The Honeywell MC-PDIY22 (80363972-150) is a 32-channel digital input processor module designed to acquire 24 V d.c. switching signals in industrial control systems. It is widely associated with Honeywell TDC 2000 and TDC 3000 architectures for reliable signal monitoring from field devices.
Get a quick price for MC-PDIY22 80363972-150
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for MC-PDIY22 80363972-150

  • Manufacturer:
    Honeywell
  • Part Number:
    MC-PDIY22 80363972-150
  • Product Family:
    Honeywell TPS Series
  • Product Type:
    Digital Input 24 Vdc Processor Module
  • Number of channels:
    32
  • Input type:
    Form A dry contact
  • Input voltage:
    24VDc nominal
  • Input current:
    2mA maximum per channel
  • Isolation:
    1500v between channels and power supply
  • Mounting:
    DIN rail mountable
  • Non CE Compliant Part Number:
    N/A
  • Compatibility:
    Honeywell's TDC 2000 and TDC 3080 control systems
  • Weight:
    0.58 kg
  • Estimated shipping dimensions:
    3x31.8x28cm
  • Tariff Code:
    3926909090
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Compatibility Efficiency Application Scenarios

Features:

  • High-density 32-channel architecture enables multi-signal acquisition in compact control systems
  • Electrical isolation design ensures stable operation between field inputs and system power
  • Standard 24 V d.c. dry contact interface supports industrial switching signal integration
The Honeywell MC-PDIY22 80363972-150 is designed as a digital input processor module for industrial control systems requiring reliable acquisition of switching signals. It operates with 24 V d.c. nominal input and supports Form A dry contact interfaces, making it suitable for standard field device connections. The Honeywell MC-PDIY22 80363972-150 is commonly associated with Honeywell TDC 2000 and TDC 3000 control environments.

In distributed control applications, the Honeywell MC-PDIY22 80363972-150 provides 32 independent input channels, enabling multiple process signals to be monitored simultaneously. This structure allows efficient data collection from switches, relays, and other discrete devices in industrial systems. The module’s isolation design ensures stable operation even when exposed to electrical noise and varying field conditions.

The Honeywell MC-PDIY22 80363972-150 is also designed for standardized cabinet integration using DIN rail mounting. Its low input current requirement and defined isolation characteristics support stable long-term operation in control system architectures. With dual identification under MC-PDIY22 and 80363972-150, it serves as a widely used interface module in legacy Honeywell DCS installations.

The MC-PDIY22 80363972-150 Honeywell Digital Input 24 Vdc Processor Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
