VM600 MPC4 200-510-071-113

/ 4.9
1001 reviews | Need a Specific Revision?
Vibro-Meter VM600 MPC4 200-510-071-113 is a four-channel machinery protection processor with two speed-reference inputs. It supports continuous measurement and protection functions in the VM600 platform.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for VM600 MPC4 200-510-071-113
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for VM600 MPC4 200-510-071-113

  • Manufacturer:
    Vibro-Meter
  • Part Number:
    VM600 MPC4 200-510-071-113
  • Product Family:
    VM600 Machinery Protection System
  • Product Type:
    Machinery Protection Card
  • Stock:
    1
  • Dynamic Inputs:
    4
  • Tachometer Inputs:
    2
  • DC Voltage Range:
    0 to +20 V or 0 to -20 V
  • AC Voltage Range:
    ±10 V maximum
  • Common-Mode Range:
    -50 to +50 V
  • Input Impedance:
    200 kΩ
  • Current Input Range:
    0 to 25 mA DC
  • AC Current Limit:
    ±8 mA
  • Analog Frequency Range:
    DC to 60 kHz
  • Integrated Frequency Range:
    2.5 Hz to 10 kHz
  • CMRR:
    Greater than 60 dB at 50 Hz
  • Crosstalk:
    -72 dB
  • Operating Temperature:
    -25 to +65 °C
  • Storage Temperature:
    -40 to +85 °C
  • Dimensions:
    262 x 20 x 187 mm
  • Mass:
    Approximately 0.40 kg
  • Weight:
    0.882 lbs (0.4 kg)
  • Estimated shipping dimensions:
    2 x 19 x 26.1 cm
  • Tariff Code:
    8537101190
  • Country of origin:
    Switzerland
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Communication & Connectivity Firmware & Updates

Features:

  • Four programmable dynamic inputs for VM600 protection measurements.
  • Two dedicated speed-reference channels for tachometer processing.
  • DSP-based filtering and measurement generation within the protection rack.
The current ordering configuration is VM600 MPC4 200-510-071-113, a processing card for online machinery protection.

It combines dynamic sensor acquisition with speed-referenced calculations and configurable protection logic.

Match the hardware revision, companion IOC4T, software database and buffered-output requirements before installation.

Availability is subject to Apter Power inventory and sourcing confirmation.
Verified resources for Vibro-Meter VM600 MPC4 200-510-071-113:Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Vibro-Meter VM600 MPC4 200-510-071-113 Machinery Protection Card Specs

General

  • Manufacturer Vibro-Meter
  • Model VM600 MPC4 200-510-071-113
  • Condition New Original ready stock
  • Product Family VM600 MPC4 200-510-074-113,VM600-CPU-M-200-595-033-111
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Monitors critical rotating equipment with continuously active protection measurements.
  • Combines vibration channels with speed references during steady-state and transient operation.
  • Supports plant alarm and shutdown strategies through the associated VM600 relay architecture.
  • Communicates through the VM600 rack interface with the installed control architecture.
  • Supports engineering access for configuration and diagnostic review through the documented service interface.
  • Routes field signals through the correctly paired IOC4T rear input/output card.
  • Requires firmware compatible with the hardware generation and installed rack software.
  • Uses a validated configuration database containing channel scaling, filters and protection logic.
  • Needs controlled backup and restoration procedures before card or firmware changes.
Description
VM600 MPC4 200-510-071-113 combines four configurable dynamic inputs, two tachometer inputs and dedicated signal processing on a 6U VM600 protection card.

It converts connected sensor signals into machinery-protection measurements across the documented voltage, current and frequency ranges, supporting continuous monitoring of critical rotating assets.

Review the complete MPC4/IOC4T pairing, software configuration and rack position before substitution. Restore the approved measurement ranges, filters, alarm thresholds and relay mappings after installation.
Alternative Names
Vibro-Meter VM600 MPC4 200-510-071-113 VM600 MPC4 200 510 071 113 VM600-MPC4-200-510-071-113 200510071113 Vibro-Meter protection card 200-510-071-113 MPC4 four-channel vibration processor VM600 MPS monitoring card MPC4 tachometer and dynamic-input module
Technical notes
For VM600 MPC4 200-510-071-113, load the correct rack database and verify IOC4T pairing before insertion; mismatched configurations can suppress protection functions.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How are alarm functions configured on VM600 MPC4 200-510-071-113?
Alert and danger logic is defined in the VM600 measurement database with the required thresholds, delays and channel behavior.
Which transducer signals can VM600 MPC4 200-510-071-113 process?
Its programmable dynamic inputs support the documented voltage and current interfaces used by compatible vibration measurement chains.
How does VM600 MPC4 200-510-071-113 communicate inside the rack?
The card exchanges configuration and status through the VM600 rack architecture and works with the installed control card.
Which rack records help Apter Power source the correct VM600 MPC4 200-510-071-113 hardware revision?
Provide the IOC4T pairing, rack inventory, firmware or software baseline, configuration backup and requested quantity.
Does VM600 MPC4 200-510-071-113 have a direct drop-in replacement?
A drop-in replacement cannot be assumed; review card revision, I/O pairing, buffered outputs, firmware and database compatibility.
Where are VM600 MPC4 200-510-071-113 manuals and quotation details available?
Use the verified Manuals links or submit rack and channel details to Apter Power for document matching and pricing.
