ABB DSTX 120 57160001-MA is the S100 I/O connection unit documented for DSDP 160 and the QGLF 108 process-I/O application.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for DSTX 120 57160001-MA
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for DSTX 120 57160001-MA

  • Manufacturer:
    ABB
  • Part Number:
    DSTX 120 57160001-MA
  • Product Family:
    ABB Advant OCS and Advant-800xA
  • Product Type:
    S100 I/O Connection Unit
  • Stock:
    1
  • Associated I/O board:
    DSDP 160
  • Documented process-I/O context:
    QGLF 108
  • Control-system category:
    MasterPiece 200 accessories
  • Dimensions:
    9.9 × 5.85 × 30.6 cm
  • WEEE category:
    5, small equipment
  • Battery content:
    No batteries
  • RoHS status:
    Exempt according to ABB product data
  • Weight:
    0.375 kg
  • Tariff Code:
    8538900000
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals DSDP Link Terminal Transfer System Validation Application
  • S100 I/O module termination unit designed for the DSDP 160 board
  • Documented for the DSDP 160 process-I/O arrangement associated with QGLF 108
  • MasterPiece 200 and 200/1 control-system accessory identified by ABB product ID 57160001-MA

DSTX 120 57160001-MA is an ABB S100 I/O connection unit classified as a module termination unit for the DSDP 160 board. It provides the field-connection interface and is not a replacement for the I/O board itself.

ABB documents the unit for the DSDP 160 S100 I/O board used in the QGLF 108 process-I/O arrangement and places it within MasterPiece 200 and 200/1 control-system accessories. Compatibility with another S100 I/O board must not be assumed.

Before replacement, confirm the complete 57160001-MA product identity, record every terminal and cable position and verify the associated DSDP 160 board label. Reproduce the existing field connections only after the old and replacement terminal arrangements have been compared.

Availability, condition, price, and shipping time for DSTX 120 57160001-MA are confirmed during quotation.

ABB DSTX 120 57160001-MA S100 I/O Connection Unit Datasheet, Manuals, and Support Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Confirm DSDP 160 on the installed I/O board label.
  • Record the cable path between the connection unit and its board.
  • Do not connect the unit to another S100 board without ABB confirmation.
  • Label all occupied terminals before any conductor is removed.
  • Move wiring only after the old and replacement terminal layouts are compared.
  • Inspect conductor seating and strain relief before controller power-up.
  • Confirm the QGLF 108 process-I/O context where applicable.
  • Verify the MasterPiece 200 or S100 I/O configuration record.
  • Complete channel checks through the associated DSDP 160 board after installation.
  • DSDP 160 S100 I/O board field-connection assemblies
  • QGLF 108 process-I/O installations documented by ABB
  • MasterPiece 200 control-system accessory installations using DSTX 120
Description
DSTX 120 57160001-MA is the ABB connection unit identified for the DSDP 160 S100 I/O board and QGLF 108 process-I/O arrangement.

ABB classifies it as a module termination unit within MasterPiece 200 control-system accessories and provides the complete 57160001-MA ordering identity.

Selection depends on the associated DSDP 160 board and existing terminal wiring, so the unit must not be chosen solely from its DSTX designation.
Alternative Names
DSTX 120 57160001-MA DSTX120 57160001-MA 57160001-MA DSTX 120 57160001-MA DSTX120 ABB DSTX 120 57160001-MA ABB 57160001-MA DSTX 120
Technical notes
DSTX 120 57160001-MA requires confirmation of the DSDP 160 board, QGLF 108 process-I/O context and recorded terminal wiring before replacement to prevent S100 I/O mismatch.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What must be matched before ordering ABB DSTX 120 57160001-MA?
Match the complete 57160001-MA identity, the associated DSDP 160 board and the documented S100 I/O system context.
Which board is ABB DSTX 120 57160001-MA intended to connect?
ABB identifies DSDP 160 as the associated S100 I/O board; confirm the installed board label before ordering.
What should be recorded before removing ABB DSTX 120 57160001-MA?
Record every terminal and cable position, the DSDP 160 board identity and the mechanical mounting before isolation.
Can ABB DSTX 120 57160001-MA be selected for a different S100 I/O board?
No cross-board compatibility is established by the located ABB data; use it only after confirming the DSDP 160 context.
What should be checked if signals are missing after fitting ABB DSTX 120 57160001-MA?
Recheck terminal allocation, cable continuity and the DSDP 160 interface before following the applicable MasterPiece or S100 I/O diagnostics.
Does ABB DSTX 120 57160001-MA replace the DSDP 160 board?
No. ABB describes DSTX 120 as the connection unit used with DSDP 160, not as the I/O board itself.
Are cables included with ABB DSTX 120 57160001-MA?
ABB product data does not confirm bundled field cables; verify included items from the quoted stock description.
