    Honeywell hardware references list FC-IOCHAS-0001R for conformal-coated redundant Safety Manager I/O configurations.

FC-IOCHAS-0001R

/ 4.9
1001 reviews | Need a Specific Revision?
FC-IOCHAS-0001R is a conformal-coated redundant i/o chassis for Honeywell Safety Manager systems.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for FC-IOCHAS-0001R
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for FC-IOCHAS-0001R

  • Manufacturer:
    Honeywell
  • Part Number:
    FC-IOCHAS-0001R
  • Product Family:
    Honeywell Safety Systems
  • Product Type:
    Redundant I/O chassis
  • Stock:
    1
  • Configuration:
    Redundant Safety Manager I/O chassis
  • Rack format:
    19-inch, 21-slot housing
  • I/O capacity:
    Up to 9 redundant module pairs
  • I/O slots:
    Slots 1–18 used in odd/even pairs
  • Extender positions:
    IO-0001 in slots 20 and 21
  • Dimensions:
    482.6 mm wide × 280 mm deep
  • Approximate weight:
    8.5 kg
  • Coating:
    Conformal-coated FC version
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Safety & Compliance Performance & Efficiency

Product overview:

  • Conformal-coated redundant 19-inch I/O chassis
  • Nine paired I/O positions
  • Separate extender modules for processor paths 1 and 2

FC-IOCHAS-0001R provides the mechanical and backplane structure for redundant Safety Manager I/O modules in a conformal-coated configuration.

The odd/even slot arrangement is fixed by the redundant architecture, and slot 19 remains unavailable for an I/O module.

Verified resources for FC-IOCHAS-0001R:

Verified specifications for FC-IOCHAS-0001R:

  • Configuration: Redundant Safety Manager I/O chassis
  • Rack format: 19-inch, 21-slot housing
  • I/O capacity: Up to 9 redundant module pairs
  • I/O slots: Slots 1–18 used in odd/even pairs
  • Extender positions: IO-0001 in slots 20 and 21
  • Dimensions: 482.6 mm wide × 280 mm deep
  • Approximate weight: 8.5 kg
  • Coating: Conformal-coated FC version

Typical applications:

  • Conformal-coated redundant I/O cabinets
  • Paired Safety Manager input and output modules
  • Industrial process-safety system expansion

The chassis is selected when both redundant I/O topology and conformal-coated hardware are required by the project specification.

Safety and compliance:

  • Documented approvals: CE, UL, CSA, TÜV and FM
  • Dedicated processor path for each side of a module pair
  • Fixed empty position at slot 19

Maintain the approved paired-module map and verify all chassis, extender and power connections before returning the safety system to service.

Performance and efficiency:

  • Capacity for nine redundant I/O pairs
  • 35 mA extender load on each 5 V path
  • Conformal-coated 19-inch mechanical assembly

The chassis organizes redundant field channels efficiently while preserving the two independent I/O communication paths.

Description

FC-IOCHAS-0001R is a conformal-coated redundant i/o chassis for the Honeywell Safety Manager platform. This conformal-coated chassis provides 21 positions for redundant Safety Manager I/O, including paired slots 1 through 18 and IO-0001 extender locations in slots 20 and 21.

FC-IOCHAS-0001R routes the odd and even I/O positions to separate processor paths and is intended for projects that specify conformal-coated hardware. Confirm rack dimensions, paired module allocation, redundant bus assemblies, power distribution and project approvals before installation.

Alternative Names
FC-IOCHAS-0001R FC IOCHAS 0001R Honeywell FC-IOCHAS-0001R Honeywell FC IOCHAS 0001R Safety Manager FC-IOCHAS-0001R FC-IOCHAS-0001R Redundant I/O chassis FCIOCHAS0001R Redundant I/O chassis Honeywell Safety Manager FC-IOCHAS-0001R
Technical notes
FC-IOCHAS-0001R is the conformal-coated redundant 19-inch I/O chassis for up to nine Safety Manager module pairs. The two IO-0001 extenders occupy slots 20 and 21.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How is FC-IOCHAS-0001R integrated into a Safety Manager configuration?
Use it in a redundant Safety Manager architecture with paired I/O modules, two IO-0001 modules and the matching FC-compatible project hardware.
Which technical interfaces or ratings define FC-IOCHAS-0001R?
The key documented points are Configuration: Redundant Safety Manager I/O chassis; Rack format: 19-inch, 21-slot housing; I/O capacity: Up to 9 redundant module pairs; I/O slots: Slots 1–18 used in odd/even pairs. Confirm these values against the installed chassis and project hardware list.
Which compatibility checks are required before installing FC-IOCHAS-0001R?
Verify conformal-coating requirements, module pair allocation, backplane revision, bus cables, two extender modules, power system and rack dimensions.
Which slot, bus position or chassis location is specified for FC-IOCHAS-0001R?
Install it in a 19-inch cabinet, observe the required rack-unit spacing and fit IO-0001 modules in slots 20 and 21 with slot 19 empty.
What diagnostic symptoms can indicate a FC-IOCHAS-0001R connection or hardware problem?
An incorrect slot map, extender position, backplane connection or power distribution in FC-IOCHAS-0001R can interrupt several I/O channels or defeat the intended redundant/non-redundant architecture. Check the affected slot group and processor path first.
Can FC-IOCHAS-0001R replace a related FS, FC, S or R version directly?
Replace only after confirming the redundant chassis and FC coating requirement; an S chassis or FS construction is not automatically interchangeable.
Which commissioning checks should be completed after fitting FC-IOCHAS-0001R?
Confirm chassis address, module slot allocation, IO-0001 position, backplane and horizontal-bus type, 5 V supply path and controller diagnostics after installation.
Which engineering data is needed to match and quote FC-IOCHAS-0001R?
Provide the complete FC-IOCHAS-0001R reference, controller and chassis type, Safety Manager release, slot or bus arrangement, coating requirement, existing hardware revision, required quantity and project approval requirements.
