6ES7315-2AH14-0AB0

/ 4.9
1001 reviews | Need a Specific Revision?
The SIMATIC S7-300 CPU 315-2DP 6ES7315-2AH14-0AB0 is a central processing unit designed specifically for industrial automation applications.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 6ES7315-2AH14-0AB0
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 6ES7315-2AH14-0AB0

  • Manufacturer:
    Siemens
  • Part Number:
    6ES7315-2AH14-0AB0
  • Product Family:
    Siemens Simatic S7-300
  • Product Type:
    Central Processing Unit
  • Stock:
    1
  • Product type designation:
    CPU 315-2 DP
  • HW functional status:
    01
  • Firmware version:
    V3.3
  • Product function:
    Isochronous mode Yes
  • Rated value (DC):
    24 V
  • permissible range, lower limit (DC):
    19.2 V
  • permissible range, upper limit (DC):
    28.8 V
  • external protection for power supply lines (recommendation):
    2 A min.
  • Power loss, typ.:
    4.5 W
  • Weight:
    0.3 kg
  • Estimated shipping dimensions:
    4x12.2x12.5cm
  • Tariff Code:
    8537101190
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Use Cases Programming Diagnostics & Protection

Features:

  • Bridge Between the 24 V DC Power Source and S7-300 Rack Backplane
  • Integrates Central Processing Capability with Dual Interface Communication Support
  • Functions Alongside the SIMATIC S7-300 Series Modules and PROFIBUS DP Networks
The SIEMENS 6ES7315-2AH14-0AB0 CPU Module serves as the Central Processing Unit in an S7-300 rack, delivering reliable program execution and data management to all modules within the system. It continuously processes automation logic through its 256 KB work memory while managing data exchange via the integrated MPI interface and the second DP master/device interface to ensure coordinated operation of all distributed I/O and function modules. Smooth communication handling is inherent with the 6ES7315-2AH14-0AB0, though utilizing a Micro Memory Card enables seamless program storage and expanded block capacity for sophisticated control applications. The 6ES7315-2AH14-0AB0 incorporates enhancements in multiple areas compared to earlier CPU generations, including the integration of dual communication interfaces within the S7-300 rack.

The 6ES7315-2AH14-0AB0 delivers essential control functions essential to the entire rack, forming a vital element of the automation pathway, directly influencing the proper, standard operation of the overall control system. One 6ES7315-2AH14-0AB0 CPU module is required per rack to serve as the central controller. The 6ES7315-2AH14-0AB0 occupies a single slot in the rack and is positioned in the designated CPU location.

For Distributed Control applications, the 6ES7315-2AH14-0AB0 CPU Module enables DP master/device operation through its secondary interface. Beyond conventional centralized processing, the distributed setup also facilitates automatic device handling. The 6ES7315-2AH14-0AB0 dual interface setup manages communication protocols using the internal architecture defined in the processor specifications. Through this approach, the distributed control architecture persistently tracks the status of connected DP devices. Should the system identify that a DP slave device has ceased providing reliable data transmission (exceeding configured communication thresholds), it will automatically register the diagnostic condition and record an entry in the diagnostic buffer for analysis.

The 6ES7315-2AH14-0AB0 SIEMENS CPU Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
SIEMENS 6ES7315-2AH14-0AB0 CPU Module Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
SIEMENS 6ES7315-2AH14-0AB0 CPU Module Specs

General

  • Manufacturer SIEMENS
  • Model 6ES7315-2AH14-0AB0
  • Condition New Original ready stock
  • Product Family 6ES7315-2AG10-0AB0,6ES7315-2EH14-0AB0,6ES7511-1AK02-0AB0
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Production & Packaging Plants: Managing complex functions in high-speed automated production lines.
  • Distributed Systems: Utilizing the PROFIBUS DP interface to act as a master or slave for up to 124 DP devices.
  • Industrial Process Control: Reliable handling of binary and floating-point arithmetic for precision engineering.
  • Maintenance & Spare Parts: Often used as a reliable spare part for existing S7-300 installations.
  • Siemens engineering environments: Software: Programmed using SIMATIC STEP 7 (V5.2 + SP1 or higher) or the newer TIA Portal.
  • Memory Management: A Micro Memory Card (MMC) is required for operation; it stores the user program and data without the need for a battery.
  • Execution Speeds: Fast processing times of approximately 0.05 µs for bit operations and 0.09 µs for word operations.
  • Block Support: Supports up to 1,024 total blocks (DBs, FCs, FBs).
  • System Diagnostics: Modules report errors via diagnostic interrupts. Built-in functions allow for quick status configuration and testing.
  • Password Protection: Prevents unauthorized access or tampering with the user program.
  • Know-how Protection: Supports block encryption to protect proprietary logic.
  • LED Indicators: Front panel LEDs (SF, BF, RUN, STOP) provide immediate visual feedback on system and bus faults.
  • Error Handling: Uses specialized Organization Blocks (OBs), such as OB 80–87 for asynchronous errors and OB 121–122 for synchronous errors, to prevent total system shutdown during faults.
Description
The SIMATIC S7-300 CPU 315-2DP with the specific model number 6ES7315-2AH14-0AB0 is a central processing unit designed for industrial automation applications. This 6ES7315-2AH14-0AB0 processor features an integrated MPI interface and a 24 V DC power supply, making it suitable for distributed control systems. The 6ES7315-2AH14-0AB0 comes equipped with 256 KB of work memory and includes a second DP interface that can operate as either a master or device, providing flexible communication options for various network configurations. A Micro Memory Card is required for operation with this 6ES7315-2AH14-0AB0 unit.

This 6ES7315-2AH14-0AB0 CPU is specifically designed for handling medium-complexity automation tasks in manufacturing environments, solving the challenge of coordinating multiple processes across distributed I/O systems. The 6ES7315-2AH14-0AB0 supports up to 1,024 blocks total, including data blocks, function blocks, and functions, with the actual maximum loadable blocks depending on the MMC capacity used. For data blocks, the 6ES7315-2AH14-0AB0 accommodates up to 1,024 DBs with numbers ranging from 1 to 16,000, each with a maximum size of 64 KB. Similarly, function blocks and functions on the 6ES7315-2AH14-0AB0 are limited to 1,024 each, numbered 0 to 7,999, with a maximum size of 64 KB per block.

Regarding counters and timers, the 6ES7315-2AH14-0AB0 provides 256 S7 counters with adjustable retentivity, preset to retain counters Z 0 through Z 7, and a counting range from 0 to 999. The 6ES7315-2AH14-0AB0 also includes unlimited IEC counters implemented as SFBs, limited only by available RAM. For timing functions, the 6ES7315-2AH14-0AB0 offers 256 S7 timers with adjustable retentivity (preset to no retentivity), covering a time range from 10 milliseconds to 9,990 seconds. Additionally, the 6ES7315-2AH14-0AB0 supports unlimited IEC timers as SFBs, constrained only by RAM capacity. This 6ES7315-2AH14-0AB0 processor is ideal for applications requiring precise timing, counting, and data processing capabilities in industrial settings such as packaging lines, material handling systems, and process control operations.
Alternative Names
6ES73I5-2AHI4-0AB0 6ES7315-2AH14-OABO 6ES7315-2AH14-0A80 6ES7315-2AG10-0AB0 6ES7315-2EH14-0AB0 6ES7511-1AK02-0AB0 6ES7953-8LF31-0AA0
Technical notes
The SIEMENS 6ES7315-2AH14-0AB0 SIMATIC S7-300 CPU 315-2 DP central processing unit integrates 256KB of working memory and supports MMC card expansion up to 8MB. Through its built-in MPI and PROFIBUS DP dual communication interfaces supporting master/slave modes, it achieves high-speed data transmission of up to 12Mbps. Within a compact 40mm chassis, it delivers exceptional processing performance with an ultra-fast bitwise operation capability of 0.05μs, making it a highly cost-effective and mature controller option for industrial applications.
