MU-TAOX02 51304476-125

/ 4.9
1001 reviews | Need a Specific Revision?
Honeywell MU-TAOX02 51304476-125 is a CE-compliant, eight-channel analog output FTA with compression terminals. The Size A assembly supports HPM and APM analog output I/O.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for MU-TAOX02 51304476-125
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for MU-TAOX02 51304476-125

  • Manufacturer:
    Honeywell
  • Part Number:
    MU-TAOX02 51304476-125
  • Product Family:
    Honeywell TPS Series
  • Product Type:
    Analog Output Field Termination Assembly (FTA)
  • Stock:
    1
  • Number of Channels:
    8
  • Output Signal Type:
    4-20 mA (standard analog)
  • Maximum Load Resistance:
    750 Ω
  • Supply Voltage:
    24 Vdc
  • Current Consumption:
    160 mA (all channels active at 20 mA)
  • Power Dissipation:
    9.6 W (typical, full load)
  • Number of 50-pin IOP Connectors:
    2
  • Weight:
    0.485 lbs (0.22 kg)
  • Estimated shipping dimensions:
    15.2x12.8x5.5cm
  • Tariff Code:
    8471499100
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Performance Operating Environment

Features:

  • 8 Independent Analog Outputs
  • Support for IOP Redundancy
  • Built-in Manual Station Interface
The Honeywell MU-TAOX02 51304476-125 provides eight discrete 4-20 mA channels, each capable of driving process loads up to 750 Ω, delivering precise analog control.

With two onboard IOP connectors, The Honeywell MU-TAOX02 51304476-125 can be wired to both primary and secondary IOPs, ensuring bumpless transfer and uninterrupted loop control during a primary IOP failure.

A dedicated 50-pin connector on The Honeywell MU-TAOX02 51304476-125 allows direct connection to a Standby Manual Device, enabling operators to manually override and control the output loop independently of the IOP for maintenance or emergency scenarios.

The MU-TAOX02 51304476-125 Honeywell 8-channel, Size A Analog Output Field Termination Assembly (FTA) may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Verified resources for Honeywell MU-TAOX02 51304476-125:Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Honeywell MU-TAOX02 51304476-125 8-channel, Size A Analog Output Field Termination Assembly (FTA)

General

  • Manufacturer Honeywell
  • Model MU-TAOX02 51304476-125
  • Condition New Original ready stock
  • Product Family MU-TAOX12,MU-TAOX12,MU-TAOX12
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Routes eight analog output channels from Process Manager hardware to final control elements.
  • Supports current commands for compatible valves, I/P converters, positioners, and actuators.
  • Fits TDC 3000 or TPS installations that use the documented size-A FTA arrangement.
  • Eight dedicated output circuits preserve the channel assignments defined by the connected IOP.
  • Compression terminals provide the documented field connection method for the CE configuration.
  • Stable loop operation depends on correct load, shielding, grounding, and channel mapping.
  • The open FTA relies on its control cabinet for ingress and contamination protection.
  • Maintain the cabinet environment, terminal cleanliness, shielding, and protective grounding required by the system.
  • Do not claim a stand-alone IP rating for the board assembly.
Description
The Honeywell MU-TAOX02 51304476-125 serves as a critical interface between a Honeywell HPM system’s Analog Output IOP and field actuators. It accepts digital commands from the IOP and converts them into industry-standard 4-20 mA analog signals, capable of driving loads up to 750 Ω. This FTA is classified as a Size A assembly (152.4 mm x 120.7 mm) and utilizes compression-type terminal connectors for secure field wiring terminations.

Designed for high-availability applications, The Honeywell MU-TAOX02 51304476-125 supports redundant IOP configurations via two dedicated 50-pin connectors. It also features a dedicated connector for an optional Analog Output Standby Manual Device, enabling manual loop control during IOP maintenance or failure. This design ensures continuous operation of critical control loops.

The part number The Honeywell MU-TAOX02 51304476-125 specifically denotes the CE-compliant version of this FTA, identifiable by the "-125" suffix on the part number. In contrast, the "-100" suffix denotes the non-CE compliant version. This component requires 24 Vdc power, drawing 160 mA, and dissipates approximately 9.6 W of power under full load, making it a fundamental building block for reliable analog output control in TDC 3000/TPS systems.
Alternative Names
MU TAOX02 51304476-125 MU-TAOX02 51304476 125 MU TAOX02 51304476 125 MU-TAOX02 51304476-125
Technical notes
Preserve the compression-terminal wiring map when exchanging MU-TAOX02 51304476-125; the eight output circuits must return to their original Process Manager channel assignments.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What channel arrangement belongs to Honeywell MU-TAOX02 51304476-125?
It is an eight-channel Process Manager analog-output FTA, not a 16-channel Series C IOTA.
How are field conductors landed on Honeywell MU-TAOX02 51304476-125?
The -125 version uses compression terminals and the documented size-A FTA mounting format.
Which devices can Honeywell MU-TAOX02 51304476-125 command?
It routes analog output signals to compatible control valves, I/P converters, positioners, and other final control elements.
What does the -125 ending identify for Honeywell MU-TAOX02 51304476-125?
It identifies the CE-compliant order configuration in the Process Manager FTA selection tables.
What must be mapped before Honeywell MU-TAOX02 51304476-125 is exchanged?
Record all eight channel assignments, terminal numbers, cable identity, loop load, shielding, and the connected output IOP.
What belongs in a Honeywell MU-TAOX02 51304476-125 RFQ?
Include the full part number, FTA and IOP photos, terminal type, required condition, quantity, destination, and delivery date.
