    8 GB industrial solid-state drive assembly
  • Stock:
    1
  • Capacity:
    8 GB; 8,195,604,480 bytes and 16,007,040 sectors in the manufacturer capacity table
  • Interface:
    2.5-inch PATA with 44-pin IDE connector
  • Master/Slave selection:
    Master and Slave jumper positions are printed on the supplied product label
  • Supply:
    5.0 V ±10% for the SiliconDrive II 4300-series PATA drive
  • Reset-to-ready:
    200 ms typical, 400 ms maximum
  • Read transfer rate:
    34 MB/s typical
  • Write transfer rate:
    19 MB/s typical
  • Burst transfer rate:
    66 MB/s
  • MTBF:
    4,000,000 hours at 25 °C
  • Bit error rate:
    Less than one nonrecoverable error in 10^14 bits read
  • Commercial operating temperature:
    0–70 °C for the non-I SSD-D08G-4300 designation
  • Compliance:
    RoHS 6 of 6 compliant for the SiliconDrive II family
  • Tariff Code:
    8471701900
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Performance Reliability Data Protection Application
  • Provides 8 GB of solid-state storage in a 2.5-inch PATA drive format.
  • Uses a 44-pin IDE interface with visible Master and Slave selection markings.
  • Integrates PowerArmor, SiSMART and SiSecure technologies for embedded storage management.

SSD-D08G-4300 51403645-400 is a Honeywell 8 gb industrial solid-state drive assembly designed for its documented industrial platform or application.

The supplied label photographs confirm a Western Digital SiliconDrive II SSD-D08G-4300, 8 GB PATA device with Master/Slave selection. Honeywell part number 51403645-400 is retained as the user-supplied order number; it is not printed on the visible SSD label.

Before installation or replacement, verify the complete catalog number, compatible hardware, wiring, configuration and installed-system requirements.

Availability, condition, price, and shipping time for SSD-D08G-4300 51403645-400 are confirmed during quotation.

Honeywell SSD-D08G-4300 51403645-400 8 GB Industrial Solid-State Drive Assembly Manuals, Product Family, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Lists a 34 MB/s typical read transfer rate.
  • Lists a 19 MB/s typical write transfer rate.
  • Supports a 66 MB/s burst transfer rate with up to 2 ms controller overhead.
  • Specifies 4,000,000 hours MTBF at 25 °C.
  • Specifies fewer than one nonrecoverable error per 10^14 bits read.
  • Provides a commercial 0–70 °C operating range for the non-I model designation.
  • PowerArmor protects data against corruption or loss during power disturbances.
  • SiSMART monitors and reports remaining useful storage life.
  • SiSecure provides selectable protection, host binding, access control and secure-erasure functions.
  • Embedded industrial control systems requiring 2.5-inch PATA storage
  • Video-surveillance equipment using low-power embedded storage
  • Storage-networking equipment requiring solid-state PATA media
Description
SSD-D08G-4300 51403645-400 uses nonvolatile solid-state media for embedded storage tasks that require a 2.5-inch ATA device without the mechanical components of a rotating hard disk.

The SSD-D08G-4300 reaches ready status in 200 ms typically and 400 ms maximum. Manufacturer data specifies a typical read rate of 34 MB/s, a typical write rate of 19 MB/s and a burst-transfer rate of 66 MB/s.

The physical drive does not by itself confirm the presence of a bootable Honeywell system image, application files or licenses. Create and verify a recoverable image of the installed medium, confirm host BIOS support and retain the original drive until the controller starts and operates correctly from the replacement.
Alternative Names
SSD-D08G-4300 51403645-400 Honeywell SSD-D08G-4300 51403645-400 SSD-D08G-4300 Honeywell SSD-D08G-4300 51403645-400 Honeywell 51403645-400
Technical notes
SSD-D08G-4300 51403645-400 uses the user-supplied Honeywell order number; verify the target controller, carrier and preloaded image because SSD specifications alone do not establish system compatibility or bootability.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Which Honeywell controller is compatible with SSD-D08G-4300 51403645-400?
The reviewed official document does not identify this part, so compatibility must be confirmed from the target controller's bill of material, service documentation and the drive label.
Does SSD-D08G-4300 51403645-400 include a bootable Honeywell system image?
Do not assume it does. Confirm image content, software release, licensing and formatting in the quotation and maintain a verified backup before replacement.
Can a generic 8 GB drive replace SSD-D08G-4300 51403645-400?
No direct substitution is supported; interface, industrial qualification, mechanical fit, firmware behavior and preloaded image may all be system-specific.
What should be included with SSD-D08G-4300 51403645-400?
Assume only the exact labeled storage assembly is included unless the stock description explicitly lists a carrier, adapter, cable, software image or license.
What must be backed up before installing SSD-D08G-4300 51403645-400?
Back up the controller image, application data, licenses and recovery procedure applicable to the target Honeywell system before removing the existing medium.
Which physical checks are required before fitting SSD-D08G-4300 51403645-400?
Compare the exact part number, connector keying, mounting carrier and orientation with the removed unit, and apply antistatic handling throughout the exchange.
What should be checked if SSD-D08G-4300 51403645-400 is not recognized at startup?
Recheck connector seating, supply, controller compatibility, firmware or BIOS support and image preparation, then restore the known-good medium if the approved recovery procedure requires it.
