        • Lifecycle status

          Active / Available from OEM
          Apter Power supports AO810V2 quotations, loop-document review, MTU matching, and sourcing guidance.

        AO810V2 3BSE038415R1

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        ABB AO810V2 3BSE038415R1 is an eight-channel S800 I/O analog output module for 0–20 mA or 4–20 mA current loops with cyclic diagnostics.
        In Stock
        Ships by Sunday, October 18
        Fast Shipping Available
        Get a quick price for AO810V2 3BSE038415R1
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for AO810V2 3BSE038415R1

        • Manufacturer:
          ABB
        • Part Number:
          AO810V2 3BSE038415R1
        • Product Family:
          ABB Advant OCS and Advant-800xA
        • Product Type:
          Analog Output Module
        • Stock:
          1
        • ABB Article Number:
          3BSE038415R1
        • Output Ranges:
          0–20 mA; 4–20 mA
        • Output Channels:
          8
        • Resolution:
          14 bit
        • Isolation:
          Groupwise isolated from ground
        • Update Cycle:
          ≤ 2 ms
        • Output Load:
          ≤500 Ω on L1+; 250–850 Ω on L2+
        • Error:
          Maximum 0.1% at 0–500 Ω
        • Rise Time:
          0.35 ms at 500 Ω
        • Field Cable Length:
          Up to 600 m
        • Matching MTUs:
          TU810V1, TU812V1, TU814V1, TU830V1, TU833
        • Keying Code:
          AE
        • Protection Rating:
          IP20
        • Weight:
          0.18 kg
        • Estimated shipping dimensions:
          Product dimensions: 4.5 x 11.1 x 11.9 cm (W x D x H), including connector.
        • Tariff Code:
          Please confirm the destination before shipping
        • Country of origin:
          Sweden
        • Place of shipment:
          Xiamen,Fujian,China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Specifications Load Planning Diagnostics Loop Commissioning

        Features:

        • Eight current loops: The module supports 0–20 mA and 4–20 mA output ranges.
        • Cyclic supervision: Readback diagnostics monitor output power and active-channel continuity.
        • Protected output stage: The output is current limited and protected against defined short-circuit conditions.

        AO810V2 is intended for analog final-control and indication loops that require supervised current output from S800 I/O.

        Loop resistance depends on the external supply connection, so L1+ or L2+ wiring must be reviewed with the field load.

        Commissioning should prove scaling, polarity, safe output behavior, open-circuit diagnostics, and the connected device response.

        Availability is subject to Apter Power's current inventory and sourcing confirmation.

        AO810V2 3BSE038415R1 Analog Output Module Manuals, Datasheets, Links

        Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

        ABB AO810V2 3BSE038415R1 Analog Output Module Specs

        General

        • ManufacturerABB
        • ModelAO810V2 3BSE038415R1
        • ConditionNew Original ready stock
        • Product FamilyABB S800 I/O and AC 800M

        Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

        Current-loop design checks

        • Supply path: Identify whether each loop uses L1+ or L2+.
        • Resistance budget: Include device input and complete cable resistance.
        • Polarity: Trace positive and return conductors before transfer.
        • Scaling: Match controller engineering units to the configured range.

        Fault-isolation workflow

        • Power supervision: Check common output supply before individual channels.
        • Open circuit: Test continuity only under the approved isolation procedure.
        • Readback: Compare commanded and reported loop behavior.
        • Indicators: Record module warnings and channel faults before reset.

        Controlled acceptance

        • Safe state: Secure the final element before driving outputs.
        • Test points: Use project-approved low, mid, and high current values.
        • Feedback: Compare field response with the control-system indication.
        • Handover: Retain results with the loop and cabinet records.
        Description
        The AO810V2 3BSE038415R1 supplies eight unipolar analog current outputs for S800 I/O applications using 0–20 mA or 4–20 mA loops.

        For AO810V2 3BSE038415R1, ABB documents 14-bit conversion, group isolation, fast updates, output-power supervision, open-circuit detection, and protected current outputs.

        Before ordering AO810V2 3BSE038415R1, verify loop range, load resistance, external supply connection, field cable, scaling, keying code, and installed MTU.
        Alternative Names
        ABB AO810V2 3BSE038415R1 AO810V2 3BSE038415R1 AO810V2 AO810 V2 AO-810-V2 3BSE038415R1 3BSE 038415 R1 S800 AO810V2 analog output
        Technical notes
        ABB AO810V2 3BSE038415R1 is a analog output module documented for ABB S800 I/O and AC 800M. Verify the complete article, installed hardware, wiring, and system configuration before ordering.
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        How should the loop load be checked for AO810V2 3BSE038415R1?
        Calculate the total device and cable resistance, then confirm the selected external-supply terminal arrangement provides sufficient compliance for every active loop.
        Can AO810V2 3BSE038415R1 change between 0–20 mA and 4–20 mA without project review?
        The configured range, controller scaling, alarm limits, connected device, and commissioning procedure must all agree before changing a loop range.
        What commonly causes an AO810V2 open-circuit channel error?
        Inspect field terminals, cable continuity, device input, loop polarity, external supply, and whether the commanded current is high enough for the diagnostic condition.
        Why does AO810V2 output power supervision matter during commissioning?
        A low external supply can affect multiple loops, so engineers should separate common power problems from individual field-circuit faults.
        What should be backed up before replacing AO810V2 3BSE038415R1?
        Save the hardware configuration, channel ranges, engineering scaling, output-state settings, alarm handling, and loop-test records.
        How should an AO810V2 loop be tested safely?
        Hold the process safe, isolate or simulate the final element as required, drive controlled current points, and compare feedback with the approved calibration plan.
        Which installation details affect AO810V2 signal quality?
        Review grounding, shielding, cable separation, terminal condition, loop resistance, cabinet temperature, and external power quality.
        What should an AO810V2 procurement RFQ include?
        Provide quantity, destination, required date, full article label, MTU model, loop ranges, load information, and requested documentation.
