51109693-100B

/ 4.9
1001 reviews | Need a Specific Revision?
This 51109693-100B serves as a critical network connectivity component that enables signal distribution and grounding management across the Universal Control Network (UCN).
Get a quick price for 51109693-100B
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 51109693-100B

  • Manufacturer:
    Honeywell
  • Part Number:
    51109693-100B
  • Product Family:
    Honeywell TPS Series
  • Product Type:
    4-Port UCN Tap Kit
  • Network Architecture:
    Universal Control Network (UCN)
  • Port Configuration:
    2 to 4-Port Tap Cable Branching
  • Functionality:
    Signal Distribution, Grounding Management, and Network Termination
  • Integrated Components:
    Built-in Termination Resistors (Terminators)
  • Mounting Type:
    In-line or Cabinet Mounting within DCS infrastructure
  • Weight:
    0.24 kg
  • Estimated shipping dimensions:
    12.0 cm x 9.8 cm x 4.0 cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Communication & Connectivity Installation & Integration

Features:

  • Signal Distribution Node Between the UCN Network Trunk and Field Instrumentation
  • Merges Multi-Port Cable Branching with Integrated Termination and Grounding Protection
  • Functions Within Honeywell TDC 2000, TDC3000, and TPS Distributed Control System Environments
The 51109693-100B serves as the 4-Port UCN Tap Kit in a Honeywell DCS network, providing reliable signal distribution and grounding management to all connected nodes across the Universal Control Network. It physically branches the UCN bus cable to support 2 to 4 connector ports and routes communication signals through the network backbone to enable steady state operation of all controllers, operator stations, and process I/O modules. Proper network termination is standard with the 51109693-100B, as the integrated terminators ensure signal integrity by preventing reflections at branch points. The 51109693-100B has made improvements in several areas over previous tap designs in addition to incorporating grounding protection within the UCN network architecture.

The 51109693-100B provides essential network connectivity functions common to the entire UCN segment, and is a critical component of the communication path, directly affecting the proper, normal operation of the overall control system. One or more 51109693-100B tap kits are required per UCN segment depending on the desired node count and physical layout. The 51109693-100B is typically mounted at strategic branching points along the UCN cable route to facilitate multi-point connections between the network trunk and field devices, occupying minimal physical space within the installation enclosure.

For expanded network applications, the UCN system requires additional 51109693-100B tap kits installed at subsequent branch points. In addition to standard single-tap operation, the distributed configuration also maintains proper signal distribution across all connected ports. The UCN network architecture executes communication routing using the integrated terminators built into the 51109693-100B design. Using this method, the network infrastructure ensures impedance matching across all branch points. If maintenance personnel determine that a network segment is no longer providing stable communication (outside configured impedance/tolerance levels), they can inspect the 51109693-100B terminators and grounding connections to restore proper network operation and record the corrective action in the system maintenance log.

The 51109693-100B Honeywell  4-Port UCN Tap Kit may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Honeywell 51109693-100B 4-Port UCN Tap Kit Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Honeywell 51109693-100B 4-Port UCN Tap Kit Specs

General

  • Manufacturer Honeywell
  • Model 51109693-100B
  • Condition New Original ready stock
  • Product Family 51402573-250,51404305-375,51201395-100
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • DCS Network Expansion: Used specifically in Honeywell TDC 3000 and Experion PKS (with UCN bridge) systems to expand the number of physical nodes on a single network segment.
  • Industrial Process Control: Deployed in environments requiring non-stop operation, such as Oil & Gas Refineries, Chemical Processing Units, and Power Generation Plants.
  • Signal Integrity Management: Applied in scenarios where long cable runs and multiple device connections risk signal degradation; the tap ensures clean branching and impedance matching.
  • Protocol Support: Designed for the UCN 5 Mbps Token Bus protocol, ensuring deterministic data exchange between controllers.
  • Multi-Port Branching: Provides 2 to 4-port connectivity, allowing the main UCN trunk (backbone) to "tap" into individual drop cables that lead to Process Managers (PM), Advanced Process Managers (APM), or High-Performance Process Managers (HPM).
  • EMI/RFI Protection: Serves as a Ground Tap, protecting the communication signal from electromagnetic interference and preventing ground loops that could lead to network-wide failures.
  • Mounting: Typically installed in marshalling cabinets or standard 19-inch racks where the UCN trunk cable is routed. Its compact footprint (12cm x 9.8cm) allows for dense installation.
  • Termination: The 51109693-100B often functions as a network endpoint or midpoint. It must be integrated with proper terminators (often part of the 51201395-100 kit) to prevent signal reflection.
  • Cabling Requirements: Requires high-quality coaxial drop cables. During installation, engineers must ensure the grounding screw is securely bonded to the cabinet's common ground bus to maintain the "Ground Tap" functionality.
  • Seamless Integration: As a passive electrical component, it does not require software configuration but must be physically verified during network commissioning using a signal analyzer to ensure low decibel (dB) loss across the ports.
Description
The Honeywell 51109693-100B is a specialized Ground Tap and Universal Control Network (UCN) Connector designed for high-performance industrial automation environments. As a critical component within the Honeywell TDC 3000 and Experion PKS ecosystems, the 51109693-100B facilitates reliable 2-4 port connections for UCN drop cables.

This Honeywell 51109693-100B is specifically designed to handle the challenge of signal integrity and electrical grounding in complex Distributed Control Systems (DCS). In large-scale industrial plants, electromagnetic interference and improper grounding can lead to data corruption or hardware damage across the network. The 51109693-100B solves this problem by providing a dedicated, stable grounding point and a secure interface for UCN drop cables, ensuring that communication signals remain clean and consistent between the process controllers and the main network trunk.

In practical application scenarios, the Honeywell 51109693-100B is frequently deployed in oil refineries, chemical processing plants, and power generation facilities where continuous UCN uptime is mandatory. For instance, when expanding a control network to include new I/O modules, the 51109693-100B is used to tap into the existing coaxial bus, effectively managing the transition from the primary trunk to individual device drops. By utilizing the 51109693-100B, engineers can prevent impedance mismatches and reduce the risk of ground loops, thereby maintaining the overall health of the automation infrastructure.
Alternative Names
51402573-250 51404305-375 51201395-100 51199929-100
Technical notes
The 51109693-100B provides 2 to 4-port UCN connector tap cable branching functionality, incorporating built-in terminators to ensure proper network termination and prevent signal reflection issues that could compromise communication reliability.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is the primary function of the 51109693-100B?
The 51109693-100B provides UCN connector tap cable branching functionality, allowing multiple devices to connect to the network backbone. It supports 2 to 4-port distribution and includes built-in terminators, ensuring proper signal routing and stable communication across industrial control systems.
Why are built-in terminators important in the 51109693-100B?
Built-in terminators ensure correct network termination, which is essential for preventing signal reflection along the communication bus. Without proper termination, reflected signals can disrupt network performance and reduce reliability. By integrating these terminators directly into the tap kit, the 51109693-100B simplifies installation and improves overall system stability.
How does the 51109693-100B assist with system expansion?
By providing strategic tap points along the UCN bus, the 51109693-100B allows new controllers, operator stations, and I/O modules to be added to existing network segments. This makes it highly valuable for retrofit projects and phased system upgrades, where scalability is essential.
