Siemens 6AV6647-0AA11-3AX1 is a KTP400 Basic mono PN operator panel with a 3.8-inch touch display, four function keys, and PROFINET.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 6AV6647-0AA11-3AX1
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 6AV6647-0AA11-3AX1

  • Manufacturer:
    Siemens
  • Part Number:
    6AV6647-0AA11-3AX1
  • Product Family:
    Siemens Simatic HMI
  • Product Type:
    SIMATIC HMI KTP400 Basic Mono PN Operator Panel
  • Stock:
    1
  • Display Technology:
    STN
  • Screen Diagonal:
    3.8 in
  • Display Area:
    76.8 x 57.6 mm
  • Resolution:
    320 x 240 pixels
  • Gray Levels:
    4
  • Touch Technology:
    Analog resistive
  • Function Keys:
    4
  • Rated Supply:
    24 V DC
  • Supply Range:
    19.2 to 28.8 V DC
  • Rated Current Consumption:
    0.1 A
  • Typical Active Power:
    3 W
  • Processor:
    32-bit RISC
  • User Memory:
    1 MB
  • Industrial Ethernet Interfaces:
    1
  • Runtime Languages:
    5
  • Project Languages:
    32
  • Maximum Variables per Device:
    250
  • Maximum Screens:
    50
  • Alarm Buffer Entries:
    256
  • Front / Rear Protection:
    IP65 / IP20
  • Operating Temperature:
    0 to +50 °C vertically; up to +40 °C at maximum tilt
  • Storage and Transport Temperature:
    -20 to +60 °C
  • Weight:
    1.08 lbs (0.49 kg)
  • Estimated shipping dimensions:
    16.7x14x8.9cm
  • Tariff Code:
    8537109190
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Display & Keys Ethernet Project Limits Mounting & Climate

Features:

  • A 3.8-inch STN display combines analog-resistive touch input with four hardware function keys.
  • One Ethernet interface carries project transfer and the selected controller communication protocol.
  • Internal memory organizes screens, messages, recipes, variables, and multilingual text within defined project limits.
Siemens 6AV6647-0AA11-3AX1 provides local operator display and input through one compact mono panel.

The Ethernet port of 6AV6647-0AA11-3AX1 links its HMI project to the configured controller.

Memory and language limits determine how the project is structured for 6AV6647-0AA11-3AX1.

The Siemens 6AV6647-0AA11-3AX1 SIMATIC HMI KTP400 Basic Mono PN Operator Panel may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Siemens 6AV6647-0AA11-3AX1 SIMATIC HMI KTP400 Basic Mono PN Operator Panel Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Operator Input and Display

  • Screen: The 3.8-inch STN panel presents a 320 x 240 image in four gray levels.
  • Touch input: The analog-resistive surface receives selections from the configured screen objects.
  • Function keys: Four hardware keys provide project-defined actions beside the touch interface.
  • Orientation: Portrait or landscape mounting changes how the screen project is arranged in the enclosure.

Project and Process Communication

  • Physical port: One Industrial Ethernet interface provides the panel network connection.
  • Project transfer: Engineering data is downloaded through the Ethernet path.
  • Controller link: The selected PROFINET, EtherNet/IP, Mitsubishi, or Modbus TCP driver uses the same interface.
  • Network setup: Addressing, DHCP or fixed parameters, cable, switch port, and target configuration must agree.

Memory and Runtime Structure

  • User memory: One megabyte stores the compiled HMI project and its runtime resources.
  • Screens and objects: The documented screen and per-screen object limits shape navigation and display density.
  • Messages and recipes: Alarm classes, message buffers, recipes, and data records consume defined project resources.
  • Languages: Five runtime languages can be selected from up to thirty-two languages configured in the project.

Panel Installation Boundary

  • Front sealing: The installed front face provides IP65 protection when the cutout and gasket are correct.
  • Rear enclosure: The IP20 rear side remains inside the control enclosure.
  • Tilt: The specified inclination can lower the applicable upper operating temperature.
  • Power: The 24 V DC input must remain within the documented voltage range during startup and operation.
Description
Siemens 6AV6647-0AA11-3AX1 is a SIMATIC HMI KTP400 Basic mono PN operator panel that combines a 3.8-inch STN touch display with four function keys. Its 320 x 240 pixel screen presents four gray levels while the analog-resistive surface accepts operator input.

One Industrial Ethernet port on 6AV6647-0AA11-3AX1 carries project transfer and process communication. PROFINET, TCP/IP, DHCP, SNMP, DCP, LLDP, EtherNet/IP, and Modbus TCP use the same physical interface through the controller connection selected in the project.

The 1 MB user memory of 6AV6647-0AA11-3AX1 holds screens, messages, recipes, variables, and text or graphics lists within the documented project limits. Five runtime languages can be selected from as many as thirty-two project languages, and the retentive alarm buffer stores up to 256 entries.

A 24 V DC supply powers 6AV6647-0AA11-3AX1 through the documented voltage range. The panel installs in portrait or landscape orientation, with the front face providing IP65 protection and the rear remaining within the enclosure at IP20.
Alternative Names
6AV66470AA113AX1 6AV6647 0AA11 3AX1 6AV 6647 0AA11 3AX1 Siemens 6AV6647-0AA11-3AX1 6AV6647-0AA11-3AX1 KTP400 Basic 6AV6647-0AA11-3AX1 HMI Panel 6AV6647-0AA1I-3AX1 6AV6647-OAA11-3AX1
Technical notes
The single Ethernet interface on Siemens 6AV6647-0AA11-3AX1 carries both project transfer and the configured controller protocol.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Why does 6AV6647-0AA11-3AX1 power up but show no controller values?
Check the 6AV6647-0AA11-3AX1 Ethernet link, IP settings, selected driver, controller address, project connection, tags, and controller run state.
Why does touch input on 6AV6647-0AA11-3AX1 select the wrong screen object?
Inspect the 6AV6647-0AA11-3AX1 touch calibration, screen cleanliness, protective overlay, mounting pressure, project coordinates, and touch-panel condition.
Why does a project download fail on 6AV6647-0AA11-3AX1?
Verify the 6AV6647-0AA11-3AX1 transfer mode, Ethernet address, cable, firewall path, engineering-software version, selected device, and available project memory.
What causes missing alarm history after restarting 6AV6647-0AA11-3AX1?
Check the 6AV6647-0AA11-3AX1 alarm-buffer configuration, acknowledgment logic, project download, clock synchronization, and retention settings.
Why does 6AV6647-0AA11-3AX1 overheat only when the cabinet door is angled?
Apply the 6AV6647-0AA11-3AX1 lower maximum temperature for inclined mounting and check enclosure airflow, spacing, supply load, and measured ambient temperature.
Why are some project languages unavailable at runtime on 6AV6647-0AA11-3AX1?
The 6AV6647-0AA11-3AX1 allows five online languages, so verify the runtime-language selection, text resources, project compilation, and transfer result.
