    Apter Power provides quotations, official manuals, procurement support, and system-matching guidance for ADV157-S50.

ADV157-S50

/ 4.9
1001 reviews | Need a Specific Revision?
Yokogawa ADV157-S50 is a 32-channel isolated 24 VDC digital input module.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for ADV157-S50
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for ADV157-S50

  • Manufacturer:
    Yokogawa
  • Part Number:
    ADV157-S50
  • Product Family:
    Centum CS-Centum VP
  • Product Type:
    Digital Input Module
  • Stock:
    1
  • Number of Input Channels:
    32
  • Rated Input Voltage:
    24 VDC sink/source
  • Input ON Voltage:
    18–26.4 VDC
  • Input OFF Voltage:
    5.0 VDC or less
  • Input Current:
    4.1 mA ±20% per channel
  • Input Response Time:
    8 ms or less
  • External Connection:
    Pressure clamp terminal
  • Weight:
    0.4 kg
  • Estimated shipping dimensions:
    3.28 × 13.09 × 13.0 cm
  • Tariff Code:
    8538900000
  • Country of origin:
    Japan
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Input Data Isolation Connection

Features:

  • 32 digital input channels for 24 VDC ON/OFF signals.
  • Supports sink or source input signals.
  • Pressure clamp terminal support only.
  • S50 configuration: standard type, no explosion protection, basic type.
Yokogawa ADV157-S50 receives 32 channels of 24 VDC status input signals for an FIO node.

The inputs are common every 16 channels, and all 24 VDC signals connected to a common must use the same polarity.

Current OEM lifecycle classification for ADV157-S50 is not stated in the available manufacturer documentation. Availability is confirmed during quotation.
Yokogawa ADV157-S50 Digital Input Module Specs

General

  • Manufacturer Yokogawa
  • Model ADV157-S50
  • Condition New Original ready stock
  • Product Family CENTUM VP FIO
  • Rated input voltage: 24 VDC, sink or source.
  • Input ON voltage: 18–26.4 VDC.
  • Input OFF voltage: 5.0 VDC or less.
  • Maximum allowable input voltage: 30.0 VDC.
  • Withstanding voltage between input signals and the system: 2 kVAC for one minute.
  • Withstanding voltage between commons: 500 VAC for one minute.
  • Inputs are common every 16 channels.
  • All voltage signals on the same common must use the same polarity.
  • External connection: pressure clamp terminal.
  • Maximum current consumption: 350 mA at 5 VDC.
  • Input response time: 8 ms or less.
  • Verify terminal wiring and signal polarity before commissioning.
Description

Yokogawa ADV157-S50 is a 32-channel, 24 VDC digital input module for FIO. The S50 suffix specifies the standard, non-explosion-protected basic type.

The module receives sink or source ON/OFF signals and provides common isolation every 16 channels. It supports status input operation through its pressure clamp terminal connection.

The module has an input response time of 8 ms or less and a maximum current consumption of 350 mA at 5 VDC.

Alternative Names
ADV157-S50 ADV157 S50 ADV157S50 Yokogawa ADV157-S50 Yokogawa ADV157 S50 YOKOGAWA ADV157S50 ADV157-S50 Digital Input Module ADV157 S50 FIO Module
Technical notes
Yokogawa ADV157-S50 provides 32 isolated 24 VDC status inputs through a pressure clamp terminal. Confirm the S50 suffix, signal polarity, and terminal arrangement before replacement.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is the function of Yokogawa ADV157-S50?
It receives 32 channels of 24 VDC ON/OFF status input signals in a Yokogawa FIO system.
What input signal does ADV157-S50 accept?
The module accepts 24 VDC sink or source inputs, with an ON range of 18–26.4 VDC and an OFF level of 5.0 VDC or less.
What does the S50 suffix mean on ADV157-S50?
The official suffix table identifies -S as standard type, 5 as no explosion protection, and 0 as basic type.
How is ADV157-S50 connected?
Yokogawa specifies pressure clamp terminal support only for this module.
What should be checked before replacing ADV157-S50?
Verify the complete suffix, 24 VDC signal polarity, pressure clamp terminal wiring, and FIO node configuration.
What is the current OEM lifecycle status of ADV157-S50?
A current OEM lifecycle classification is not stated in the available Yokogawa documentation; availability is confirmed during quotation.
