    Apter Power can assist with 6ES7317-6TK13-0AB0 manuals, quotations, and S7-300 technology CPU matching.

6ES7317-6TK13-0AB0

/ 4.9
1001 reviews | Need a Specific Revision?
Combining PLC execution with integrated technology I/O, Siemens 6ES7317-6TK13-0AB0 is an S7-300 CPU 317T-2 DP that coordinates general DP communication and a separate DP(DRIVE) bus.
In Stock
Ships by Saturday, October 17
Fast Shipping Available
Get a quick price for 6ES7317-6TK13-0AB0
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 6ES7317-6TK13-0AB0

  • Manufacturer:
    Siemens
  • Part Number:
    6ES7317-6TK13-0AB0
  • Product Family:
    Siemens Simatic S7-300
  • Product Type:
    SIMATIC S7-300 CPU 317T-2 DP Technology Central Processing Unit
  • Stock:
    1
  • CPU designation:
    CPU 317T-2 DP
  • Work memory:
    1,024 KB integrated
  • Required memory card:
    SIMATIC Micro Memory Card, minimum 8 MB
  • Engineering software:
    STEP 7 V5.4 SP5 or later with S7-Technology V4.2
  • Supply:
    24 V DC; permissible 20.4–28.8 V DC
  • No-load current:
    200 mA typical
  • Typical power loss:
    6 W
  • Bit processing time:
    0.05 µs
  • Word/fixed-point processing:
    0.2 µs
  • Floating-point processing:
    1 µs
  • Integrated digital inputs:
    4 for technology functions
  • Integrated digital outputs:
    8 high-speed technology outputs
  • Output rated current:
    0.5 A per channel
  • Shielded I/O cable length:
    Up to 1,000 m
  • First interface:
    Isolated RS485 MPI/DP master or slave
  • First-interface DP slaves:
    Up to 124
  • Second interface:
    Isolated RS485 DP(DRIVE) master
  • Second-interface DP slaves:
    Up to 64
  • Communication connections:
    32 total
  • Diagnostic buffer:
    100 entries
  • Operating temperature:
    0–60 °C
  • Isolation test:
    500 V DC
  • Cycle monitoring:
    Adjustable 1–6,000 ms
  • Weight:
    1.78 lbs (0.808 kg)
  • Estimated shipping dimensions:
    17x14x14cm
  • Tariff Code:
    85371091
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Technology I/O Bus Roles Memory & Tools Test Functions

Features:

  • One CPU executes PLC logic and the configured S7-Technology functions within an S7-300 station.
  • Four technology inputs and eight high-speed outputs are wired through a 40-pin front connector.
  • The MPI/DP interface and dedicated DP(DRIVE) master divide general communication from drive synchronization.
Siemens 6ES7317-6TK13-0AB0 combines the cyclic PLC program with technology processing rather than assigning those functions to a separate controller.

Its Micro Memory Card stores the project and backup data required by the CPU, while integrated work memory holds the active program and process values.

The first bus connection supports engineering, operator access, routing, and DP operation; the second is reserved for the documented DP(DRIVE) role.

The Siemens 6ES7317-6TK13-0AB0 SIMATIC S7-300 CPU 317T-2 DP may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Siemens 6ES7317-6TK13-0AB0 SIMATIC S7-300 CPU 317T-2 DP Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Signal Flow Through the Integrated Channels

  • Technology Inputs: Four digital inputs accept the signals assigned to counting or other configured technology functions.
  • High-Speed Outputs: Eight outputs issue technology control signals such as high-speed cam-switch commands.
  • Output Grouping: Current limits apply to the output group, and the channels cannot be paralleled to increase load power.
  • Electrical Separation: Both input and output circuits are isolated from the S7-300 backplane bus.

Why the Two RS485 Interfaces Are Not Interchangeable

  • Interface One: MPI and PROFIBUS DP services include PG/OP access, routing, DP master operation, and DP slave operation.
  • Interface Two: The second connection is a DP(DRIVE) master for the assigned drive network.
  • Excluded Services: MPI, PG/OP communication, routing, and S7 communication are not provided on the DP(DRIVE) interface.
  • Isochronous Operation: Both documented DP master paths support equidistant and isochronous operation within their assigned roles.

Project Storage and Engineering Chain

  • Micro Memory Card: The CPU requires a SIMATIC MMC with at least the specified capacity to hold the project.
  • Work Memory: Integrated memory contains the active PLC code, technology logic, and runtime data.
  • STEP 7 Project: STEP 7 supplies the PLC configuration, hardware assignment, and supported programming languages.
  • S7-Technology: The matching option package creates and configures the technology functions executed by the CPU.

Checks Available During Commissioning

  • Status and Control: Selected inputs, outputs, markers, data blocks, timers, and counters can be observed or modified.
  • Forcing: The engineering system can force the documented input and output variables during controlled testing.
  • Program Analysis: Status blocks, single-step operation, and breakpoints expose program execution for commissioning work.
  • Diagnostic History: The diagnostic buffer retains CPU events independently of the channel-state LEDs.
Description
Siemens 6ES7317-6TK13-0AB0 is the SIMATIC S7-300 CPU 317T-2 DP central processing unit for PLC and technology tasks. It executes the S7 control program while coordinating integrated technology I/O and two separately assigned PROFIBUS communication paths.

At the front connector, 6ES7317-6TK13-0AB0 brings four digital inputs and eight high-speed digital outputs into the technology function. The inputs can capture the assigned technological signals, while the short-circuit-resistant outputs produce control signals such as high-speed cam-switch commands without being paralleled for higher power.

Communication duties are deliberately split on 6ES7317-6TK13-0AB0. The first isolated RS485 interface handles MPI, DP master or slave operation, programming-device and operator-panel communication, and routing; the second isolated RS485 interface operates only as a DP(DRIVE) master and does not carry MPI, PG/OP, or routing services.

Program storage for 6ES7317-6TK13-0AB0 requires a SIMATIC Micro Memory Card, while its integrated work memory holds the active code and data. STEP 7 and S7-Technology provide the engineering environment for PLC logic, technology objects, interface configuration, and the compiled project loaded through that memory structure.

Commissioning functions on 6ES7317-6TK13-0AB0 separate status and control variables, forcing, status blocks, breakpoints, cycle-time monitoring, and the diagnostic buffer. Channel LEDs indicate the integrated input and output states, while the electrical isolation keeps the technology I/O circuits separated from the backplane bus.
Alternative Names
6ES73176TK130AB0 6ES7 317 6TK13 0AB0 6ES7317 6TK13 0AB0 Siemens 6ES7317-6TK13-0AB0 6ES7317-6TK13-0AB0 CPU 317T-2 DP 6ES7317-6TK13-0AB0 technology CPU 6ES7317-6TKI3-0AB0 6ES73I7-6TK13-0AB0
Technical notes
Siemens 6ES7317-6TK13-0AB0 combines an S7-300 PLC runtime with four technology inputs, eight high-speed outputs, and a dedicated DP(DRIVE) master interface.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Why is the second port on Siemens 6ES7317-6TK13-0AB0 not a substitute for its MPI/DP port?
The second port of Siemens 6ES7317-6TK13-0AB0 is a DP(DRIVE) master only; it does not provide MPI, PG/OP communication, routing, or DP slave operation.
Is a Micro Memory Card optional when commissioning 6ES7317-6TK13-0AB0?
No. 6ES7317-6TK13-0AB0 requires a SIMATIC Micro Memory Card with at least the documented 8 MB capacity.
Can two outputs of Siemens 6ES7317-6TK13-0AB0 be paralleled for a larger load?
No. Siemens 6ES7317-6TK13-0AB0 does not permit output paralleling for increased power or redundant load control.
What makes the onboard I/O of 6ES7317-6TK13-0AB0 different from ordinary CPU status points?
The four inputs and eight high-speed outputs of 6ES7317-6TK13-0AB0 are integrated for assigned technology functions and are wired through the 40-pin front connector.
Which software pair belongs to Siemens 6ES7317-6TK13-0AB0?
Siemens 6ES7317-6TK13-0AB0 is engineered with STEP 7 V5.4 SP5 or later and the S7-Technology V4.2 option package.
Where is routing available on 6ES7317-6TK13-0AB0?
Routing is supported through the first MPI/DP interface of 6ES7317-6TK13-0AB0, not through the dedicated DP(DRIVE) interface.
