DI620-3BHT300002R1

/ 4.9
1001 reviews | Need a Specific Revision?
The DI620-3BHT300002R1 is an ABB digital input module with 32 channels, 24V DC, designed for S600 I/O systems, Advant Controller 160, and Advant OCS with Master SW.
Get a quick price for DI620-3BHT300002R1
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for DI620-3BHT300002R1

  • Manufacturer:
    ABB
  • Part Number:
    DI620-3BHT300002R1
  • Product Family:
    ABB Advant OCS and Advant-800xA
  • ABB Type Designation:
    DI620
  • Product Type:
    Digital Input Module (I/O Module)
  • Channel Type:
    DI (Digital Input)
  • Number of Inputs:
    32 channels
  • Input Voltage:
    24V DC
  • RoHS Status:
    Compliant with EU Directive 2011/65/EU
  • Compatible Systems:
    S600 I/O, Advant Controller 160 (v2.2), Advant OCS with Master SW
  • Pain Point Solved:
    Solves the need for a high‑density (32‑channel) digital input module for legacy ABB S600 I/O and Advant systems – reducing cabinet space by consolidating 32 field device signals into a single module, with RoHS compliance for continued use in regulated markets.
  • Weight:
    1.16 kg
  • Estimated shipping dimensions:
    3.8x26x27.1cm
  • Tariff Code:
    8517795000
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Application Firmware and Updates Configuration

Features:

  • 32 discrete 24V DC inputs in a single module; reduces rack space and saves slots.
  • Works with S600 I/O, Advant Controller 160 (v2.2), and Advant OCS with Master SW.
  • Follows EU Directive 2011/65/EU; zero batteries for maintenance‑free operation.
The DI620-3BHT300002R1 packs 32 discrete 24V DC input channels into a single module. This high density is a significant advantage for systems with limited rack slots. Instead of using four 8‑channel modules or two 16‑channel modules, a single DI620 handles 32 field devices – such as limit switches, pushbuttons, proximity sensors, or photoelectric sensors. This consolidation frees up slots for other module types (analog, output, communication) and reduces backplane bus loading.

The DI620-3BHT300002R1 is listed under multiple ABB product categories, making it a versatile spare part for various legacy systems. It is compatible with S600 I/O (ABB's rugged, distributed I/O family), Advant Controller 160 Version 2.2, and Advant OCS with Master SW. This wide compatibility means a single DI620 module can serve as a spare for different generations of ABB control systems – from older Advant OCS installations to newer Advant Controller 160 racks. For system integrators managing multiple ABB sites, stocking a single DI620 reduces inventory complexity.

The DI620-3BHT300002R1 is fully compliant with EU Directive 2011/65/EU (RoHS), meaning it does not contain restricted hazardous substances such as lead, mercury, cadmium, or hexavalent chromium. This compliance is critical for installations in European markets and for companies with environmental sustainability policies. The module also has a SCIP number (666dc7a3-475f-4c7b-8fb7-995fd94ecfb6) for substance tracking under the EU Waste Framework Directive. Additionally, the DI620-3BHT300002R1 contains zero batteries. This eliminates battery replacement maintenance – a common nuisance in older systems with battery‑backed RAM modules. No battery means no risk of leakage, no scheduled replacement, and no data loss due to battery failure.

The DI620-3BHT300002R1 ABB Input Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).

ABB DI620-3BHT300002R1 Input Module Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
ABB DI620-3BHT300002R1 Input Module Specs

General

  • Manufacturer ABB
  • Model DI620-3BHT300002R1
  • Condition New Original ready stock
  • Product Family DI610,DI630,DI640
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Field Signal Acquisition: Used to acquire 24 VDC digital status from sensors, limit switches, contactor auxiliary contacts, or buttons.
  • Key Industrial Processes: Widely deployed in industries such as power generation, metallurgy, and chemicals to handle high-density logic inputs.
  • System Expansion: Often used with the S600 I/O system, providing up to 32 input points in a compact space (only 40mm wide), greatly improving rack utilization.
  • Update Method: The logic of the I/O module itself is usually fixed at the factory. Updates are typically made by upgrading the firmware of its associated AC 800M controller or replacing the firmware of the bus interface module responsible for data forwarding (such as the CI810B).
  • Lifecycle Management: ABB recommends checking the system firmware version during scheduled maintenance. You can find the latest controller system firmware compatible with the I/O module through ABB PCDC (Product Compatibility and Download Center).
  • Development Environment: Configure using Control Builder M or ABB Ability System 800xA software.
  • Address Assignment: In the project software's Hardware Tree, add the DI620 to the corresponding I/O slot; the system will automatically assign I/O addresses.
  • Variable Connections: Connect the 32 input channels (Channel 1–32) to Boolean variables in the application to use field signals in the control logic.
Description
The DI620-3BHT300002R1 is a digital input module with 32 channels, each rated for 24V DC. It belongs to ABB's S600 I/O family and is compatible with Advant Controller 160 (Version 2.2) and Advant OCS with Master SW.

When using the DI620-3BHT300002R1, engineers can connect up to 32 discrete field devices such as sensors, pushbuttons, limit switches, or proximity switches. The module is classified under WEEE Category 5 (small equipment) and contains zero batteries. Its customs tariff number is 85389091, with HS code 853890.

The DI620-3BHT300002R1 is RoHS compliant, following EU Directive 2011/65/EU. It has a SCIP number (666dc7a3-475f-4c7b-8fb7-995fd94ecfb6) for substance tracking. The module is listed under multiple ABB categories: S600 I/O Modules, Advant Controller 160 I/O Modules, and Advant OCS I/O Modules.

For legacy ABB system expansions or repairs, the DI620-3BHT300002R1 provides a direct 32‑channel digital input replacement. It is part of the DI620 series of digital inputs. Always verify compatibility with your specific Advant Controller or S600 I/O rack before ordering. The product ID is 3BHT300002R1.
Alternative Names
DI610 DI630 DI640 DO620
Technical notes
The DI620-3BHT300002R1 has 32 channels but no built‑in diagnostics (unlike DI640). Field wiring errors or sensor failures must be detected by the PLC logic or external monitoring.he module contains zero batteries, eliminating battery replacement maintenance. However, it has no on‑board buffering – all input states are read cyclically by the controller.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How many inputs does the DI620-3BHT300002R1 provide?
The DI620-3BHT300002R1 provides 32 digital input channels, each rated for 24V DC. This high density allows connection of up to 32 field devices (sensors, pushbuttons, limit switches) in a single module, saving valuable rack space.
Which ABB systems work with the DI620-3BHT300002R1?
The DI620-3BHT300002R1 is compatible with S600 I/O systems, Advant Controller 160 (Version 2.2), and Advant OCS with Master SW. It is listed under multiple ABB categories for I/O modules. Verify your rack compatibility before ordering.
Is the DI620-3BHT300002R1 RoHS compliant?
Yes. The DI620-3BHT300002R1 follows EU Directive 2011/65/EU (RoHS), meaning it is free from restricted hazardous substances. It also has a SCIP number for substance tracking. This makes it suitable for use in European markets and environmentally conscious installations.
