6ES7221-1BF32-0XB0

/ 4.9
1001 reviews | Need a Specific Revision?
Siemens 6ES7221-1BF32-0XB0 is an eight-channel SIMATIC S7-1200 SM 1221 digital input module for 24 VDC sink or source field signals.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for 6ES7221-1BF32-0XB0
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 6ES7221-1BF32-0XB0

  • Manufacturer:
    Siemens
  • Part Number:
    6ES7221-1BF32-0XB0
  • Product Family:
    Siemens Simatic S7-1200
  • Product Type:
    SIMATIC S7-1200 SM 1221 Digital Input Module
  • Stock:
    1
  • Inputs:
    8
  • Rated Input Voltage:
    24 VDC
  • Input Circuit:
    Sink / source
  • Backplane Current:
    105 mA
  • Input Delay:
    Parameterizable in groups of four
  • Cable Length:
    500 m shielded / 300 m unshielded maximum
  • Diagnostics:
    Input status indication and diagnostic alarm
  • Potential Separation:
    Between digital input channels in groups of 2
  • Protection:
    IP20
  • Weight:
    0.15 kg
  • Estimated shipping dimensions:
    8.8 x 10.9 x 6.0 cm
  • Tariff Code:
    Please confirm the destination before shipping
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Input Planning Wiring Review Commissioning Product Applications

Features:

  • Eight-point input expansion: Adds a compact signal group where cabinet width and point count must stay controlled.
  • Sink/source use: Supports the documented 24 VDC field-circuit conventions when commons are wired correctly.
  • Local state indication: Channel LEDs give maintenance a visible first check at the input module.
6ES7221-1BF32-0XB0 reports discrete field states to an S7-1200 controller in an eight-input expansion position.

Its small input bank is useful where the control cabinet needs a defined set of sensor and contact points without consuming a sixteen-input position.

The module acquires field conditions for the CPU; the application program determines their meaning in the machine sequence.

Apter Power can help confirm the Siemens 6ES7221-1BF32-0XB0 SIMATIC S7-1200 SM 1221 Digital Input Module, input wiring and lifecycle timing before quotation.
Siemens 6ES7221-1BF32-0XB0 SIMATIC S7-1200 SM 1221 Digital Input Module Manuals,Datasheets,Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Signal inventory: Record sensor type, normal state and the input tag for every channel.
  • Sink/source fit: The field device and PLC input need a compatible current path.
  • Assigned positions: Each used channel must correspond to the intended hardware tag in the project.
  • Spare scope: Identify whether the front connector remains with the cabinet.
  • Power isolation: Remove field energy before reseating conductors or the connector.
  • Connector seating: A loose field interface can interrupt a valid sensor signal before it reaches the input circuit.
  • Route separation: Keep the input path away from switching-power wiring that can contaminate discrete states.
  • Channel labels: Maintain conductor identity through the module change.
  • Local-to-PLC proof: Compare terminal voltage, channel indication and program tag.
  • Normal-state test: Exercise both active and inactive conditions for every input.
  • Sequence control: Keep motion inhibited until interlocks respond correctly.
  • Alarm context: Capture any module diagnostic separately from the ordinary channel-state indication.
  • Proximity sensors: Brings qualified 24 VDC position signals into the PLC.
  • Limit and selector contacts: Reports machine-state contacts to control logic.
  • Panel status inputs: Collects permissive, alarm and auxiliary contact information.
  • Compact expansion: Adds eight inputs without selecting a larger sixteen-channel module.
Description
6ES7221-1BF32-0XB0 adds eight digital input positions for the sensors and contacts of a supported S7-1200 machine. Those field states become controller data rather than switched power for an actuator.

The eight-point scope of 6ES7221-1BF32-0XB0 suits a smaller group of signals without assigning a sixteen-input article and reworking the hardware map. Matching the full order code matters because input and output signal modules can look similar in the cabinet.

With 6ES7221-1BF32-0XB0, local input indication and a configured PLC tag provide different observations of the same field transition. Maintenance can use that separation to locate a wiring or project-mapping fault without treating every missing machine state as a failed sensor.
Alternative Names
6ES72211BF320XB0 6ES7221 1BF32 0XB0
Technical notes
6ES7221-1BF32-0XB0 divides its eight inputs between X10/1M (a.0–a.3) and X11/2M (a.4–a.7). Each common serves four inputs; it is not a separate return for every pair. A crossed common during connector transfer can misstate an entire four-point bank. Reconcile the conductors with the approved wiring map while field energy is isolated before returning the machine to automatic operation.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
A replacement photoeye provides only a 5 V logic-high signal for a 6ES7221-1BF32-0XB0 input. Can it be wired directly?
No. Siemens specifies a 15 V DC minimum for a logic-1 signal on this 24 V input module. Select an approved 24 V interface or field sensor instead of assuming that a visible 5 V transition will register reliably.
An emergency-stop contact is wired into 6ES7221-1BF32-0XB0. Does that make this standard module a certified safety input?
No. SM 1221 is a standard digital input module; wiring a safety-related contact to it does not create a fail-safe input function. Have the machine safety design use the approved safety architecture and dedicated hardware where required.
An input on 6ES7221-1BF32-0XB0 stays on after an electronic sensor turns off. What separates a field-signal issue from a failed module?
A residual voltage at the module terminal is a possible field-side cause, not proof of a failed input. Measure the off-state terminal voltage and compare it with the Siemens OFF threshold before deciding whether the sensor circuit or module needs service.
A PNP sensor is added to a cabinet using 6ES7221-1BF32-0XB0. Is “sink/source” on the module label alone enough to approve the connection?
No. A PNP sensor sources current, so use the module as a sinking input with M connected to the negative field reference as shown in the Siemens wiring diagram. Do not use the sourcing-input common arrangement for that sensor.
A 6ES7221-1BF32-0XB0 replacement reads a contact correctly during manual test but misses brief production events. What should be compared?
Compare the installed group delay, pulse duration and archived hardware configuration during the actual cycle. A steady manual test does not prove the required event timing.
A sensor lead feeding 6ES7221-1BF32-0XB0 is extended to 350 m without a shield. Can the same cable plan be accepted?
No. Siemens gives 300 m as the maximum unshielded input-cable length for this module. Redesign the route or use a qualified shielded arrangement before commissioning the relocated sensor.
