6ES7214-2AD23-0XB8

/ 4.9
1001 reviews | Need a Specific Revision?
Siemens 6ES7214-2AD23-0XB8 is a legacy SIMATIC S7-200 CN CPU 224XP compact controller with integrated digital and analog I/O for installed machine systems.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 6ES7214-2AD23-0XB8
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 6ES7214-2AD23-0XB8

  • Manufacturer:
    Siemens
  • Part Number:
    6ES7214-2AD23-0XB8
  • Product Family:
    Siemens Simatic S7-200
  • Product Type:
    SIMATIC S7-200 CN CPU 224XP Compact Controller
  • Stock:
    1
  • Platform:
    SIMATIC S7-200 CN
  • CPU Type:
    CPU 224XP compact device
  • Supply:
    DC
  • Digital Inputs:
    14
  • Digital Outputs:
    10 transistor
  • Analog Inputs:
    2
  • Analog Outputs:
    1
  • Program Memory:
    12 / 16 KB
  • Data Memory:
    10 KB
  • Interfaces:
    2 PPI / user-programmable
  • Approval Note:
    CE approval for this CN article
  • Estimated shipping dimensions:
    14.0 x 8.0 x 6.2 cm
  • Tariff Code:
    Please confirm the destination before shipping
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals CPU Replacement I/O Migration Service Continuity Product Applications

Features:

  • Compact control core: Local digital and analog functions reduce the number of separate modules in a small machine.
  • Dual serial access: Two programmable interfaces support the installed operator, programming or peer-communication arrangement.
  • Legacy continuity: An exact spare can restore the original application while migration evidence is prepared.
6ES7214-2AD23-0XB8 belongs to the earlier S7-200 CN platform and is now presented by Siemens as a spare-part article.

The controller identity includes both its integrated I/O mix and the regional approval note, so another CPU 224XP should not be treated as equivalent from the family name alone.

Successful recovery depends on having a usable project and knowing how the two ports and analog points were assigned in the machine.

Apter Power can help confirm the Siemens 6ES7214-2AD23-0XB8 SIMATIC S7-200 CN CPU 224XP Compact Controller, project environment and installed I/O scope before quotation.
Siemens 6ES7214-2AD23-0XB8 SIMATIC S7-200 CN CPU 224XP Compact Controller Manuals,Datasheets,Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Project backup: Preserve program, data blocks, symbols and password state before removing the CPU.
  • Hardware identity: Match the complete MLFB and documented CN approval scope.
  • Memory evidence: Confirm retained values and startup data expected by the process.
  • STOP-mode start: Restore the project before enabling field outputs.
  • Digital map: Label every input, output and common before disconnecting conductors.
  • Analog scaling: Record sensor ranges, engineering units and output behavior.
  • Field protection: Verify external fusing and suppression around transistor loads.
  • Proof test: Exercise each point from the controller to the real device under controlled conditions.
  • Port inventory: Identify programming, HMI and peer use on both interfaces.
  • Cable retention: Keep verified adapters and pinout records with the machine backup.
  • Battery and data: Review retained-memory expectations after long storage.
  • Migration record: Capture the complete installed function before the legacy platform becomes unavailable.
  • Legacy machine control: Restores an installed S7-200 CN compact automation task.
  • Small process skids: Combines discrete and analog control in one controller.
  • Serially connected equipment: Supports existing HMI or peer links on the programmable ports.
  • Bridge maintenance: Provides continuity while a modern PLC conversion is engineered.
Description
6ES7214-2AD23-0XB8 combines the processor, local digital points, analog channels and two programmable communication interfaces in one compact S7-200 CN controller for legacy machines.

As a spare-part article, 6ES7214-2AD23-0XB8 should be selected by the full MLFB and the installed program environment; a similar CPU 224XP faceplate does not prove memory, approval or regional identity.

Before changing 6ES7214-2AD23-0XB8, maintenance should secure the project, passwords, data blocks and port settings, then restore the controller with outputs inhibited and validate every safety-related external circuit independently.
Alternative Names
6ES72142AD230XB8 6ES7214 2AD23 0XB8
Technical notes
6ES7214-2AD23-0XB8 is a legacy controller whose field outputs can energize as soon as the restored program runs. Archive the project and communication settings, isolate connected machinery, verify supply polarity and I/O commons, then commission in STOP mode. Do not release automatic operation until analog scaling and both serial interfaces are proven.
