    Apter Power delivers genuine Siemens 6ES7332-7ND02-0AB0 replacement hardware, offering industrial facilities a trusted source for critical control components to maintain peak performance and uninterrupted production.

6ES7332-7ND02-0AB0

/ 4.9
1001 reviews | Need a Specific Revision?
The 6ES7332-7ND02-0AB0 is a high-performance analog output module from the SIMATIC S7-300 series, compatible with a wide range of actuators, valves, and control devices.
In Stock
Ships by Saturday, October 17
Fast Shipping Available
Get a quick price for 6ES7332-7ND02-0AB0
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 6ES7332-7ND02-0AB0

  • Manufacturer:
    Siemens
  • Part Number:
    6ES7332-7ND02-0AB0
  • Product Family:
    Siemens Simatic S7-300
  • Product Type:
    Analog output module
  • Stock:
    1
  • Rated value (DC):
    24 V
  • Reverse polarity protection:
    Yes
  • from load voltage L+ (without load), max.:
    290 mA
  • from backplane bus 5 V DC, max.:
    120 mA
  • Power loss, typ.:
    3 W
  • Number of analog outputs:
    4;Isochronous mode
  • Weight:
    0.26 kg
  • Estimated shipping dimensions:
    4x11.6x12.4cm
  • Tariff Code:
    8537101190
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Use Cases Environmental Ratings Firmware & Updates

Features:

  • Interface Between the Analog Control System and S7-300 Rack Backplane
  • Combines Capability of High-Resolution Signal Conversion with Channel Isolation Support
  • Operates in Conjunction with the CPU and Standard S7-300 Modules
The 6ES7332-7ND02-0AB0 operates as the Analog Output SM 332 in a S7-300 rack, providing reliable 16-bit analog output signals to all connected actuators within the system. It continuously converts digital process values from the CPU to precise analog signals (0-10 V, 1-5 V, ±10 V, ±20 mA, 0/4-20 mA) and distributes these signals through the 20-pole front connector to support accurate control of field devices and process variables. Seamless signal generation is standard with the 6ES7332-7ND02-0AB0, however using the Isochronous Mode capability will allow synchronized output updates with improved bus cycle times for time-critical applications. The 6ES7332-7ND02-0AB0 has made improvements in several areas over previous analog output designs in addition to incorporating channel-to-channel isolation capability within the S7-300 rack.

The 6ES7332-7ND02-0AB0 provides essential analog output functions common to the entire control loop, and is a critical component of the control path, directly affecting the proper, normal operation of the overall automation system. One 6ES7332-7ND02-0AB0 module provides 4 analog output channels per rack depending on the required I/O density. The 6ES7332-7ND02-0AB0 occupies only a single slot in the rack and can be located in any standard I/O slot position.

For High-Density Analog Control applications, the S7-300 System requires additional 6ES7332-7ND02-0AB0 analog output modules installed in available slots. In addition to standard voltage/current output operation, the 6ES7332-7ND02-0AB0 configuration also performs automatic diagnostics. The 6ES7332-7ND02-0AB0 dual-range capability executes signal selection using the internal configuration specified in the hardware setup. Using this method, the 6ES7332-7ND02-0AB0 system continually monitors the health of all output channels. If the system detects that an output channel is no longer providing stable signal (outside configured range/tolerance levels), it will automatically report the fault to the CPU and place a diagnostic event in the System Diagnostic Buffer.

The 6ES7332-7ND02-0AB0 Siemens SIMATIC S7-300 Analog Output SM 332 may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Siemens 6ES7332-7ND02-0AB0 SIMATIC S7-300, Analog output module Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Siemens 6ES7332-7ND02-0AB0 SIMATIC S7-300, Analog output module Specs

General

  • Manufacturer Siemens
  • Model 6ES7332-7ND02-0AB0
  • Condition New Original ready stock
  • Product Family 6ES7392-1AJ00-0AA0,6ES7392-1BJ00-0AA0
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Actuator Control: Driving proportional valves, frequency converters (drives), and actuators that require specific voltage or current inputs.
  • Process Regulation: Regulating variables like pH levels in wastewater plants, steam valves in power stations, or flow rates in chemical processing.
  • High-Speed Synchronous Operations: Its support for isochronous mode makes it ideal for applications requiring synchronized, high-speed data processing (e.g., motion control or precise timing in automotive manufacturing).
  • Operating Temperature: Horizontal mounting: 0°C to 60°C. Vertical mounting: 0°C to 40°C.
  • Humidity: 10% to 95% relative humidity (non-condensing), conforming to RH Class 2 (IEC 61131-2).
  • Protection Class: IP20 (requires a protective housing/cabinet).
  • Isolation: High electrical isolation (1500V DC) between channels and the backplane bus to protect the PLC from field surges.
  • Pollution Degree: Designed for Pollution Degree 2 environments.
  • Update Method: Unlike modern S7-1500 modules, S7-300 Analog Modules (SM) generally do not feature user-upgradable firmware. Any necessary "updates" are usually handled via hardware revisions (E-Stand) at the factory.
  • Diagnostics: You can check the hardware version and diagnostic status via STEP 7 Classic or TIA Portal under the "Online & Diagnostics" view.
Description
The 6ES7332-7ND02-0AB0 is a high-performance analog output module from Siemens' SIMATIC S7-300 series, specifically designed as the SM 332 module. This 6ES7332-7ND02-0AB0 module features channel-to-channel isolation, providing independent electrical isolation for each of its 4 analog output channels to ensure signal integrity and prevent interference in industrial environments.

The 6ES7332-7ND02-0AB0 delivers exceptional precision with 16-bit resolution across all output channels. It supports versatile signal ranges including 0-10 V, 1-5 V, ±10 V for voltage outputs, and ±20 mA, 0/4-20 mA for current outputs, making the 6ES7332-7ND02-0AB0 compatible with a wide range of actuators, valves, and control devices. The module utilizes a 20-pole front connector for reliable field wiring connections.

This 6ES7332-7ND02-0AB0 is specifically optimized for isochronous mode operation, featuring improved bus cycle times that enable precise synchronization and real-time response capabilities. The 6ES7332-7ND02-0AB0 is designed for applications requiring deterministic control timing, such as motion control systems, coordinated drive controls, and high-speed manufacturing processes where synchronized multi-axis operation is critical.

The 6ES7332-7ND02-0AB0 is engineered to handle complex analog control challenges in process automation and manufacturing environments. This 6ES7332-7ND02-0AB0 module addresses the critical need for precise, synchronized analog signal generation in applications such as chemical dosing systems, temperature control loops, and pressure regulation systems. By providing isolated high-resolution outputs with deterministic timing, the 6ES7332-7ND02-0AB0 eliminates signal cross-talk and ground loop issues that commonly plague multi-channel analog control systems, ensuring accurate and reliable process variable manipulation in demanding industrial scenarios.
Alternative Names
6ES7332 7ND02 0AB0 6ES7332-7NDO2-OABO 6ES7332-7ND02-0A80 6ES73327ND020AB0 6ES7307-1KA00-0AA0 6ES7315-1AF03-0AB0 6ES7315-2EH13-0AB0
Technical notes
The Siemens 6ES7332-7ND02-0AB0 requires a standard 20-pin front connector for field terminal wiring. For optimum noise immunity and to achieve the maximum specified cable length of 200 meters, it is mandatory to use high-quality shielded cables.
