Ask our team:
  • Phone: +86 181 0690 9650
  • E-Mail sales1@apterpower.com
  • Lifecycle status

    Active / Available from OEM
    Apter Power provides quotations, chassis review, official documentation, and procurement support for this power unit.

FC-PSU-240516 V1.1

/ 4.9
1001 reviews | Need a Specific Revision?
Honeywell FC-PSU-240516 V1.1 is a conformal-coated 24/5 VDC, 16 A power supply unit for the Safety Manager controller chassis.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for FC-PSU-240516 V1.1
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for FC-PSU-240516 V1.1

  • Manufacturer:
    Honeywell
  • Part Number:
    FC-PSU-240516 V1.1
  • Product Family:
    Honeywell Safety Systems
  • Product Type:
    24/5 VDC 16 A Power Supply Unit
  • Stock:
    1
  • Input Voltage:
    24 VDC, -15% to +30%
  • Input Current:
    Less than 6 A at 24 VDC
  • Low-Line Input Current:
    Less than 7 A at 20.4 VDC
  • Inrush Current:
    Less than 5 A
  • Output Voltage:
    5 VDC
  • Maximum Output Current:
    16 A
  • Hold-Up Time:
    Less than 1 ms
  • Operating Temperature:
    -5 to 70 C
  • Storage Temperature:
    -40 to 85 C
  • Relative Humidity:
    10-95%, non-condensing
  • Coating:
    Conformal coated
  • Version Note:
    V1.1 component update with no functional change
  • Weight:
    0.85 kg
  • Estimated shipping dimensions:
    17.6 x 3.52 x 21.2 cm
  • Tariff Code:
    Please confirm the destination before shipping
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Chassis Power Environment Review Ordering Review

Features:

  • Power conversion: 24 VDC input to regulated 5 VDC output.
  • Output capacity: Maximum 16 A load in the controller chassis.
  • Version status: V1.1 changes components without a functional change.

FC-PSU-240516 V1.1 supplies the Safety Manager controller chassis from a 24 VDC source.

Input capacity, output loading and environmental limits should be checked in the installed cabinet.

The V1.1 marking and conformal-coated hardware identity should be confirmed before replacement.

Availability is subject to Apter Power's current inventory and sourcing confirmation.

Verified resources for Honeywell FC-PSU-240516 V1.1:

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

General

  • ManufacturerHoneywell
  • ModelFC-PSU-240516 V1.1
  • ConditionNew Original ready stock
  • Product FamilyHoneywell Safety Manager Power Supplies

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Chassis Power

  • Input range: Maintain 24 VDC within the documented tolerance.
  • Output load: Keep the 5 V demand within 16 A.
  • Chassis position: Use the approved Safety Manager location.

Environment Review

  • Temperature: Maintain the documented operating range.
  • Humidity: Prevent condensation within the specified range.
  • Airflow: Keep controller-chassis cooling paths clear.

Ordering Review

  • Version: Confirm FC-PSU-240516 V1.1.
  • Coating: Match the conformal-coated requirement.
  • Power record: Compare input and load documentation before acceptance.
Description
The FC-PSU-240516 V1.1 is a conformal-coated Honeywell Safety Manager power supply unit that converts a 24 VDC input to a regulated 5 VDC output rated up to 16 A.

Official documentation for FC-PSU-240516 V1.1 identifies modified components relative to the earlier hardware version without a functional change and specifies installation in the controller chassis.

Before ordering FC-PSU-240516 V1.1, verify the complete version marking, chassis position, input supply, and approved Honeywell Safety Manager hardware records.
Alternative Names
Honeywell FC-PSU-240516 V1.1 Honeywell Safety Manager FC-PSU-240516 V1.1 power supply Honeywell FC-PSU-240516 FC-PSU-240516 FC PSU 240516 V1.1 FCPSU240516 V11 Safety Manager 24/5 VDC power supply
Technical notes
FC-PSU-240516 V1.1 is a conformal-coated Safety Manager power supply converting 24 VDC input to regulated 5 VDC output up to 16 A. Verify the V1.1 marking, controller-chassis position, input protection, ventilation, and approved Honeywell hardware records before replacement; an earlier-looking version must not be assumed equivalent from appearance alone.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Before selecting FC-PSU-240516 V1.1, which chassis and version details must match?
Match the V1.1 marking, conformal coating, approved Safety Manager controller-chassis position, connector condition, 24 VDC source, and installed hardware records.
What does the official version note mean for FC-PSU-240516 V1.1 replacement planning?
Honeywell identifies a component update with no functional change, but the installed version, chassis approval, connector condition, and project documentation still require confirmation.
Why should chassis input voltage be measured directly at FC-PSU-240516 V1.1?
The approved 24 VDC source must remain within minus 15% to plus 30% at the module under load; a reading taken only at the source can miss polarity, wiring, protection, or voltage-drop faults at the chassis.
Operation of FC-PSU-240516 V1.1 approaches 70 C; which environmental conditions require review?
Keep operation within minus 5 to 70 C and 10-95% non-condensing relative humidity, while maintaining chassis airflow and checking load current when abnormal heating occurs.
Can FC-PSU-240516 V1.1 be installed in any Safety Manager chassis position?
No. Use only the controller-chassis position approved by the Honeywell hardware documentation and preserve the original connector and power-distribution arrangement.
How should the 5 VDC load be assessed before installing FC-PSU-240516 V1.1?
Confirm that the controller-chassis demand remains within the documented 16 A output and review source capacity, connector condition, and power-distribution records.
After installing FC-PSU-240516 V1.1, what Safety Manager checks demonstrate correct operation?
Verify stable 5 VDC output within the documented 16 A capacity, normal chassis diagnostics, acceptable module temperature, and successful controller startup under the approved Safety Manager procedure.
