  • Lifecycle status

    Discontinued / Obsolete by OEM
    Product manuals, quotations and SIMOREG identification support for 6RY1703-0EA01 are available from Apter Power.

6RY1703-0EA01

/ 4.9
1001 reviews | Need a Specific Revision?
Siemens 6RY1703-0EA01 is a SIMOREG DC-MASTER field-supply spare for systems rated from 850 A.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 6RY1703-0EA01
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 6RY1703-0EA01

  • Manufacturer:
    Siemens
  • Part Number:
    6RY1703-0EA01
  • Product Family:
    Siemens SIMOREG DC-MASTER
  • Product Type:
    Field Supply Spare
  • Stock:
    1
  • Official Supply Scope:
    Field supply from 850 A
  • Spare Classification:
    Customer-specific engineered spare
  • Board Marking:
    C98043-A7004-L1
  • Converter Arrangement:
    Type D
  • Armature Current Classes:
    900–1200 A; 1500–2000 A
  • Field Current Classes:
    30 A; 40 A
  • Resistor Array:
    R1–R8, each 0R04
  • Adjustment Function:
    P051=22 internal offset adjustment
  • Weight:
    1.102 lbs (0.5 kg)
  • Estimated shipping dimensions:
    28×15.7×3.2 cm
  • Tariff Code:
    8537101190
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Order Identity Current-Class Match Hardware References Commissioning Check

Features:

  • Identifies a customer-specific field-supply spare for ratings from 850 A.
  • Links the 6RY order reference to C98043-A7004-L1 field-board hardware.
  • Retains two documented Type D armature-to-field current pairings.
The complete 6RY1703-0EA01 suffix is the purchasing identity used to separate this spare from adjacent 6RY1703 configurations.

Its board-level identifiers provide a second check when the order label and the installed circuit board are compared.

Commissioning work includes the internal offset function after the field-board hardware is changed.

The Siemens 6RY1703-0EA01 Field Supply Spare may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Siemens 6RY1703-0EA01 SIMOREG Field Supply Spare Manuals, Datasheets, Links Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Spare-Code Verification

  • Order number: The complete spare reference is 6RY1703-0EA01.
  • Supply scope: The entry covers field supplies from 850 A.
  • Hardware code: The associated field-board marking is C98043-A7004-L1.
  • Match rule: Ordering and board identities should be recorded together.

Type D Rating Pairs

  • First armature band: 900–1200 A is associated with the 30 A field level.
  • Second armature band: 1500–2000 A is associated with the 40 A field level.
  • Board family: Both pairs belong to the A7004-L1/-L2 grouping.
  • Review point: The installed armature rating decides which field level applies.

Board-Level Cross-Checks

  • Switching devices: The field-board arrangement designates V7 and V8.
  • Resistor positions: Eight positions are numbered R1 through R8.
  • Resistor value: Every position in that array is identified as 0R04.
  • Connector reference: X102 provides the named board interface.

Offset-Adjustment Sequence

  • Function selection: Set P051 to 22 for the internal offset adjustment.
  • Procedure timing: Run the step after changing the associated field board.
  • Configuration limit: Do not transfer settings from another 6RY1703 suffix.
  • Identification record: Preserve the complete order and board codes before commissioning.
Description
Siemens 6RY1703-0EA01 is the customer-specific field-supply spare identified for ratings from 850 A within the SIMOREG DC-MASTER range. The ordering number distinguishes the spare configuration from the board code carried on its field-board hardware.

The hardware associated with 6RY1703-0EA01 uses the C98043-A7004-L1 identification and the A7004-L1/-L2 Type D arrangement. That arrangement pairs 900–1200 A armature current with a 30 A field and 1500–2000 A armature current with a 40 A field, while the eight resistors R1–R8 are each 0R04.

For identification of 6RY1703-0EA01, the complete 6RY ordering code is recorded together with the C98043-A7004-L1 board marking and the installed current class. Field-board work is followed by the P051=22 internal offset adjustment, which sets the zero point of the field-current sensing path.
Alternative Names
6RY17030EA01 6RY1703 0EA01 6RY 1703-0EA01 Siemens 6RY1703-0EA01 SIMOREG 6RY1703-0EA01 6RY1703-0EA01 Field Supply C98043-A7004-L1 6RYI703-0EA01
Technical notes
Siemens 6RY1703-0EA01 identifies the 850 A-and-above field-supply spare; verify the complete order code and C98043-A7004-L1 board marking together.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Why can the order label and the printed board code differ on 6RY1703-0EA01?
The 6RY1703-0EA01 reference identifies the spare order, while C98043-A7004-L1 is the corresponding field-board hardware marking.
A record says only “field supply from 850 A.” What is still missing for 6RY1703-0EA01?
Add the complete 6RY1703-0EA01 order identity, its C98043-A7004-L1 hardware code and the converter rating recorded at the installation.
Which details should be photographed before disconnecting 6RY1703-0EA01 hardware?
Capture the full 6RY1703-0EA01 order code, the C98043-A7004-L1 marking, the current class and the X102 connection.
Why does the customer-specific classification matter when recording 6RY1703-0EA01?
Siemens classifies 6RY1703-0EA01 as engineered for a specific order or customer and not reusable in another form, making the exact order identity essential.
Why should the R1–R8 markings be checked while identifying 6RY1703-0EA01?
Eight 0R04 positions support the A7004-L1/-L2 hardware identity associated with 6RY1703-0EA01.
After field-board work, which commissioning record should be updated for 6RY1703-0EA01?
For 6RY1703-0EA01, document P051=22 completion because this adjustment establishes the field-current sensing zero point.
