    Apter Power provides IOC4T 200-560-000-113 pricing, documents, sourcing and MPC4 matching.

VM600 IOC4T 200-560-000-113

/ 4.9
1001 reviews | Need a Specific Revision?
Vibro-Meter VM600 IOC4T 200-560-000-113 is a rear input/output card for earlier-generation MPC4 protection processors. It provides field terminals, buffered outputs, relays and programmable open-collector outputs.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for VM600 IOC4T 200-560-000-113
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for VM600 IOC4T 200-560-000-113

  • Manufacturer:
    Vibro-Meter
  • Part Number:
    VM600 IOC4T 200-560-000-113
  • Product Family:
    VM600 Machinery Protection System
  • Product Type:
    Input/Output Card
  • Stock:
    1
  • Companion Processor:
    Earlier-generation MPC4
  • Dynamic Signal Inputs:
    4
  • Tachometer Inputs:
    2
  • Rear Connections:
    Screw-terminal connectors
  • Terminal Count:
    48
  • Software-Controlled Relays:
    4
  • Open-Collector Outputs:
    32 programmable outputs
  • Buffered Output Impedance:
    2000 Ω
  • Card Format:
    6U rear rack card
  • Dimensions:
    262 x 20 x 125 mm
  • Mass:
    Approximately 0.25 kg
  • System Function:
    Rear I/O for machinery protection channels
  • Signal Processing:
    Performed by paired MPC4
  • Installation Check:
    Verify card keying and rack position
  • Replacement Requirement:
    Review MPC4/IOC4T pair together
  • Weight:
    0.551 lbs (0.25 kg)
  • Estimated shipping dimensions:
    26.2 x 12.4 x 2 cm
  • Tariff Code:
    8537101190
  • Country of origin:
    Switzerland
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Installation & Integration Signal Routing

Features:

  • Rear I/O interface for four dynamic MPC4 measurement channels.
  • Two tachometer connections for speed and phase references.
  • Earlier 2000-ohm buffered-output hardware arrangement.
The current ordering configuration is VM600 IOC4T 200-560-000-113, the rear interface paired with an earlier MPC4 processor.

It terminates dynamic, tachometer, relay and configurable-output wiring while the companion MPC4 performs signal processing.

Verify card keying, terminal mapping, MPC4 generation and buffered-output impedance before replacement.

Availability is subject to Apter Power inventory and sourcing confirmation.
Verified resources for Vibro-Meter VM600 IOC4T 200-560-000-113:Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Vibro-Meter VM600 IOC4T 200-560-000-113 Input/Output Card

General

  • Manufacturer Vibro-Meter
  • Model VM600 IOC4T 200-560-000-113
  • Condition New Original ready stock
  • Product Family VM600 IOC16T 200-565-000-013,VM600 MPC4 200-510-070-113,VM600 MPC4 200-510-041-021
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Connects vibration sensors and tachometers to a paired MPC4 protection processor.
  • Provides rear field terminals for relay and configurable output circuits.
  • Supports machine-protection installations that require access to buffered raw signals.
  • Occupies the rear rack position corresponding to its MPC4 front card.
  • Uses screw-terminal connectors for documented sensor, speed and output wiring.
  • Requires card keying and rack-slot alignment to match the installed VM600 assembly.
  • Passes field signals to the MPC4 for channel-health and protection evaluation.
  • Exposes buffered outputs whose 2000-ohm impedance must match connected equipment.
  • Requires complete signal-path testing after terminal or card replacement.
Description
VM600 IOC4T 200-560-000-113 is a 6U rear I/O card for an earlier-generation MPC4, providing forty-eight screw terminals for four dynamic signals and two tachometer paths.

The card routes field signals to the front processor and makes available buffered outputs, four software-controlled relays and thirty-two programmable open-collector outputs for system interfacing.

Verify the MPC4 generation, card keying and rack position before installation. Confirm every terminal assignment and output function against the project drawings before energizing connected protection circuits.
Alternative Names
Vibro-Meter VM600 IOC4T 200-560-000-113 VM600 IOC4T 200 560 000 113 VM600-IOC4T-200-560-000-113 200560000113 Vibro-Meter input output card 200-560-000-113 IOC4T rear machinery protection interface VM600 MPC4 companion I/O card IOC4T 2000-ohm buffered-output card
Technical notes
VM600 IOC4T 200-560-000-113 must remain paired with the compatible MPC4 hardware generation; verify buffered-output impedance and rear-terminal wiring before replacement.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Can VM600 IOC4T 200-560-000-113 be removed independently of its MPC4?
Treat the two cards as a paired protection assembly and follow the approved rack isolation or live-maintenance procedure.
Which MPC4 generation matches VM600 IOC4T 200-560-000-113?
The -113 IOC4T belongs to the earlier hardware arrangement; confirm the paired MPC4 part number and buffered-output impedance.
What system connections terminate on VM600 IOC4T 200-560-000-113?
It provides rear connections for four dynamic channels, two tachometer references, relays and configurable outputs.
Which MPC4 pairing must be stated when sourcing VM600 IOC4T 200-560-000-113?
Include the front-card part number, hardware generation, rack position, buffered-output impedance and required quantity.
What must be compared before replacing VM600 IOC4T 200-560-000-113?
Compare hardware generation, rack keying, terminal wiring, output impedance and the companion MPC4 configuration.
Which details should accompany a VM600 IOC4T 200-560-000-113 manual request?
Include the MPC4 part number, rack slot, terminal arrangement and required quantity for accurate document matching.
