MU-TLPA02 51309204-125

/ 4.9
1001 reviews | Need a Specific Revision?
MU-TLPA02 51309204-125 is a power adapter module for LLMUX/SDI/SI systems, used for power distribution and signal connection within modular control cabinets.
Get a quick price for MU-TLPA02 51309204-125
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for MU-TLPA02 51309204-125

  • Manufacturer:
    Honeywell
  • Part Number:
    MU-TLPA02 51309204-125
  • Product Family:
    Honeywell Experion PKS ( C200, C300 )
  • Product Type:
    51309204-125
  • Input voltage range:
    85–265VAC
  • Output voltage:
    24VDC
  • Output current:
    25A
  • System compatibility:
    LLMUX / SDI / SI series (Honeywell)
  • Connection types:
    Screw and compression terminals available
  • Weight:
    0.3 kg
  • Estimated shipping dimensions:
    15.1x12x5cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.
Description
Model MU-TLPA02-51309204-125 is a power adapter board for Low-Level Multiplexed (LLMUX) / SDI / SI systems in Honeywell systems.

This module converts and distributes power or signals within the system control cabinet to Low-Level Analog Input Multiplexers (LLMUX) or SDI/SI modules. It is used in Honeywell's Experion series or Series 8 control hardware to support reliable power supply and connection between rack-mounted modules and the control unit. This module features a wide input voltage range (85-265VAC), a 24VDC output, and an output current up to 25A.
Alternative Names
FC-PDB-ARTF05 FTA-T-02 FC-TPSU-2430 T921D-1008 TC-IXR061 TK-PRS021
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is the input voltage range of the MU-TLPA02?
The module supports a wide input voltage range of 85–265VAC, adaptable to various industrial power grid environments, without the need for an additional voltage converter.
What are the output current and voltage?
The output is 24VDC, with a maximum output current of up to 25A, capable of powering multiple LLMUX or SDI/SI modules simultaneously.
Which Honeywell systems is this module compatible with?
Compatible with LLMUX (Low Level Multiplexer), SDI (Serial Data Interface), and SI (Signal Interface) series modules, suitable for Experion or Series 8 control racks.
What are the installation methods and interface types?
The module connects via screw terminals or crimp terminals and is installed in a control cabinet. It supports standard industrial DIN rail wiring for easy field installation and maintenance.
