Features:
- Interface Between the DC Power Source and S7-1200 System Backplane
- Combines Capability of DC Power Conversion with Integrated I/O Support
- Operates in Conjunction with the SIMATIC S7-1200 Series and Standard TIA Portal Programming Environment
The 6ES7215-1HG40-0XB0 operates as the CPU 1215C Compact Controller in a S7-1200 rack, providing reliable DC power processing and integrated I/O functionality to all connected modules within the system. It continuously processes incoming DC power (20.4 - 28.8 V DC) to support steady state operation of all onboard and expansion modules. Seamless communication is standard with the 6ES7215-1HG40-0XB0, however using an optional Dual PROFINET Port Configuration will allow seamless network integration and redundancy in the event of a primary network failure. The 6ES7215-1HG40-0XB0 has made improvements in several areas over previous CPU designs in addition to incorporating universal DC input voltage capability within the S7-1200 rack.
The 6ES7215-1HG40-0XB0 provides essential control functions common to the entire rack, and is a critical component of the automation path, directly affecting the proper, normal operation of the overall control system. One 6ES7215-1HG40-0XB0 CPU module is required per rack as the central processing unit. The 6ES7215-1HG40-0XB0 occupies a compact form factor in the rack and is always located in the central controller position, with dedicated slots for expansion modules to the right.
For Dual PROFINET Network applications, the 6ES7215-1HG40-0XB0 utilizes its second integrated PROFINET port installed in the redundant network slot. In addition to standard single network operation, the redundant configuration also performs automatic switchover. The 6ES7215-1HG40-0XB0 dual network configuration executes failover using the internal circuitry specified in the CPU options. Using this method, the redundant network system continually monitors the health of both connections. If the system detects that the primary PROFINET port is no longer providing stable communication (outside configured network tolerance levels), it will automatically transfer the load to the secondary port and place an event in the System Event List.
The 6ES7215-1HG40-0XB0 SIEMENS SIMATIC S7-1200 CPU 1215C Compact Controller may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
SIEMENS 6ES7215-1HG40-0XB0 SIMATIC S7-1200 CPU 1215C Compact Controller Manuals,Datasheets,Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
SIEMENS 6ES7215-1HG40-0XB0 SIMATIC S7-1200 CPU 1215C Compact Controller Specs
General
- Manufacturer SIEMENS
- Model 6ES7215-1HG40-0XB0
- Condition New Original ready stock
- Product Family 6ES7215-1AG40-0XB0,6ES7215-1BG40-0XB0
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
- Packaging & Labeling: Manages photoeyes and limit switches via 14 digital inputs, while 10 relay outputs drive motor starters and solenoids.
- Conveyor Systems: Uses high-speed counters for product tracking and relay outputs for section motor control.
- HVAC & Facility Control: Leverages the integrated real-time clock (480-hour backup) and analog inputs for temperature and scheduling.
- Process Mixing: Employs built-in PID controllers to manage pump speeds via analog outputs.
- Dual PROFINET Ports: Features two integrated ports that support daisy-chain and star topologies for communication with HMI, SCADA, and distributed I/O.
- Expansion Capacity: Support for up to 3 communication modules (CM) (e.g., for RS485, RS232, or PROFIBUS) and 1 communication board (CB).
- Protocols: Supports standard TCP/IP, ISO-on-TCP, S7 communication, and OPC UA (starting with Firmware V4.4) for standardized cross-manufacturer data exchange.
- Safety Restriction: The integrated relay contacts are not certified for safety-critical emergency stop functions; these require dedicated safety relays or S7-1200F/S7-1500F CPUs.
- Industrial Security: Siemens provides integrated security functions to protect against unauthorized access to the controller and its programs.
- General Compliance: The device is CE marked, RoHS compliant, and meets standard industrial approvals for automation equipment.
