    Apter Power provides quotations, product manuals, and model matching for 6AV3627-1JK00-0AX0.

6AV3627-1JK00-0AX0

/ 4.9
1001 reviews | Need a Specific Revision?
Siemens 6AV3627-1JK00-0AX0 is a SIMATIC OP27 operator panel with a monochrome display and keypad for machine visualization, alarms, recipes, and controller operation.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 6AV3627-1JK00-0AX0
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 6AV3627-1JK00-0AX0

  • Manufacturer:
    Siemens
  • Part Number:
    6AV3627-1JK00-0AX0
  • Product Family:
    Siemens Simatic HMI
  • Product Type:
    OP27 Monochrome Operator Panel
  • Stock:
    1
  • Panel Type:
    SIMATIC OP27
  • Display Technology:
    STN monochrome liquid-crystal display
  • Display Resolution:
    320 x 240 pixels
  • Display Gray Levels:
    8
  • Operation:
    Membrane keypad with function and navigation keys
  • Processor:
    x86, 33 MHz
  • Configuration Software:
    SIMATIC ProTool
  • Serial Interfaces:
    TTY/V.24, RS232, RS422, and RS485
  • Maximum RS485 Rate:
    12 Mbit/s
  • Rated Supply:
    24 V DC
  • Permitted Supply Range:
    18 to 30 V DC
  • Typical Power Consumption:
    8 W
  • Front Protection:
    IP65
  • Rear Protection:
    IP20
  • Operating Temperature:
    0 to +50 °C
  • Storage Temperature:
    -25 to +70 °C
  • Weight:
    4.162 lbs (1.888 kg)
  • Estimated shipping dimensions:
    30.1x39.3x13.6cm
  • Tariff Code:
    85371099
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Display & Keys Controller Links Project & Alarms Panel Mounting

Features:

  • A monochrome LCD presents process values, alarms, recipes, and operating screens.
  • The membrane keypad provides function keys and navigation without a touch surface.
  • Serial interfaces connect the configured ProTool project to the selected controller protocol.
Siemens 6AV3627-1JK00-0AX0 places machine visualization and keypad commands in one panel assembly.

The downloaded project on 6AV3627-1JK00-0AX0 assigns screens and messages to controller data.

Front sealing and rear-cabinet wiring keep the environmental and communication boundaries of 6AV3627-1JK00-0AX0 separate.

The Siemens 6AV3627-1JK00-0AX0 SIMATIC OP27 Monochrome Operator Panel may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Siemens 6AV3627-1JK00-0AX0 SIMATIC OP27 Monochrome Operator Panel Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Operator Display and Keypad

  • Display: The 320 x 240 monochrome LCD renders process graphics in eight gray levels.
  • Function keys: The membrane keyboard provides dedicated function-key operations defined in the project.
  • Navigation: Cursor and system keys move between configured screens and entries.
  • Backlight: Display visibility depends on the installed backlight and the configured contrast setting.

Serial Communication Paths

  • RS485 path: The configured RS485 interface supports the selected MPI or PROFIBUS communication.
  • RS232 paths: Serial ports connect supported controllers, service equipment, or a printer as assigned.
  • Driver dependency: The loaded ProTool project must contain the driver and parameters matching the installed controller.
  • Cable check: Pinout, shielding, termination, and baud rate must agree at both ends of the link.

Runtime Data and Retained Functions

  • Screen project: ProTool defines process screens, tags, key functions, and language resources.
  • Alarm buffer: Configured messages are recorded and acknowledged through the operator interface.
  • Recipe handling: Recipe records exchange grouped setpoints with the connected controller.
  • Backup need: The project source and transfer route must be retained before a panel exchange.

Cabinet Fit and Environmental Limits

  • Front boundary: The installed front provides the documented IP65 protection when the seal is intact.
  • Rear boundary: Rear electronics and connectors remain IP20 inside the cabinet.
  • Supply path: The panel operates from a documented 18 to 30 V DC input range.
  • Temperature range: Normal operation is specified from 0 to +50 °C.
Description
Siemens 6AV3627-1JK00-0AX0 is a SIMATIC OP27 operator panel with an STN monochrome liquid-crystal display and membrane keypad. It presents process screens, alarms, recipes, and operator commands for the connected automation system.

Serial interfaces on 6AV3627-1JK00-0AX0 provide the communication paths used by the configured controller driver and service equipment. The installed ProTool project determines screen objects, message handling, recipes, and the protocol assigned to each connection.

The 24 V DC supply of 6AV3627-1JK00-0AX0 powers the panel electronics and display backlight. Its cabinet installation separates the protected front face from the rear connections, so the mounting cutout, sealing surface, and ventilation clearance remain part of the replacement check.

Before exchanging 6AV3627-1JK00-0AX0, the project source, transfer method, controller address, interface wiring, and any external memory media must be preserved. A mechanically identical panel does not restore operation unless those configuration elements also agree.
Alternative Names
6AV36271JK000AX0 6AV3627 1JK00 0AX0 6AV 3627 1JK00 0AX0 Siemens 6AV3627-1JK00-0AX0 6AV3627-1JK00-0AX0 OP27 Panel 6AV3627-1JK00-0AX0 Monochrome HMI 6AV3627-IJK00-0AX0 6AV3627-1JKOO-OAXO
Technical notes
The Siemens 6AV3627-1JK00-0AX0 combines keypad operation, a monochrome display, and multiple serial interfaces whose behavior depends on the downloaded ProTool project.
