AC1335

/ 4.9
1001 reviews | Need a Specific Revision?
ifm AC1335 is a SmartLink DP gateway combining one AS-i 2.1 master with a PROFIBUS DP slave interface. It links as many as 62 A/B slaves to a higher-level fieldbus while providing local display and diagnostics.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for AC1335
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for AC1335

  • Manufacturer:
    Ifm
  • Part Number:
    AC1335
  • Product Family:
    SmartLink DP AS-i Gateway
  • Product Type:
    AS-Interface PROFIBUS Gateway
  • Stock:
    1
  • AS-i master generation:
    AS-i 2.1
  • AS-i master count:
    1
  • Maximum AS-i slaves:
    62 A/B slaves
  • AS-i profile:
    M3
  • Fieldbus role:
    PROFIBUS DP slave
  • PROFIBUS data rate:
    9.6 kbit/s to 12 Mbit/s
  • Supply source:
    AS-i network
  • Operating voltage:
    26.5 to 31.6 V DC
  • Current consumption:
    Less than 0.2 A
  • Display:
    128 x 64 pixel backlit graphic LCD
  • Local controls:
    4 keys
  • Status indication:
    4 LEDs
  • Service interface:
    RS-232 via RJ11
  • RS-232 rate:
    9600 to 115200 bit/s
  • Mounting:
    35 mm DIN rail
  • Housing material:
    Aluminium
  • Degree of protection:
    IP20
  • Operating temperature:
    0 to 60 °C
  • Storage temperature:
    -20 to 70 °C
  • Estimated shipping dimensions:
    68 x 85 x 138 mm
  • Tariff Code:
    Please confirm the destination before shipping.
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Applications Communication Diagnostics Configuration

Features:

  • Controls one AS-i network while acting as a PROFIBUS DP slave toward the plant controller.
  • Displays network states and diagnostic information on a backlit local graphic screen.
  • Supports both standard slaves and extended A/B addressing within the AS-i 2.1 architecture.
The ordered unit is the single-master SmartLink DP version with integrated local operation.

It concentrates sensor and actuator data from the AS-i cable into the PROFIBUS process image.

Commissioning should begin with the saved bus address, GSD assignment and slave configuration from the existing station.

Apter Power can review sourcing, documentation and system matching for AC1335.
Verified resources for ifm AC1335: Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Packaging machines can collect distributed binary field signals on one AS-i segment and forward them to a PROFIBUS controller.
  • Conveyor zones use the gateway to combine compact actuator networks with established DP-based line control.
  • Service teams can inspect slave faults locally before opening controller engineering software.
  • PROFIBUS DP exchanges cyclic plant data at selectable rates up to 12 Mbit/s.
  • The AS-i master addresses as many as 62 extended A/B nodes on one network.
  • A front-access RS-232 port supports service communication from 9600 to 115200 bit/s.
  • The graphic LCD presents configuration and fault information without requiring an external display.
  • Four status LEDs provide immediate indication of gateway and bus operating states.
  • Keypad navigation allows maintenance personnel to inspect the connected AS-i system locally.
  • Controller integration uses the device description and the selected PROFIBUS station address.
  • Extended-address operation must match the A/B assignments already stored for the field nodes.
  • A saved slave list reduces commissioning risk when replacing a gateway in an operating machine.
Description
AC1335 consolidates one AS-Interface segment and a PROFIBUS DP connection in a 68 mm DIN-rail housing. The gateway is powered from the AS-i supply and presents status through a 128 x 64 backlit graphic display, four keys and four LEDs.

Its AS-i master manages standard and extended-address slaves while PROFIBUS transfers cyclic process data to the controller. An RS-232 service interface supports local commissioning and diagnostic access without changing the field wiring.

Network design must retain the AS-i voltage window, bus profiles and PROFIBUS transmission limits. Replacement work should also preserve the GSD-based controller configuration, station address and the existing A/B slave allocation.
Alternative Names
AC1335 ifm AC1335 IFM AC 1335 IFM-AC1335 AC1335 SmartLink DP ifm SmartLink DP AC1335 AC1335 AS-i Gateway AC1335 PROFIBUS Gateway
Technical notes
For AC1335 replacement, preserve the PROFIBUS address and AS-i slave map before disconnecting the original gateway.
