ABB CI522A 3BSE018283R1 is an AF100 interface module for S800 I/O stations, adding redundant Advant Fieldbus 100 communication and documented long-distance support for Advant controllers.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for CI522A 3BSE018283R1
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for CI522A 3BSE018283R1

  • Manufacturer:
    ABB
  • Part Number:
    CI522A 3BSE018283R1
  • Product Family:
    ABB Advant OCS and Advant-800xA
  • Product Type:
    AF100 Interface Module
  • Stock:
    1
  • Supported I/O Platform:
    S800 I/O
  • Communication:
    Redundant AF100
  • AC410 Compatibility:
    Base version 1.4 or later
  • AC450 Compatibility:
    Base version 2.2 or later
  • Exchange Part Number:
    EXC3BSE018283R1
  • Dimensions:
    12 × 2.7 × 26.5 cm
  • Weight:
    0.2 kg
  • Tariff Code:
    8538900000
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Compatibility Kit Context Ordering Application
  • AF100 interface for S800 I/O stations
  • Supports redundant Advant Fieldbus 100 communication
  • Adds the long-distance support documented for CI522A

CI522A 3BSE018283R1 is an ABB AF100 interface module designed to connect S800 I/O stations to supported Advant controllers.

Its documented role includes redundant AF100 communication and long-distance connection arrangements that distinguish CI522A from the earlier CI522.

Before installation or replacement, verify the controller base version, redundant-path assignment, S800 station configuration, special modem cable and complete product or exchange order code.

Availability, condition, price, and shipping time for CI522A 3BSE018283R1 are confirmed during quotation.

ABB CI522A 3BSE018283R1 AF100 Interface Module Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • AC410 support starts from base version 1.4
  • AC450 support starts from base version 2.2
  • ABB Product Details also places the module in AC400, AC460 and RMC product groups
  • ABB lists CI522A within AF100 communication set 3BSE014070R1
  • CI522AK01 through CI522AK06 are separately identified AF100 interface kits containing the module
  • CI522AK11 through CI522AK16 and CI522AK21 through CI522AK26 are additional documented kit configurations
  • Standard product ID is 3BSE018283R1
  • Exchange product ID is EXC3BSE018283R1
  • ABB lists multiple kits separately, so a kit code must not replace the module identity
  • S800 I/O stations with redundant AF100 communication
  • AC410 systems at base version 1.4 or later
  • AC450 systems at base version 2.2 or later, including documented long-distance links
Description
CI522A 3BSE018283R1 is an ABB AF100 interface module for S800 I/O stations used with Advant controller platforms.

The module supports redundant AF100 communication and the long-distance arrangements documented for CI522A, with compatibility from AC410 base version 1.4 and AC450 base version 2.2.

Before installation or replacement, confirm the exact order code, controller base version, S800 I/O station, redundant communication arrangement, modem cable and available mounting space.
Alternative Names
CI522A 3BSE018283R1 3BSE018283R1 CI522A ABB CI522A 3BSE018283R1 ABB CI522A CI522A 3BSE018283R1
Technical notes
CI522A 3BSE018283R1 requires confirmation of the controller base version, S800 I/O station, redundant AF100 paths and long-distance modem cable; substituting CI522 without checking these functions creates compatibility risk.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Can CI522A 3BSE018283R1 be treated as a drop-in replacement for every CI522 installation?
ABB identifies CI522A as the replacement for CI522, but the installed controller baseline, S800 I/O station, redundant AF100 paths and any long-distance modem arrangement still need to be matched before exchange.
Can CI522A 3BSE018283R1 provide redundant AF100 communication for S800 I/O?
Yes. ABB identifies CI522A as the AF100 interface for S800 I/O stations with redundant communication. The paired interfaces and fieldbus paths must match the installed design.
What should be checked if an S800 I/O station does not communicate after installing CI522A 3BSE018283R1?
Verify that the controller meets ABB's documented CI522A software baseline, then check both AF100 paths, the paired interface arrangement, modem cabling and the station configuration before assuming the new module is faulty.
Can an unidentified existing modem cable be reused with CI522A 3BSE018283R1?
Do not assume so. ABB documents special modem cables for CI522A long-distance arrangements, and the required cable depends on the controller installation. Match the cable identity and connection scheme before reuse.
What information should be supplied when requesting a replacement for CI522A 3BSE018283R1?
Provide the complete installed label, controller type and base version, S800 I/O role, redundant-path arrangement, modem-cable identity and whether a standard or exchange service item is required.
Does CI522A 3BSE018283R1 support the documented long-distance AF100 arrangement?
Yes. ABB specifically distinguishes CI522A by long-distance support. Use the manufacturer-specified modem arrangement and special cable rather than treating it as a direct short-distance cable extension.
What identity checks should be completed before replacing CI522A 3BSE018283R1?
Match CI522A, product ID 3BSE018283R1, the target Advant platform, S800 I/O role, base-version requirement, redundant AF100 arrangement and the installed modem cable.
