ABB DSDX454 5716075-AT is an S400 digital basic unit with twenty 48 V DC inputs, twelve relay outputs, MasterFieldbus SDB communication, and expansion support.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for DSDX454 5716075-AT
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for DSDX454 5716075-AT

  • Manufacturer:
    ABB
  • Part Number:
    DSDX454 5716075-AT
  • Product Family:
    ABB Advant OCS and Advant-800xA
  • Product Type:
    S400 Digital Basic Unit
  • Stock:
    1
  • I/O Platform:
    S400 remote I/O
  • Unit Role:
    Digital basic unit
  • Digital Inputs:
    20
  • Input Signal Level:
    48 V DC
  • Digital Outputs:
    12
  • Output Type:
    Relay
  • Communication:
    MasterFieldbus SDB
  • Monitoring:
    Power loss, startup self-test and communication monitoring
  • Indicators:
    Operation, channel, power supply and transducer power supply
  • Supported Expansion Units:
    DSDX 453 or DSDI 453
  • Dimensions:
    23.5 × 21.8 × 8.8 cm
  • Weight:
    2.85 kg
  • Tariff Code:
    8538900000
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Signal Arrangement Station Diagnostics Expansion and Migration Application
  • Twenty digital inputs are specified for 48 V DC field signals.
  • Twelve digital outputs use relay contacts.
  • MasterFieldbus SDB communication supports an expandable S400 station.

DSDX454 5716075-AT is the ABB DSDX 454 digital basic unit for S400 remote I/O installations.

The unit combines twenty 48 V DC inputs, twelve relay outputs, MasterFieldbus SDB communication, power-loss monitoring and startup self-test.

Confirm the complete 5716075-AT identity, field voltage, relay loads, bus address and any DSDX 453 or DSDI 453 expansion before installation.

Availability, condition, price, and shipping time for DSDX454 5716075-AT are confirmed during quotation.

ABB DSDX454 5716075-AT S400 Digital Basic Unit Manuals, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • The basic unit provides twenty digital input channels.
  • ABB specifies the DSDX 454 input circuits for 48 V DC signals.
  • Twelve relay outputs provide the documented digital output section.
  • The unit monitors loss of power and runs a self-test during startup.
  • Communication supervision is included for the MasterFieldbus SDB connection.
  • Indicators cover operation, individual channels, power supply and transducer power supply.
  • DSDX 453 and DSDI 453 are the documented expansion choices for DSDX 454.
  • ABB maps a standalone DSDX 454 position to TU402 in the S400-to-S800 evolution system.
  • Expanded stations use TU405 with DSDI 453 or TU407 with DSDX 453.
  • 48 V DC digital-input acquisition in ABB S400 remote I/O stations.
  • Relay-output control over MasterFieldbus SDB in Advant Master installations.
  • Retention or migration of DSDX 454 field wiring through the documented S400-to-S800 evolution assemblies.
Description
DSDX454 5716075-AT is the ABB DSDX 454 digital basic unit for S400 remote I/O installations.

It combines twenty 48 V DC digital inputs with twelve relay outputs, communicates over MasterFieldbus SDB, and monitors power loss, startup self-test and communication status.

Match the full 5716075-AT identity, field voltage, output loads, address setting and any DSDX 453 or DSDI 453 expansion before installation or controlled migration.
Alternative Names
DSDX454 5716075-AT DSDX 454 5716075-AT DSDX454 DSDX 454 5716075-AT ABB DSDX454 5716075-AT ABB DSDX 454 5716075-AT U5716075-AT
Technical notes
DSDX454 5716075-AT is the 48 V DC S400 digital basic unit; verify relay loads, MasterFieldbus SDB addressing and the exact DSDX 453 or DSDI 453 expansion arrangement.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Which signal mix must an ABB DSDX454 5716075-AT replacement preserve?
Preserve the documented combination of twenty 48 V DC digital inputs and twelve relay outputs. A board with a similar S400 enclosure but a different input voltage or output type is not an evidence-based substitute.
Which expansion units are documented for ABB DSDX454 5716075-AT?
ABB lists DSDX 453 and DSDI 453 as expansion choices for the DSDX 454 basic unit. Confirm the installed expansion type, connector path and project address before replacement.
What communication path is used by ABB DSDX454 5716075-AT?
The basic unit communicates over MasterFieldbus SDB. Keep the fieldbus connection, address switches and controller configuration aligned with the installed S400 station.
How does ABB DSDX454 5716075-AT report operating problems?
ABB documents monitoring for power loss, startup self-test and communication, with indicators for operation, channels, power supply and transducer power supply. Use those indications together with system diagnostics.
Which ABB migration hardware applies to a standalone ABB DSDX454 5716075-AT position?
ABB maps a standalone DSDX 454 to TU402 3BSE035452R1 in the S400-to-S800 evolution arrangement. Expansion combinations use different termination assemblies and must be matched separately.
What should be checked before commissioning ABB DSDX454 5716075-AT?
Verify the complete label, 48 V DC input circuits, relay-output loads, field commons, MasterFieldbus SDB address, expansion connection and controller I/O configuration before enabling outputs.
What should be retained before removing ABB DSDX454 5716075-AT from an operating S400 station?
Record the MasterFieldbus SDB address, connected DSDX 453 or DSDI 453 expansion, input commons, relay-output assignments, indicator state and controller I/O configuration so the documented station arrangement can be restored and checked.
